DAEWOO SECURITY Alarm system accessories
QUICK INSTALLATION GUIDE
EN /
WIRELESS KEYPAD
WKE301
PRODUCT DESCRIPTION
This product is a wireless touch keypad that arms and
disarms your security system with a passcode or RFID
tag. It is connected to your alarm hub via the eV1527
protocol, with an effective communication range of up
to 80 meters without obstacles. The internal lithium-ion
rechargeable battery provides power operation up to 3
months.
SPECIFICATION
• Power supply : Micro USB+5VDC/1000mA
• Backup Battery: 3.7V, 500mAh Lithium-ion Battery
• Consumption: <15uA@sleep and <15mA@ready
• Radio Frequency: 433Mhz
• RFID Chip: 4100/4200
• RFID Frequency: 125KHz
• Operation Temperature: -10~55°C
IN THE BOX
• Keypad x1
• Mounting Screws x2
• User Guide x1
• USB Cable x1
• RFID tag x2
AT A GLANDE
X
12 3
45 6
7 8
6
X
0
ON OFF
1
2
12
345
6
7
8
9
10 11
13 14
1. RFID tag reader zone
2. Power / Ready indicator
3. Away / Home arming indicator
4. Disarming indicator
5. Setting indicator
6. Away arming button
7. Dismarming button
8. Home arming button
9. Doorbell button
10. Clear / Return button
11. Check / Set / Continue button
12. Tamper Switch
13. Battery on / off switch
14. Power / Charging port
15
16
15. Bracket
16. Back cover
POWER / READY INDICATOR
What you see What it means
Blinking red
Flashing red once per 2s
Solid red
Breathing green
Solid green
Battery failure of battery
switch is off
Low battery
Ready
Charging
Charged fully
CHARGING THE BATTERY
Push the battery switch to on. Connect your keypad to a
power outlet using the included cable and USB power
adapter.
It takes two to three hours to charge the keypad battery
fully from an empty state. The power indicator turning
from breathing green to solid green means that the
battery is fully charged.
If the keypad is low battery, the power indicator may
flash red once per 2 seconds, indicating that it needs
to charge.
INSTALLATION OF YOUR KEYPAD
After having correctly installed your AM301 central to
your Daewoo Home Connect control app, you can add
your wireless keypad WKE301.
1. Click on "add an accessory + " from the page of your
AM301 central.
2. Select the “Keypad” tab.
3. Turn on your WKE301 keypad.
4. Enter the user code (1234) then press the
Arm icon.
5. Install your keyboard in your home :
- Secure the bracket to the surface with the screws
provided.
- Insert the keyboard into the bracket.
It is not recommended to mount the keypad on metal
surfaces as the material may block RF signals between
the keypad and the control panel.
ABOUT KEYPAD
• Sleep / Wake mode
• User and Admin Passcode
To save the battery power, the keypad goes to sleep
without operation within 20 seconds.
Touch any button to wake the keypad.
The keypad has two 4-digit passcodes.
The user passcode is used to arm, home arm and
disarm your security system, the admin passcode
can be used to pair, delete RFID tags and change
passcodes.
The default user passcode is “1234” and
admin passcode is “8888”.
PROGRAMMING
• Basic programming steps
STEP 1 - Enter admin passcode then √, the setting
indicator lighting on means that programming mode
is ready.
STEP 2 - Input number to select functions:
Pair RFID Tag
Delete RFID Tag
Delete All RFID Tags
Set User Passcode
Set Admin Passcode
then √, the setting indicator blinks.
1
2
3
0
9
STEP 3 - Enter setting then √, the buzzer beeps twice.
LAST STEP - Press then √ to exit programming.
PAIRING RFID TAG
X
12 3
45 6
7 8
6
X
0
The RFID tags supplied
with this kit are paired
with keypad. IF NOT or
you want to pair more,
you might easily pair the
tag with your keypad as
following.
STEP 1 - Enter admin passcode ( 8888 default ) then √.
STEP 2 - Press 1 then √.
STEP 3 - Enter a digit from 0 to 9 to designate
a unique number for the tag to be paired, then √, the
arming, disarming and setting indicators blinks together.
STEP 4 - Tap the tag on the read zone, the keypad
gives two beeps of successful indication.
Tips : up to 10 RFID tags
can be added.
TEST : Press then swipe your RFID tag on the keypad
to arm the system
DELETING RFID TAG
STEP 1 - Enter admin passcode then √.
STEP 2 - Press 2 then √.
STEP 3 - Enter the tag number from 0 to 9 to be deleted,
then √.
DELETING ALL RFID TAGS
STEP 1 - Enter admin passcode then √.
STEP 2 - Press 3 then √ to delete all RFID tags.
SETTING USER PASSCODE
STEP 1 - Enter admin passcode then √.
STEP 2 - Press 0 then √.
STEP 3 - Enter the new 4-digit user passcode, then √.
SETTING ADMIN PASSCODE
STEP 1 - Enter admin passcode then √.
STEP 2 - Press 9 then √.
STEP 3 - Enter the new 4-digit user passcode, then √.
The default user password is "1234".
The administrator password is "8888".
DOORBELL
STEP 1 - Set your hub into pairing/sniffer mode.
STEP 2 - Enter user passcode then press to send
arming transmission signal to bub.
STEP 3 - The hub gives the successful indication.
The doorbell identification number in transmission code
to the hub is different from the arming/disarming id
number, so It is necessary to pair doorbell code with
your hub before using doorbell. Do like the followings:
Fix the bracket to the surface with included screws.
Insert the keypad into the bracket.
Now the doorbell function can be used.
The default user password is "1234".
The administrator password is "8888".
Enter user passcode then press to disarm.
X
ARMING / DISARMING YOUR SYSTEM
• Using User Passcode
Enter user passcode then press to away arm.
Enter user passcode then press to home arm.
• Using RFID Tag
Press then tap the RFID tag to away arm.
Press then tap the RFID tag to disarm.
Press then tap the RFID tag to home arm.
X
RESET
This process resets your keypad to factory settings
and removes all RFID tags.
Press and release tamper switch found underneath
the bracket ten times, then all indicators are on, then
the keypad restarts.
