dallmeier IPS 2400 Manuel utilisateur
Service
English
Rev. 1.1.0 / 2014-10-06
Appliance
PRELOADED
IPS 2400
SMAVIA Appliance
www.dallmeier.com 2
Information about copyright, trademarks, design patents
© 2014 Dallmeier electronic
The reproduction, distribution and utilization of this document as well as the communication of
its contents to others without express authorization is prohibited. Offenders will be held liable for
the payment of damages. All rights reserved in the event of the grant of a patent, utility model or
design.
We reserve the right to make technical modications.
The manufacturer accepts no liability for damage to property or pecuniary damages arising due
to minor defects of the product or documentation, e.g. print or spelling errors, and for those not
caused by intention or gross negligence of the manufacturer.
Dallmeier electronic GmbH & Co.KG
Cranachweg 1
93051 Regensburg
Germany
www.dallmeier.com
info@dallmeier.com
All trademarks identied by ®are registeres trademarks of Dallmeier electronic.
All trademarks identied by *)are trademarks of the following owners:
Third-party trademarks are named for information purposes only.
Dallmeier electronic respects the intellectual property of third parties and always attempts to ensure the complete identication of thirdparty
trademarks and indication of the respective holder of rights. In case that protected rights are not indicated separately, this circumstance is
no reason to assume that the respective trademark is unprotected.
SMAVIA Appliance
www.dallmeier.com 3
1 Introduction...................................................................................................4
1.1 Validity.............................................................................................................4
1.2 Documents......................................................................................................4
1.3 Typographical Conventions.............................................................................5
2 Safety Instructions........................................................................................6
3 General Notes................................................................................................8
3.1 Appropriate Use..............................................................................................8
3.2 Performance Features ....................................................................................8
3.3 Warranty .........................................................................................................8
3.4 Mainboard Battery...........................................................................................8
4 Login ..............................................................................................................9
4.1 Local Login......................................................................................................9
4.2 Remote Login................................................................................................11
5 Licenses.......................................................................................................13
6 Update..........................................................................................................14
6.1 Maintenance License....................................................................................14
6.2 Implementation .............................................................................................15
7 System Parameters.....................................................................................16
7.1 Default Parameters.......................................................................................16
7.2 Export Parameters........................................................................................16
7.3 Import Parameters ........................................................................................17
8 HDDs ............................................................................................................19
8.1 Identify ..........................................................................................................19
8.1.1 Information Dialog.........................................................................................19
8.1.2 Display ..........................................................................................................20
8.2 Procedure .....................................................................................................20
8.2.1 With RAID System ........................................................................................20
8.2.2 Without RAID System ...................................................................................22
8.3 Exchange......................................................................................................23
9 Power Supply Modules...............................................................................26
9.1 Identify ..........................................................................................................26
9.1.1 Information Dialog.........................................................................................26
9.1.2 Display ..........................................................................................................27
9.1.3 Status LED....................................................................................................27
9.2 Deactivation ..................................................................................................28
9.3 Exchange......................................................................................................28
10 Cleaning.......................................................................................................31
Table Of Contents
SMAVIA Appliance
www.dallmeier.com 4
1.1 Validity
This document is valid for the SMAVIA Recording Server appliance IPS 2400 in conjunction
with the preloaded VideoIP server software SMAVIA Recording Server 8.X.6.
The images in this document might differ from the actual product.
1.2 Documents
Data Sheet
Technical specications and data
(for trained system integrators)
Commissioning
Instructions for installation, connection and commissioning
(for trained system integrators)
Service (this document)
Instructions for maintenance and cleaning
(for trained system integrators)
Main Functions
For instructions on using basic functions of the software
(for users with no technical knowledge)
Operation
For instructions on using all features of the software
(for users with no technical knowledge)
Conguration
Instructions for conguring the software
(for trained system integrators)
1 Introduction
SMAVIA Appliance
www.dallmeier.com 5
1.3 Typographical Conventions
This document may contain various warning words and symbols that indicate potential
sources of danger.
DANGER
DANGER indicates a hazardous situation which, if not avoided, will result
in death or serious injury.
WARNING
WARNING indicates a hazardous situation which, if not avoided, could
result in death or serious injury.
CAUTION
CAUTION indicates a hazardous situation which, if not avoided, could
result in minor or moderate injury.
NOTICE
NOTICE indicates practices for preventing property damage, incorrect
congurations or faulty operations.
For reasons of clarity and readability, various text formatting elements and types of empha-
sis are used in this documentation:
Instructions are indicated by arrows ().
Always carry out instructions one after the other in the sequence described.
Expressions in bold/italics generally indicate a control element on the device (switches or
labels) or on its user interface (buttons, menu entries).
Paragraphs in italics provide information on basic principles, special features and efcient
procedure as well as general recommendations.
SMAVIA Appliance
www.dallmeier.com 6
Only use the units described in this document if they are technically in proper working
condition and for the intended purpose while keeping safety and potential dangers in
mind.
Qualied Personnel
The installation, mounting, connection, commissioning and conguration of the units may
only be carried out by qualied personnel.
This also applies to the maintenance, testing and repair, whereat the regulations of the
DIN VDE 0701 series of standards (repair, modication and inspection of electrical appli-
ances) must be followed.
Regulations
The use of video and audio surveillance systems is, in general, strictly regulated.
Inform yourself about the currently valid laws and regulations regarding data, worker and
environmental protection before using the units and ensure compliance with them.
