Daikin TSTATD2200C-2 Mode d'emploi
Non-Programmable
Owner's
Manual
and
Installation
Instructions
Digital Thermostat
with Humidity Control • Multi Stage 2+2
TSTATD2200C-2
COMMERCIAL
for
Commercial Use
D_TSTATD2200C-2_Manual_HR.pdf 1 8/29/13 1:11 PM
PAGE I
NOTE: Due to variations in environmental conditions, it is not
always possible to achieve the desired humidification or
dehumidification setpoint.
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) this device may not cause
harmful interference, and (2) this device must accept any interference
received, including interference that may cause undesired operation.
Follow the Installation Instructions before proceeding.
Set the thermostat mode to “OFF” prior to changing
settings in setup or restoring Factory Defaults.
CAUTION
FOR HOME OR OFFICE USE
Tested to Comply
with FCC Standards
Thermostat TSTATD2200C-2
D_TSTATD2200C-2 _p3.pdf 3 9/6/13 3:30 PM
Glossary of Terms
PAGE II
Auto-Changeover: A mode in which the thermostat will turn on the
heating or cooling based on room temperature demand.
Cool Setpoint: The warmest temperature that the space should rise
to before cooling is turned on (without regard to deadband).
Deadband: The number of degrees the thermostat will wait, once a
setpoint has been reached, before energizing heating or cooling.
Dehumidify: To reduce the amount of moisture in the air.
Differential: The forced temperature difference between the heat set-
point and the cool setpoint.
Heat Setpoint: The coolest temperature that the space should drop
to before heating is turned on (without regard to deadband).
Humidify: To increase the amount of moisture in the air.
Icon: The word or symbol that appears on the thermostat display.
Mode: The current operating condition of the thermostat (i.e. Off,
Heat, Cool, Auto, Program On).
Non-Programmable Thermostat: A thermostat that does not have
the capability of running Time Period Programming.
Temperature Swing: Same as Deadband.
D_TSTATD2200C-2_Manual_HR.pdf 5 8/29/13 1:11 PM
Table of Contents
PAGE III
5
1
17
18
21
22
23
15
Quick Start
Get to Know Your Thermostat
USER SETUP
Thermostat Display Options
Humidification & Dehumidification
Locking and Unlocking the Keypad
24
Factory Defaults
Dry Contact Operation
INSTALLER SETUP
16
Scrolling Display Options
System Runtimes
Advanced Setup
TECHNICIAN SETUP
29
Advanced Output Testing
Equipment Testing
19
Backlight Operation
25
26
Troubleshooting
Sensor Calibration 25
25
INDEX
16
Emergency Heat
27
Advanced Setup Table
7
INSTALLATION INSTRUCTIONS
Sample Wiring Diagrams 11
Test Operation 14
Setpoint Limits 19
20
Remote Sensor Operation
D_TSTATD2200C-2_Manual_HR.pdf 7 8/29/13 1:11 PM
OVERRIDE
OUTDOOR
HUMIDITY MODE
OVERRIDE
Outdoor
COOL
79
77
80
AUTOON
FAN
RST FLTR
EMERGCY
HEAT DISPLAY ACCESSORY SETUPSERVICE
RST FILTER
EMERGCY
HEAT DISPLAY ACCESSORY SETUPSERVICE
OVERRIDE
HUMIDITY MODE
OVERRIDE
Outdoor
C
OO
L
79
77
80
RUNOFF
PROGRAM
HOLD TO SET
RST FLTR
EMERGCY
HEAT DISPLAY ACCESSORY SETUPSERVICE
SET CLOCK
EMERGCY
HEAT DISPLAY ACCESSORY SETUPHOLIDAY
PAGE 1
Get to Know Your Thermostat
Down
Button Override
Button Up
Button
Heat or Cool
Demand Indicator
Red = Heat
Green = Cool
Backlit LCD Display Front Panel
Scrolling Display
Emergency
Heat Service Accessory
Humidity
Outdoor Temp.
Mode
Display
Options
Setup
Reset
Filter
Fan
On | Auto
Hidden
Buttons
D_TSTATD2200C-2_Manual_HR.pdf 9 8/29/13 1:11 PM
PAGE 2
Mode Indicators
Selects the operational mode of the equipment.
HEAT - Indicates the heating mode.
COOL - Indicates the air conditioning mode.
HEAT & COOL - Indicates the system will automatically change-
over between heat and cool modes as the temperature varies.
OFF - Indicates heating and cooling is turned off.
RoomTemperature Display
Indicates the current room temperature and displays the outdoor
temperature when selected.
The scrolling display will be used to help you easily navigate the setup
screens in the thermostat.
Get to Know Your Thermostat
Outdoor icon
Indicates the temperature displayed is from the optional outdoor
sensor.
