Daihan Scientific VM-100 Manuel utilisateur
Man247 (18 Jul. 2017)
VM-100
Mini Vortex Mixer
Certifications by - - -
ISO 9001 Certified.
PL Insurance
User Manual
(Version 2.1.1)
written for
VM-100 model
“VM-100” Mini Vortex Mixer.
Sales & Basic A/S :
DAIHAN
-
Sci.com or
ALL
for
LAB.com
Shopping Mall
DAIHAN-Sci.com or
ALL
for
LAB.com
Shopping Mall
DAIHAN Scientific, VM Mini Vortex Mixer 2/12
Table of Contents
Page
1. Precautions Before Use ………………………………………..…………….……………………3
2. Product Introduction …………………………………………………….…………………………. 4
3. Product Configuration ……………………………………………………………………………… 4
4. Product Installation ………………………..………………………………………….………. 5
5. Precautions when using …………………………………………………………………………… 6
6. Names of Each Part ………………………………………………………………………….. 9
7. Usage Instructions ……………………………………………………………………………. 9
8. Product Specifications …………………………………………………………………………….. 10
9. Maintenance and Management ………………………………………………………... 10
10. Troubleshooting …………………………………………………………………………………… 11
11. Quality Assurance ………………………………………………………………………………. 12
DAIHAN-Sci.com or
ALL
for
LAB.com
Shopping Mall
DAIHAN Scientific, VM Mini Vortex Mixer 3/12
Precautions Before Use 1
Thank you for purchasing Mini Vortex Mixer This manual describes the performance,
usage, and handling precautions of the product you have purchased. Be sure to read
it carefully before using the product. There are warning signs below where user's
attention is required, so read and understand each warning sign and its meaning to
use it safely
Warning
Failure to follow the instructions may result in injury.
Caution
Failure to follow the instructions may result in product failure.
Notification
Do not disassemble or modify the product or use it for purpose other than
its intended function.
Danger of Explosion
If volatile, explosive chemicals are used, there is a danger of explosion.
DAIHAN-Sci.com or
ALL
for
LAB.com
Shopping Mall
DAIHAN Scientific, VM Mini Vortex Mixer 4/12
Product Introduction 2
Mini Vortex Mixer can be conveniently used for various fields (fields of chemistry, life science,
medical science, pharmacology etc.).
The advantages of Mini Vortex Mixer are as follows:
nAchieved robust design and very stable grounding force
nRealized strong power, stable operation and low noise (Up to 3,200 rpm).
nMaximized the space efficiency of the workbench with the minimum size
nEnabled various speed controls and applied the automatic push start
function
nUp to 50ml tube available
nIn the event of an accident, this product may be compensated by products
liability insurance (PL insurance). (100 million won for person and object,
respectively)
Product Configuration 3
VM-100, Mini Vortex Mixer ......................................................................................... [ 1 ]
Power Adapter .......................................................................................................... [ 1 ]
Operation Manual ..................................................................................................... [ 1 ]
DAIHAN-Sci.com or
ALL
for
LAB.com
Shopping Mall
DAIHAN Scientific, VM Mini Vortex Mixer 5/12
Product Installation 4
1. This product is manufactured to operate normally at rated voltage.
Check the voltage before installing the product.
2. Install the product on a firm and even floor.
3. Do not install in direct sunlight.
4. If water or organic solvents flow into the part of the controller of the product or
body, it may cause short-circuit, so do not install in such places.
5. Do not install in hazardous places.
6. Be careful not to drop the product when carrying it.
7. Do not lay the product down or shock it. Damage to the inside may occur.
8. Install at a place away from the corner to prevent it from falling off the testing
bench.
9. When installing and using the product, be sure to use the POWER Adapter
provided with the product.
¨Products liability insurance (PL insurance)
Daihan Scientific Co., Ltd. took out a products liability insurance (PL insurance) as
described below so that our customers can trust and use our products in preparation
for accidents that may occur during the use of products produced on our own.
[Contents] ………………………………………………………………………………………
Insurance name: Products Liability Insurance
Issuing agency: Machinery Insurance Cooperative
Compensation limit: 100 million won for person and object, respectively
Security area: Worldwide (Excluding North America)
Emergency contact number: Daihan Scientific Co., Ltd. (TEL : 080-967-5235, FAX : 02-
967-5231)
Machinery Insurance Cooperative (TEL : 02-369-8516, FAX : 02-369-8521)
DAIHAN-Sci.com or
ALL
for
LAB.com
Shopping Mall
DAIHAN Scientific, VM Mini Vortex Mixer 6/12
Safety Instructions 5
Please read following warning for safety and proper use.
Please be familiar with the user manual before using this product, and
operation should be performed only by qualified personnel
Install the product in a place where the floor is hard and flat. Failure to do so
can cause accidents. by negligence.
This product should be connected to a appropriate power source that it is
generally used. Please use a lower power source than the regulation load
permitted.
