DAELIM HISTORY Manuel utilisateur

OM44-0110-01E

OWNER'S MANUAL

󳥎󳥎HEAD OFFICE (FACTORY)

#58, SUNG SAN-DONG, CHANG WON, KYUNGNAM, KOREA

TEL : (82-55) 239-7000 FAX : (82-55) 239-7524

SPECIFICATION ································ 3

OPERATION INSTRUCTION ··················· 4

SAFETY PRECAUTIONS ······················ 4

PRIOR TO STARTING VEHICLE ················· 5

OPERATION ································· 5

CORRECT ATTIRE···························· 6

CARGO ····································· 6

MODIFICATION ······························ 7

ATTACHMENT ······························· 7

MUFFLER ··································· 7

PARTS LOCATION···························· 8

METER READING AND USAGE ···············10

METER ·····································10

INDICATOR LAMPS ···························10

SWITCH OPERATION ·························11

MAIN SWITCH ·······························11

STARTER BUTTON ···························12

HEADLIGHT ·································12

WINKER SWITCH·····························13

HORN BUTTON ······························13

HAZARD SWITCH ····························13

EQUIPMENT USAGE ··························14

STEERING LOCK ·····························14

SEAT LOCK ·································14

PARKING BRAKE ·····························15

TRUNK ·····································15

DOCUMENT STORAGE AREA ··················16

INNER BOX··································16

HANDPHONE CHARGER·······················17

BAG HOLDER································17

CORRECT DRIVING OPERATION ·············18

STARTING THE ENGINE ·······················18

IF ENGINE CANNOT BE STARTED···············20

AFTER STARTING ENGINE·····················21

PROPER DRIVING METHODS ··················22

STOPPING ··································23

SELF INSPECTIONS BEFORE OPERATION ···25

INSPECTION OF CONCERNED AREA ············26

BRAKE INSPECTION ··························26

FUEL CHECK ································27

TIRE INSPECTION ····························28

ENGINE OIL LEVEL CHECK ····················29

LIGHTS AND WINKER INSPECTION··············29

BACK MIRROR INSPECTION ···················30

FUEL LEAK INSPECTION ······················30

CONTENTS

**SL-125OWNERS(1~49) 02.11.5 4:21 PM 페이지1

LICENSE PLATE INSPECTION ··················30

MAINTENANCE ·······························30

MAINTENANCE SCHEDULE ····················31

MAINTENANCE PRECAUTIONS ·················33

BRAKES ····································33

BRAKE HOSE, PIPE LEAKAGE, DAMAGE, ASSEMBLY STATE

·35

BRAKE PAD WEAR ···························35

PARKING BRAKE ADJUSTMENT ················36

PARKING BRAKE SHOE INSPECTION ············36

CHANGING ENGINE OIL ·······················37

TRANSMISSION OIL INSPECTION ···············38

WHEEL REMOVAL ····························39

SPARK PLUG ································41

BATTERY INSPECTION ························42

FUSE REPLACEMENT ·························43

BULB REPLACEMENT ·························44

AIR CLEANER ELEMENT INSPECTION ···········46

SIDE STAND INSPECTION ·····················47

CABLE RUBBER PART INSPECTION ·············47

NOTABLES FOR CAR WASHING ················48

STORAGE GUIDE ····························48

FRAME AND ENGINE NUMBER ···············49

SAFE DRIVING ·································50

PREPARATION BEFORE DRIVING ············50

DRIVING METHOD ····························51

DRIVING POSITION ···························51

PRECAUTION WHEN DRIVING ··················53

STARTING ··································54

TURNING METHOD ···························56

PRINCIPLE OF TURN··························56

EFFECT OF SPEED ···························56

3 POSITIONS OF TURNING·····················57

TURNING METHOD ···························58

PRECAUTION WHEN TURNING ·················59

BRAKING METHOD ···························60

BASIC PRINCIPLE OF BRAKE(FRICTION FORCE) ··60

RESTRAINT OF BRAKE EFFECT (INERTIA) ·······60

BRAKING METHOD ···························61

COMPARISION OF BRAKING DISTANCE··········61

IMPACT WHEN COLLISION·····················61

WIRING DIAGRAM······························62

**SL-125OWNERS(1~49) 02.11.5 4:21 PM 페이지2

LENGTH×WIDTH×HEIGHT(mm)

WHEEL BASE(mm)

GROUND CLEARANCE(mm)

SEAT HEIGHT(mm)

DRY WEIGHT(kgf)

PASSENGER

ENGINE TYPE

PISTON DISPLACEMENT(cc)

BORE AND STROKE(mm)

STARTING SYSTEM

TRANSMISSION TYPE

1,965×690×1,230

1,350

120

780

125

OIL COOLED/AIR COOLED

4 STROKE 4VALVE

124.9

56×50.7

START MOTOR / KICK

V - MATIC

IGNITION SYSTEM

BATTERY CAPACITY

C.D.I

12V8AH(MF TYPE)

120 / 70 - 12 53K

130 / 70 - 12 62K

TELESCOPIC

UNIT SWING OIL DAMPER

HYDRAULIC DISK

CR8EH-9

ITEM DATA ITEM DATA

FR.

