Daewoo DWD-L1021 Manuel utilisateur
Service Manual
Drum Washing Machine
Model: DWD-L1021
Oct. 2009
✔ Caution
: In this Manual, some parts can be changed for improving, their
performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in
Service Information Center (http://svc.dwe.co.kr).
S/M No. :
3
3
2. WASHER SpECIfICATIoN
1. Product Specification
■1st Model ■2st Model
MODEL DWC-LU1011/1211 DWD-LU1011/1211 DWC-LD1411/1611 DWD-LD1411/1611
Dimension (mm) 600 X 645 X 850
Maximum mass of textile (kg) 9 Kg
Unit Weight (net/gross) 78/82 71/75 76/80 69/73
Standard Water Consumption 65 ℓ
Spin Speed (RPM) DWC(DWD)-LU10XX : MAX 1000
DWC(DWD)-LU12XX : MAX 1200
DWC(DWD)-LD14XX : MAX 1400
DWC(DWD)-LD16XX : MAX 1600
Operating Water Pressure 0.03MPa ~ 0.8MPa (0.3kgf/cm2~ 8kgf/cm2)
6
2. pANEl f AS
A01
A02
A03
A04
A09
A10
A11
A12
A13
A07
A06
A14
A18 A17 A16 A15
A08
A05
■ 2st Model
7
No. PARTS NAME CODE SPECIFICATIONS Q’TY REMARK
A00 pANEl fRoNT AS 361------- D-LU1221 1
A01 pANEl fRoNT AS 36142T2100 AbS 24x16 SUS 430
A02 bUTToN fUNCTIoN 3616644400 AbS 1
A03 bUTToN opTIoN 3616644700 AbS 1
A04 HolDER lED fUNCTIoN 3613058500 HIpS 1
A05 pCb f AS PRPSSW- - - - D-LU1221 1
A06 HolDER lED DISplAy 3613058600 AbS 1
A07 CASE pCb f 36111T1R00 HIpS 1
A08 SCREW TAppING 7122401611 T2S TRS 14x16 MfZN
A09 pCb boARD f 3614348500 FR-1 1
A10 HolDER lED CoURSE 3613058400 HIpS 1
A11 bUTToN DIAl 3616644300 AbS 1
A12 DECoRAToR bUTToN DIAl 3611696400 AbS 1CHRoMIUM CIlDING
A13 bUTToN START 3616644600 AbS 1
A14 bUTToN poWER 3616644500 AbS 1
A15 DECoRAToR fIlM 36116- - - - - p.C fIlM 1
A16 WINDoW CoURSE 3615509400 TR-ABS 1
A17 SCREW TAppING 7122401608 T2S TRS 1
A18 CASE DETERGENT AS 36111- - - - - D-LU1221 1
NO DISPONIBLE
8
B01
B02
B03
B05
B04
B08
B07
B06
B10
B09
B11
B12
B13
B14
3. INlET boX AS
9
No. PARTS NAME CODE SPECIFICATIONS Q’TY REMARK
b01 NoZZlE *T 3618111100 pp 1
b02 NoZZlE *U 3618111000 pp 1
b03 boX INlET 3610526500 pp 1
b04 HoSE INlET 3613274600 EpDM 1
b05 ClAMp AS 3611203200 ID=60, WIRE+GUIDE+bolT+NUT 1
b06 VAlVE INlET 3615416821 220-240V.VDE.BITRON. 1
b07 HoSE WATER SUpply 3613270900 EpDM ID9.5 oD14.5, WASHING 1
b08 HoSE WATER SUpply 3613270900 EpDM ID9.5 oD14.5, pRE.WASH 2
b09 ClAMp HoSE 3611205800 100H, ID=13.8 W=10.0 0.9T 10
b10 VAlVE INlET 3615414820 220-240V,1-WAY HOT PP 1
b11 HoSE WATER SUpply 3613270900 EpDM ID9.5 oD14.5, HoT 1
b12 HoSE WATER SUpply 3613270900 EpDM ID9.5 oD14.5, STEAM 1
b13 pIpE JoINT I 3614426000 pp 1
b14 Unit Steam AS 36189M2U00 L-SERIES STEAM UNIT 900W 1option
10
4. CAbINET f ASSy
C12
C01
C02
C03
C14
C15
C06
C07
C04
C05
C11
C08
C09
C10
C13
■ 1st Model
11
No. PARTS NAME CODE SPECIFICATIONS Q’TY REMARK
C01 CAbINET *f 3610814000 SECD 0.8T 1
C02 SWITCH DooR loCK 3619047200 DL-S1.250V16A.BITRON 1
C03 plATE HINGE SUppoRT 3614539800 SPG 0.8T, DWD-T110R 1
C04 fRAME DooR *o 36122UD800 AbS 1
C05 pRoTECToR GlASS 3618345500 AbS 1
C06 DECoRAToR DooR *o 3611695900 AbS 1
C07 HooK DooR 3613100900 ZNDC 1
C08 SpRING HooK 3615115400 SUS304, 1
C09 HooK SHAfT 3613101000 SUS, D=3.0 1
C10 fRAME DooR *I 36122UD600 pp 1
C11 HINGE DooR 3612903800 AL, DWD-T110R 1
C12 CAp HINGE DooR 3610916500 poM 4
C13 DooR GlASS 361A113300 GlASS 1
C14 CASE pUMp 36111T1K00 pp 1
C15 CoVER pUMp 3611431500 AbS 1
12
5. DooR AS
C11
C01
C02
C03
C12
C10
C09
C04
C07
C05
C06
C08
■ 2st Model
13
No. PARTS NAME CODE SPECIFICATIONS Q’TY REMARK
C00 DooR AS 361------- 1
C01 fRAME DooR 0 36122UDC00 AbS 1
C02 pRoTECToR GlASS 3618345600 TR-ABS 1
C03 DooR GlASS 361A113300 GlASS 1
C04 fRAME DooR 1 36122UDD00 pp 1
C05 HINGE DooR 3612903800 AlDC 1
C06 CAp HINGE DooR 3610916500 poM 4
C07 SCREW TAppING 7115402029 T1S flT 14 4*20 STS430 NATURE
C08 HooK DooR 3613100900 ZNDC 1
C09 SpRING HooK 3615115400 SUS 1
C10 KooK SHAfT 36131101000 SUS 1
C11 CASE SpRING DooR 3611149300 AbS 1
C12 SCREW TAppING 7122401611 T2STRS 24*6 MfZN
