Daewoo DWF-1089 Manuel utilisateur

Service Guide

Auto Washer

Model: DWF-7589/8089 Serise

SN SGWF7589001 FEB. 2000

1. SPECIFICATIONS

SPECIFICATIONS

NO.ITEM DWF-1089 DWF-9289 DWF-8089 DWF-7589

1POWER SOURCE AVAILABLE IN ALL LOCAL AC VOLTAGE AND CYCLE

POWER CONSUMPTION

MACHINE NON-PUMP

WEIGHT PUMP

4DIMENSION (WXHXD) 628 X 1005 X 673mm 610 X 962 X 655mm

5WASHING COURSE FULL AUTOMATIC 8 COURSE

(FUZZY, MEMORY, DRY, SILK, ECONOMICAL, STRONG, NIGHT, BLANKET)

WATER CONSUMPTION

WATER LEVEL SELECTOR

OPERATING WATER PRESSURE

0.3kgf/cm2~8kgf/cm2 (2.94 N/cm2~78.4N/cm2)

60Hz WASH : 145~160, SPIN : 750~800

950Hz WASH : 130~145, SPIN : 700~750

WASH : 70 (60Hz), 60 (50Hz)

10 PULSATOR 6 WINGS (Ø396mm) 6 WINGS (Ø376mm)

WATER LAVEL CONTROL

ELECTRONICAL SENSOR

12 ANTI NOISE PLATE OOOO

GEAR MECHANISM ASS’Y

HELICAL GEAR FOR LOW NOISE

14 LINT FILTER OOOO

15 SOFTENER INLET OOOO

FUNCTION FOR SOAK WASH

OOOO

17 ALARM SIGNAL OOOO

RESIDUAL TIME DISPLAY

OOOO

AUTO. WATER SUPPLY

OOOO

20 NEW WATER FLOW WATER FLOW FOR ADJUST THE UNBALANCED LOAD

21 ECONOMIC COURSE OOOO

FUNCTION FOR BUBBLE

OOOO

AUTO RE-FEED WATER

OOOO

24 AUTO POWER OFF OOOO

50Hz

430W

60Hz

480W

50Hz

430W

60Hz

480W

50Hz

400W

60Hz

460W

50Hz

400W

60Hz

460W

55Kg (GROSS : 64Kg)

56Kg (GROSS : 65Kg)

54Kg (GROSS : 63Kg)

55Kg (GROSS : 64Kg)

50Kg (GROSS : 60Kg)

51Kg (GROSS : 61Kg)

49Kg (GROSS : 59Kg)

50Kg (GROSS : 60Kg)

NORMAL 315L

HIGH(96L), MID(81L)

LOW(65L), SMALL(49L)

E.SMALL(36L)

NORMAL 304L

HIGH(93L), MID(78L)

LOW(61L), SMALL(48L)

E.SMALL(33L)

NORMAL 265L

HIGH(82L), MID(70L)

LOW(57L), SMALL(43L)

E.SMALL(31.5L)

NORMAL 259L

HIGH(80L), MID(68L)

LOW(55L), SMALL(42L)

E.SMALL(30.5L)

SILK, DRY

COURSE

REVOLUTION

PER MINUTE

PARTS DIAGRAM

2. Parts Diagram

A10

PARTS DIAGRAM

B20

B19

B18

B17

B15 B16

B21

B22

B23

B24

PARTS DIAGRAM

C32

PARTS DIAGRAM

3. Parts List

3-1. DWF-7589, DWF-8089

NO PART CODE PARTS NAME EA DESCRIPTION REMARK

A01 3611611400 DECORATOR PANEL F 1PC FILM 0.188T

A02 3614215520PANEL F 1ABS 7589,8089,8059

PRPSSWN500 DWF-1089 NON-PUMP

A03 PRPSSWN800 P.C.B ASS'Y 1DWF-1089CTE NON-PUMP

PRPSSWN900 DWF-1089PT PUMP

A04 3614504210 PLATE T 1ABS , NON METALLIC

A05 3610906700 CAP 2ABS

A06 3616001200 SPECIAL BOLT2T1 TRS 5x73

3618902101 AC 110-130V/60Hz

A07 3618919400 BUBBLE PUMP ASS'Y1AC 220-240V/50Hz,60Hz

A08 3614202000 PANEL B 1ABS

A09 3610902600 CAP REAR 2CR

A10 3611105400 CASE DETERGENT 1ABS

A113612300110 GASKET VALVE 2PVC-S (IN-LET) l

5EP1048010 T5-V1 (AC 110-130V)