(AC 120V, 50/60Hz or AC 230V, 50/60Hz, Single phase)
Installing the device (repeated in the Section 6)
WARNING
Place the device on a level, horizontal surface to support the capacity of the
device without vibration. If there is vibration, install the device on a support
material with enough space. Small place may cause the device to drop.
Do not install at a dangerous place.
Do not operate the device where there are flammables. It could be caused
serious accidents like explosion or fire.
Do not operate the device outside.
Avoid areas where the sun shines or rain directly on the device. It is very
dangerous as cause over-heat or a short circuit.
Do not install the device where it can get damp or dust.
It may be caused overheating, a short circuit or a fire by damp or dust inside of
the device.
DAIHAN-Sci.com or
ALL
for
LAB.com
Shopping Mall
DAIHAN Scientific, VM Mini Vortex Mixer 7/12
Do not use this device if the ambient temperature is below 5°C or above 40°C.
Do not use the device at a place with high temperature. Do not operate the
device near a heater, blowing an air-conditioner. It may be caused an accident
by over-heating.
The device should be set at a well ventilated place.
Be sure the holes on the side or rear surface of the body are blocked by a wall
or an object. And do not operate the device at a poor ventilated place or use
closed.
It may cause a fire or damage of the device as not to release heat or
insufficient ventilation may result.
Set the device a lightening place.
When you set the device at a dark place, it may cause an unexpected accident
by mistake in operation.
lWarnings
- Please observe the following precautions
WARNING
Be careful to operate the device.
You should read this manual carefully before using.
The device should only be operated by laboratory personnel especially trained for
this purpose and familiar with all precautionary measures required for working in a
laboratory.
Operate after check the safety of the device.
If there is generated a slight shock or a poisonous gas from a sample, figure it out
and make sure the safety using dustproof or a gas mask.
If unexpected sound, smell or smog is generated, pull out the mains plug and
contact manufacturer or a supplier.
Do not put any objects insides the machine.
When an object that is easy to be combustible is like a stone, a metal or paper
goes insides, it may cause a fire, an electric shock or a break down.
If do, pull out the mains plug from a socket and contact a manufacturer or a
supplier.
DAIHAN-Sci.com or
ALL
for
LAB.com
Shopping Mall
DAIHAN Scientific, VM Mini Vortex Mixer 8/12
Do not disassemble or remodeling by yourself.
It may cause damage to the designed safety.
We do not have any duties for an accident, quality deterioration or a defect
caused by a customer..
All the mechanisms and electric/electronic devices in this machine are designed
and developed by the manufacturer. The devices could be disassembled and
serviced only by the engineers of manufacturer or by engineers approved by
manufacturer.
Do not touch the device with wet hand while operation.
CAUTION
This device must be connected to an earthed power supply.
If you use radiation or contaminated samples, the responsibility is to the customer.
Do not use this product to sterilization or disinfection.
Avoid a sample that is poisonous or flammable.
Never use for a explosive sample.
Please avoid ultraviolet lamps.
It could be cracked or faded.
Disconnect the power supply plug if the unit is not going to be used for an
extended period of time.
※All of the circuits, electrical or mechanical parts and configurations used in this product are
the technical assets of DAIHAN Scientific (Co., Ltd.). Only technicians of the technical support
team at DAIHAN Scientific (Co., Ltd.) or technicians approved through the education from
DAIHAN Scientific should be allowed to repair this product.
DAIHAN-Sci.com or
ALL
for
LAB.com
Shopping Mall
DAIHAN Scientific, VM Mini Vortex Mixer 9/12
Names of Each Part 6
Usage Instructions 7
1. Preparation for use
lConnect the power to the socket with the proper voltage appropriate for the standard.
lPlace it on a flat and stable place.
2. How to operate
Mixing head
Speed control knob
1. Insert the test tube into the mixing holder
and press it to start mixing.
2. Adjust the proper speed via the speed
control knob (Clockwise switching -
acceleration)
3. Lift the test tube to stop mixing
push
DAIHAN-Sci.com or
ALL
for
LAB.com
Shopping Mall
DAIHAN Scientific, VM Mini Vortex Mixer 10/12
Product Specifications 8
Technical Information
Models
VM
-
100
Tube Capacity
U
p
to 50
ml
Platform Dimension
w300×d115 mm
Speed
3,200
rpm
Overall Dimension &
Weight(N.W./G.W.) W55×d173×h81 mm, 0.77 / 0.9 kg
Power Supply
AC 220V 50/60Hz
Maintenance and Management 9
1. If not used for a long time, unplug the power plug, dry it, and wrap it for storage.
2. If parts need to be replaced due to failure during use, you should use only
genuine parts provided by us.
3. Failure due to usage beyond normal limits cannot be maintained
4. When cleaning the product, unplug the power plug and wipe it with a soft towel.
In case of a non-erasable part, wipe only dirt with a towel soaked in a solvent
with low freezing point.