Outdoor
Fan On
AUXHEAT
Setup Step
2nd
Stage
COOL
88
88
Lo
88
H
88
Display Features
D_TSTATD2200C-2_Manual_HR.pdf 10 8/29/13 1:11 PM
Outdoor
Fan On
AUXHEAT
Setup Step
2nd
Stage
COOL
88
88
Lo
88
H
88
PAGE 3
Desired SetTemperature
Indicates desired room temperature(s).
Setup Step icon
Indicates the step number when the thermostat is in the
setup mode.
icon
Indicates the keypad has been locked.
2nd Stage icon
Indicates what stage of cooling or heating is currently energized.
Get to Know Your Thermostat
Display Features
6
6
D_TSTATD2200C-2_Manual_HR.pdf 11 8/29/13 1:11 PM
AuxHeat icon
Indicates 2nd stage electric strip heat is being used when the
thermostat is programmed for Heat Pump operation.
Fan On icon
Indicates constant, continuous fan operation.
When Fan On is not lit - indicates the fan will only operate when
necessary to heat or to cool.
PAGE 4
Get to Know Your Thermostat
Display Features
Outdoor
Fan On
AUXHEAT
Setup Step
2nd
Stage
COOL
88
88
Lo
88
H
88
10
10
D_TSTATD2200C-2_Manual_HR.pdf 12 8/29/13 1:11 PM
PAGE 5
Press the UP or DOWN buttons to modify the selection.
Quick Start
Press the MODE button to advance and confirm through the setup steps.
During Setup and Programming:
Selecting the Heat or Cool Mode
Select mode by pressing the MODE button.
Heating Only - The HEAT setting indicates the temperature the room has to reach
before the furnace will turn on to heat the room.
Cooling Only - The COOL setting indicates the temperature the room has to reach
before the air conditioner will turn on to cool the room.
Heating or Cooling (Auto-Changeover) - AUTO will automatically select heat or cool
based on room temperature demand.
OFF - OFF indicates both heating and air conditioning systems are turned off.
Selecting Your Desired Temperature
AUTO-CHANGEOVER MODE - Pressing the UP or DOWN buttons in Auto mode
will adjust both the heat and cool setpoints simultaneously. To adjust heat and cool
setpoints individually, choose HEAT mode to adjust the heat setpoint and COOL
mode to adjust the cool setpoint, then return to AUTO mode.
HEAT OR COOL MODE - Pressing the UP or DOWN buttons in Heat or
Cool mode will adjust only the heat or cool setpoints individually displayed.
NOTE - This thermostat has a fixed two degree deadband. With a Cool setpoint of
72 degrees Fahrenheit, cooling will energize at a room temperature of 74 degrees.
With a Heat setpoint of 68 degrees Fahrenheit, heating will energize at 66 degrees.
Using the Reset Filter Button
Reset Filter - Press the RST FILTER button to view the current filter
runtime. Press the OUTDOOR button to reset the filter runtime counter
to 0. Press the RST FILTER button again to return to normal operation.
D_TSTATD2200C-2_Manual_HR.pdf 13 8/29/13 1:11 PM
Quick Start
Using the Override Button
Unoccupied Operation - During a Dry Contact forced unoccupied period pressing the
OVERRIDE button will force the thermostat into the mode it was in before the Dry
Contact forced it into the Unoccupied mode. For example: if the thermostat was in the
Auto mode and the Dry Contact forced it into Unoccupied mode, pressing OVERRIDE
will force the thermostat back into the Auto mode. The remaining override time will be
displayed in the upper left corner of the display. Each press of the OVERRIDE button
will add another 30 minutes of time for up to 4 hours. If the maximum time has been
set, the next press of the OVERRIDE button will reset the timer and return the
thermostat to the Unoccupied mode.
NOTE: Override may only be
used when the Dry Contact
has forced the thermostat
into the Unoccupied mode.
PAGE 6
OUTDOOR TEMP - Press the OUTDOOR button to view the current
outdoor temperature. Pressing the OUTDOOR button again to return
to normal operation.
REMOTE TEMP - Press the ACCESSORY button to enter the accessory
setup screen. Press the UP button to view linked wireless and wired
sensors and other accessories. Press the ACCESSORY button to
return to the main screen.
Note: If no outdoor sensor is connected, 2 dashes [- -] will appear with
the first button press.
Viewing and Setting the Indoor Humidity Sensor
Press the HUMIDITY button to display the current humidity measured at
the thermostat. The room relative humidity is displayed in the top left corner.
The humidification setpoint appears in the larger center display and can be
adjusted using the UP or DOWN buttons. Press the MODE button to view and
adjust the dehumidification setpoints. Press the HUMIDITY button again to
confirm settings and return to normal operation.
Note: Due to variations in environmental conditions, it is not always
possible to achieve the desired humidification or dehumidification
setpoint.
IMPORTANT: Allow at least 2 minutes after the thermostat
is powered on for the humidity to read correctly.
Viewing the Outdoor and Remote Temperature Sensors
D_TSTATD2200C-2_Manual_HR.pdf 14 8/29/13 1:11 PM