A12 5EP1048020 TRANS POWER 1T5-V1F(AC 110-130V) FUSE

5EP1048030 T5-V2 (AC 220-240V)

5EP1048040 T5-V2F(AC 220-240V) FUSE

A13 3615103510SPRING 1DWF-8089, D=2.0 RIGHT

A14 3612900400 HINGE LEFT 1POLYACETAL

A15 3612900300 HINGE RIGHT 1POLYACETAL

A16 3615103610SPRING 1DWF-8089, D=2.0 LEFT

A17 3619007800 SWITCH DOOR AS 1DWDS-01

A18 3610400800 BASE DETERGENT 1PP

3610400820 PP SINGLE VALVE

A19 3619006720 SWITCH SAFETY 1DC 15V 050 K

A20 3611404601 COVER R 1ABS RIGHT

A21 3610903010CAP DOOR AS 240 'S

A22 3614801120 SENSOR PRESSURE 1D10T, TERMINAL

A23 3611715100DOOR F 1ABS

A24 3611715200DOOR B 1ABS

A25 3612603010 HANDLE DOOR 1 ABS

NO PART CODE PARTS NAME EA DESCRIPTION REMARK

A26 3611521700 CUSHION DOOR 4CR

A27 3611405101 COVER L 1ABS LEFT

A28 7121401608 SCREW 8T2S PAN 4x16 SUS

3612725100 NON-PUMP

A29 3612725110 HARNESS ASS¡ﬂY1PUMP

3612725120 NON-PUMP, SINGLE VALVE

3615403510 AC 110-130V/60Hz

A30 3615403711VALVE INLET COLD 1AC 220-240V/50Hz

3615402010 AC 220V/60Hz

3615403630 AC 110-130V/60Hz

A31 3615403831VALVE INLET HOT 1AC 220-240V/50Hz

3615402130 AC 220V/60Hz

A32 7121301208 SCREW 2T2S TRS 3x12 SUS

B01 3612200100 FRAME T 1PP

B02 3610805600 CABINET AS 1PAINTING

B03 3610303130 BASE U 1PP NON-PUMP

3610303110 PP PUMP

B04 ----

B05 3617702100 LEG ADJUST 2PP

B06 3612100300 FOOT 2PP

B07 4509D10020 FOOT 2RUBBER BUTYL

B08 ----

3610076130 54.0¥F+60¥H, L=470 110V

B09 3610076230 ASSY CONDENSER 141.6¥F+60¥H, L=470 127V

3610032630 13.5¥F+60¥H, L=470 220V

3610031930 12.5¥F+60¥H, L=470 240V

B10 3612600700 HANDLE CABINET 2PE-HD

B113610068700 ASSY EARTH 150/0.18 GREEN ST710480-2

B12 ----

B13 3611402800 COVER BACK 1PP

B14 3614504300 PLATE UPPER 1PP

B15 3613214200 HOSE DRAIN O AS 1L=1000 NON-PUMP

3613203101 HOSE AS 1DWF-5230PN PUMP

B16 3612502300 GUIDE DRAIN HOSE 1PP PUMP

B17 3611201000 CLAMP 1HSW3,D2.6,MFZN,D36 NON-PUMP

PARTS DIAGRAM

NO PART CODE PARTS NAME EA DESCRIPTION REMARK

3611200200 CLAMP B 1SW D2.6 ZN8-C PUMP

B18 3618703700 TERMINAL PUMP 1250V/1A PUMP

3618703720 125V/3.15A PUMP

B19 3611405320 COVER PUMP 1PP PUMP

B20 7122501611SCREW TAPPING 3T2 TRS 5x16 MFZN PUMP

3963220330 AC 110V/60Hz PUMP

B21 3963821530 MOTOR SHADED POLE 1AC 120V/60Hz PUMP

3963322730 AC 220V/60Hz PUMP

3963513430 AC 220-240V/50Hz PUMP

B22 3611901530 FILTER AS 1DWF-5590DPNF, E-TYPE PUMP