System Components
Only use internal components that have been tested and approved by Dallmeier.
Inappropriate internal components may cause malfunctions, damages and data loss and
may result in the loss of warranty.
Modications
Do not make any modications to the hardware or software that have not been tested and
approved by Dallmeier.
Inappropriate modications may cause malfunctions, damages and data loss and may
result in the loss of warranty.
Documentation
Read the documents included in the delivery carefully and thoroughly.
Always observe the contained instructions, notes and warnings.
Condensation Water
If the units are brought from a cold to a warm environment, resulting condensation water
may cause malfunctions and damages.
In this case, wait (up to 8 hours) until the units have reached room temperature before
commissioning.
Earthing & Equipotential Bonding
For the safety of persons (protection against dangerous contact voltages) and devices
(protection against overvoltages) and the immunity of information and communication
technology equipment to electromagnetic interferences (EMI), all protective measures,
which are specied by the currently valid DIN, VDE and ISO standards and which provide
for a standard-compliant earthing and a correct equipotential bonding of electrical and
electronic devices, are mandatory and must be fullled by all means.
2 Safety Instructions
SMAVIA Appliance
www.dallmeier.com 7
Lightning Storms
To avoid damage to the units by electrical surge during lightning storms, unplug the units
from the mains power supply (pull out the power plug).
This is also recommended, when the units have been unused for a long period of time.
Operating Conditions
Unfavourable operating conditions can shorten the life of the units and may cause mal-
functions, damages and data loss and may result in the loss of warranty.
Observe the specications given in the technical data, the operating condition require-
ments and the maintenance instructions.
Shocks
Shocks can cause malfunctions and damages.
The units may not be moved while in operation.
Foreign Bodies
If objects or liquids get into the units, immediately disconnect them from the power supply
(pull out the power plug).
Contact the sales partner responsible for your area.
Burnt Smell
If you notice burnt smell or formation of smoke from the units, immediately disconnect
them from the power supply (pull out the power plug).
Contact the sales partner responsible for your area.
Opening
The housings of the units may only be opened by qualied personnel for commissioning,
inspection, maintenance and repair.
Disposal
Do not dispose waste electrical and electronic equipment into the household trash.
Disconnect the units from the power supply.
Remove all connected devices.
Return the units to your respective sales partner.
SMAVIA Appliance
www.dallmeier.com 8
3 General Notes
3.1 Appropriate Use
The IPS 2400 is a high performance appliance with a processing capacity for up to 24 IP vi-
deo channels and an integrated storage system. In conjunction with the dedicated software
SMAVIA Recording Server it is optimally suited for all applications which require a high
recording speed, enhanced storage capacity and low power consumption while providing
maximum security. The IPS 2400 is characterised by its space-saving design as well as
low power consumption and low heat emission. It can be installed in a 19“ rack using the
included 19“ bracket.
3.2 Performance Features
• High performance server hardware with Multi-Core CPU
• Flash memory for operating system
• Suitable for up to 24 SD, HD or megapixel video channels
• High storage capacity due to integrated storage system
• High recording speed due to concerted components
• Easy-Change functionality for hard disk drives (hot-swap)
• Components optimized for SMAVIA Recording Server
• 19“ bracket included in delivery
3.3 Warranty
The terms and conditions valid at the signing of the contract shall apply.
3.4 Mainboard Battery
Important basic functions (eg time and hardware settings) can be obtained from a battery
on the main board of the appliance. If the battery is emptied after a certain time (3-6 ye-
ars), it may cause interference during the boot process: The appliance will not start after a
complete shutdown.
The battery on the mainboard must be replaced only by authorized personnel.
Contact for an exchange the Dallmeier service.
CAUTION
Injury due to explosion hazard!
Replace the battery on the main board always by a battery of the same
type.
Dispose of used batteries according to the present instructions.
SMAVIA Appliance
www.dallmeier.com 9
4 Login
After connecting and operating the appliance, the device can be congured locally (moni-
tor) or on the ethernet (workstation with NetCong).
Note the documentation “Commissioning”. It contains detailed instructions on mounting,
connection assignment and commissioning of the device.
4.1 Local Login
In order to access the conguration interface of the appliance, proceed as follows:
Move the mouse pointer to the bottom of the screen.
The Login button is displayed.
Fig. 4-1
Click Login.
The virtual keyboard is displayed.
Enter the password.
Conrm with OK.
SMAVIA Appliance
www.dallmeier.com 10
The conguration interface is displayed.
Fig. 4-2
Make the required settings (see below).
Click Close in order to exit the conguration interface.
Table des matières
Autres manuels dallmeier Serveur
dallmeier
dallmeier PVS IV Instructions d'utilisation et d'entretien
dallmeier
dallmeier SMAVIA appliance VideoNetBox II Mode d’emploi
dallmeier
dallmeier SMAVIA VideoNetBox III Instructions de montage
dallmeier
dallmeier VideoNetBox eXd Mode d’emploi
dallmeier
dallmeier DMS 2400 Mode d’emploi
dallmeier
dallmeier SMAVIA IPS 10000 Manuel utilisateur
dallmeier
dallmeier VideoNetBox Manuel utilisateur
dallmeier
dallmeier VideoNetBox Instructions de montage
dallmeier
dallmeier DIS-4/M SRS Mode d’emploi
dallmeier
dallmeier DIS-2/M UTP Mode d’emploi
