Drum Washing Machine
Model: DWD-L100 Series
vUGYWW`
GGGGGGfGj
a pGGtSGGGGGGGSGG
GGGGGGUGzSGGGGG
GGSGGGGwwsOwGwGsPGG
zGpGjGOaVVUUUPU
zVtGuUGaGk~kskX[WWXG
DRUM WASHING MACHINE
SERVICE MANUAL
1. WHAT IS DRUM WASHING MACHINE?......................................1
2. WASHER SPECIFICATION ..........................................................2
3. PARTS LIST BY ASS'Y.................................................................4
4. CONTROL PART FUNCTION SPECIFICATION ........................23
5. ELECTRONIC FIELD PARTS LIST AND SPECIFICATION .......38
6. WIRING DIAGRAM .....................................................................39
1
Water consumption is reduced by using the power of the laundry falling (free-fall) created when rotating
the drum. With temperature control system, this drum washing machine saves energy and improves
washing performance at the same time.
1. WHAT IS DRUM WASHING MACHINE?
1. Drum Washing Machine
俕Waist Care
Designed by the waist, and the most comfortable
angle eject into the laundry is convenient and easy to
manipulate.
䯥Star Drum
Using Star Drum is able to show users higher
Washing Performance and Minimal damage of
laundry, water consumption.
䯥Luxury Audio Dial
Using the advanced Audio Dial is luxury design of
exterior.
俕DD inverter motor
The direct-drive type of which motor is directly
connected to drum without an interim clutch,
significantly reduces noise and vibration.
俕Self-Cleaning Course of Drum.
Enables the machine to do Self-Cleaning of Drum.
俕Digital Condensing Dry System.
Condensing Dry System with saveing energy.
2. Key Features
2
Ŗ&&%QPVTQN&KTGEVFTKXGV[RGQHFKTGEVEQPPGEVKQPDGVYGGPFTWOCPFOQVQT
Ŗ4QVCVKQPD[RQYGTHWNJKIJRGTHQTOCPEG$.&%OQVQT
2QYGT5[UVGO
Sxps#Gudlqdjh EOGF
ODXQGU\
33
2. WASHER SPECIFICATION
2TQFWEV5RGEKHKECVKQP
O1st Model O2st Model
MODEL DWC-LU1011/1211 DWD-LU1011/1211 DWC-LD1411/1611 DWD-LD1411/1611
Dimension (mm) 600 X 645 X 850
Maximum mass of textile (kg) 9 Kg
Unit Weight (net/gross) 78/82 71/75 76/80 69/73
Standard Water Consumption Ɛ
Spin Speed (RPM) DWC(DWD)-LU10XX : MAX 1000
DWC(DWD)-LU12XX : MAX 1200
DWC(DWD)-LD14XX : MAX 1400
DWC(DWD)-LD16XX : MAX 1600
Operating Water Pressure 0.03MPa ~ 0.8MPa (0.3kgf/cm2~ 8kgf/cm2)
4
1. PANEL AS
3. PARTS LIST BY ASS'Y
A03
A02
A22
A21
A19
A20
A15
A14
A11
A09
A16
A18
A17
A01
A04
A05
A06
A07
A08
A10
A12
A13
OUV/QFGN
5
No. PARTS NAME CODE SPECIFICATIONS Q’TY REMARK
A01 PANEL *F 36142T2000 ABS 1
A02 DECORATOR WINDOW COURSE 3611696000 ABS 1
A03 WINDOW COURSE 3615509200 %.7 1
A04 DECORATOR WINDOW DISPLAY 3611696100 ABS 1
A05 BUTTON FUNCTION 3616644000 ABS 1
A06 BUTTON PS 3616644100 ABS 1
A07 WINDOW DISPLAY 3615509300 %.7 1
A08 BUTTON LED 3616644200 %.7 1
A09 PCB BOARD 3614347000 L SERIES FRONT PCB BOARD 1
A10 CUSTOM LED 3613058300 %.7 1
A11 LED LAMP &592 9MM FORMING TYPE , D=3MM 36
A12 SW TACT 5S50101402 2PIN, 6*6*5 9
A13 HOLDER LED OPTION 3613058000 HIPS 1
A14 HOLDER LED FUNCTION 3613058100 HIPS 1
A15 HOLDER LED COURSE 3613058200 HIPS 1
A16 CASE PCB F 36111T1N00 HIPS 1
A17 BUTTON DIAL OUTER 3616643800 ABS 1
A18 BUTTON DIAL INNER 3616643900 ABS 1
A19 CASE DETERGENT 36111T1J00 PP 1
A20 CAP SOFTENER 3610916600 PP 1
A21 CASE HANDLE 3611149200 ABS 1
A22 DECORATOR CASE HANDLE 3611696200 ABS 1
6
2. PANEL F AS
A01
A02
A03
A04
A09
A10
A11
A12
A13
A07
A06
A14
A18 A17 A16 A15
A08
A05
OUV/QFGN
7
No. PARTS NAME CODE SPECIFICATIONS Q’TY REMARK
A01 PANEL FRONT 36142T2100 ABS 2 4x16 SUS 430
A02 BUTTON FUNCTION 3616644400 ABS 1
A03 BUTTON OPTION 3616644700 ABS 1
A04 HOLDER LED FUNCTION 3613058500 HIPS 1
A05 PCB F AS PRPSSWL050 LD10/LU10,STANDBY 1W 1
PCB F AS PRPSSWL051 LD12/LU12,STANDBY 1W 1
PCB F AS PRPSSWL052 LD14,STANDBY 1W 1
PCB F AS PRPSSWL053 LD16,STANDBY 1W 1
PCB F AS PRPSSWL060 LD10/LU10,EC 1
PCB F AS PRPSSWL061 LD12/LU12,EC 1
PCB F AS PRPSSWL062 LD14,EC 1
PCB F AS PRPSSWL063 LD16,EC 1
A06 HOLDER LED DISPLAY 3613058600 ABS 1
A07 CASE PCB F 36111T1R00 HIPS 1
A08 SCREW TAPPING 7122401611 T2S TRS 1 4x16 MFZN
A09 PCB BOARD F 3614348500 (4 1
A10 HOLDER LED COURSE 3613058400 HIPS 1
A11 BUTTON DIAL 3616644300 ABS 1
A12 DECORATOR BUTTON DIAL 3611696400 ABS 1 CHROMIUM CILDING
A13 BUTTON START 3616644600 ABS 1
A14 BUTTON POWER 3616644500 ABS 1
A15 DECORATOR FILM 3611696500 P.C FILM 1
A16 WINDOW COURSE 3615509400 64#$5 1
A17 SCREW TAPPING 7122401608 T2S TRS 1
A18 CASE DETERGENT AS 36111T1P10 PP 1
8
B01
B02
B03
B05
B04
B08
B07
B06
B10
B09
B11
B12
B13
B14
3. INLET BOX AS