3618912600 AC 250V/4A, FERRITE

B23 3618912630 UNIT FUSE FILTER 1AC 250V/5A, FERRITE TUV

3618912610 AC 250V/8A, FERRITE

3611301300 3x0.75, 300x2, 300-RTML ITALIAN 3PIN

4508B81001 3x0.75, 300x2, 300-RTML CP-2PIN

B24 450E181000 POWER CORD AS 13x0.75, 300x2, 300-RTML 3-WIRE

WAK42H762- A VCTFK 2x0.75, 2.3M FLAT 2PIN

450KA81003 3x0.75, 300x2, 300-RTML EUROPE-2PIN

C01 3618101400 NOZZLE BODY 1PP

C02 3611408500 COVER TUB O 1PP

C03 3619802800 SUSPENSION AS(A) 2DWF-8094

C04 3619802900 SUSPENSION AS(B) 2DWF-8094

C05 3618802620 TUB O 1PP NON-PUMP

3618802630 PP PUMP

C06 3613208900 HOSE OVERFLOW 1PE-LD NON-PUMP

C07 3615404000 VALVE DRAIN AS 1DWF-5590D, VE NON-PUMP

450ED45020 AC 110-130V/60Hz NON-PUMP

3966320210 AC 220V/60Hz NON-PUMP

C08 3966010120 MOTOR SYNCHRONOUS 1AC 220-240V/50Hz NON-PUMP

450ED45040 AC 110-130V/60Hz PUMP

3966320240 AC 220V/60Hz PUMP

3966010140 AC 220-240V/50Hz PUMP

C09 3610303000 BASE 1SECEN 2.0Tx410x385

C10 4500D08180 CLAMP 1SWC

C114500D08170 HOSE 0.62 ID=8.0, OD=12.0

PARTS DIAGRAM

NO PART CODE PARTS NAME EA DESCRIPTION REMARK

C12 3611502800 CUSHION DOWN 2POM H=18mm

3964220400 AC 110V/60Hz F34-C

3964820510 AC 127V/60Hz F36-C

C13 3610019700 MOTOR CONDENSER 1AC 220/60Hz F3A-C

3964310510 AC 220V/50Hz F32-1C

3964610310 AC 240V/50Hz F33-1C

C14 3611502000 CUSHION UPPER 2POM

C15 3618401400 PULLEY MOTOR AS 1ADC-12, DS=10, DP=48.5 60Hz

3618401420 ADC-12, DS=10, DP=53.0 50Hz

C16 3613218500 HOSE DRAIN AS 1PE-LD/EVA, L=219.5 NON-PUMP

3613212100 HOSE DRAIN I 1PE-LD/EVA, L=184 PUMP

C17 3617307410 GEAR MECHAISM 1GM-1300-KJ4P0

C18 3618300100 PLATE GEAR PROTECTOR 1SBHG 1.6T

C19 ----

C20 4507D34020 BELT V 1M20 50Hz, 60Hz

C21 3610906200 CAP PULSATOR 1PP

C22 4505E3203A SC PULSATOR FIX AS 16x26.5 O-RING+SILOCK

C23 3610906400 CAP 1PP

C24 3610085500 ASS¡ﬂY FILTER 1PP(NYLON 74x130)

C25 3619702910PULSATOR AS 1PULSATOR+INSERT

C26 4509G83081 NUT-SPIN SHAFT 1ZDC2 CU, NI COATING

C27 4509L83070 SPECIAL WASHER 1SUS304 T2.0 PI44

C28 3610009900 BALANCER AS 1DWF-7590R DWF-7589series

3616101600 DWF-8080R2 DWF-8089series

C29 3618800301 TUB INNER 1PP DWF-7589series

3618801700 TUB YUS 430D DWF-8089series

C30 3618802000 TUB U 1PP DWF-8089series

C31 3617200600 FLANGE TUB 1ALDC 12 VE1

C32 3612500100 GUIDE FILTER 1PP(JI-360) DWF-7589serise

3612502200 GUIDE FILTER AS DWF-8080R2 DWF-8089series