RR.

FR.

RR.

FR.

RR.

SPARK PLUG

FUSE(A)

TIRE SIZE

SUSPENSION

BRAKE

SPECIFICATION

FUEL CAPACITY(ℓ)

RESERVE FUEL CAPACITY(ℓ)

8.0

1.7

**SL-125OWNERS(1~49) 02.11.5 4:21 PM 페이지3

This manual describes matters pertaining to correct operation,

safe operation and simple maintenance of the vehicle you

purchased.

To ensure more comfortable and safer operation, make sure to

read this manual carefully prior to operation.

●The photographs and drawings shown in this manual may

differ from those of actual vehicles due to changes in vehicle

specifications and modifications made.

●This vehicle is designed for 2 riders including the operator.

CAUTION

●Do not use polluted gasoline.

Using polluted gasoline will cause rust inside the fuel

tank, and will close the supply of fuel to the carburetor,

leading to an improper engine starting or may cause

serious damage to an engine.

●Do not use polluted or low-grade oil.

Always use genuine oil to protect and extend vehicle

performance and its life span.

●If any failure occurs due to the use of polluted gasoline

or oil, such failure will be excluded from being eligible

for repairs under the warranty.

●Careful driving and the wearing of proper attire and safety

equipment are the most important factors in the safe

operation of the scooter. Please obey traffic regulations and

do not be hurried and careless.

●Many new vehicle owners operate their newly purchased

vehicles with great care and attention to safety factors.

However, after becoming accustomed to the operations are

often discarded, which can lead to accidents. Please don't let

this happen to you and always approach the operation of your

vehicle with the safety considerations needed.

When operating the vehicle, always keep in mind and obey

the notes of precaution printed on the“Safety Precaution

Label”attached to the vehicle.

OPERATION INSTRUCTION

SAFETY PRECAUTIONS

●Always wear helmet.

●Always put on gloves.

●Observe posted speed limits.

●Park vehicle away from people(especially children) as

the muffler can get very hot.

●For safety, do not illegally modify the vehicle.

●Regularly conduct specified maintenance inspections.

Brakes, Tires, Oil, Lights, Horn, Instruments

**SL-125OWNERS(1~49) 02.11.5 4:21 PM 페이지4

●Read user's manual carefully.

●Conduct maintenance checks prior to operation.

●Always maintain vehicle in clean status and carry out

specified maintenance checks.

●Make sure to stop engine and stay away from fire when

fueling.

●Exhaust gas contains harmful substance such as carbon

monoxide. Start engine in well-ventilated places.

PRIOR TO STARTING VEHICLE

●Operators should naturally fix bodies to keep smooth driving.

●Please check whether or not you are unnaturally strained and

strung up.

●Driving pose has a great influence on safe operation.

Please always maintain the center of your body in the middle

of seat.

Especially do not sit at the rear seat because it may lessen the

weight of front wheel and cause trembling steering wheel.

●Passengers should accurately fix bodies using both hands and

put both feet on floor panel.

●When wanting to turn, slightly lean to body toward the

direction of the turn. It is unsafe if the body is not moved in

union with the vehicle.

●Curvy roads and poor, unpaved roads constantly change in

surface quality. Driving on these roads can be unsafe if

certain safety precautions are not followed.

●In order to safely drive through these driving conditions,

anticipate coming road conditions, slow down to at least half

the normal speed, and relax your shoulders and wrists while

securely holding the handles.

OPERATION

**SL-125OWNERS(1~49) 02.11.5 4:21 PM 페이지5

●When carrying cargo, you must keep in mind that operating

the vehicle, especially when turning, will be different.

●Make sure not to overload the vehicle with goods as this can

make the vehicle unstable during operation.

REAR CARRIER MAXIMUM LOAD : 3kg

TRUNK MAXIMUM LOAD : 10kg

CAUTION

●Only load cargo in or on designated areas as placing or

fastening cargo to other areas can cause damage to the

vehicle.

●Do not place articles between the frame body cover and

engine as this can burn the goods.

CARGO

Correct shirts or jackets

with tight-fitting sleeves

should be worn.

A helmet should always be

worn and the helmet chin

strap should be securely

fastened.

Shoes should fit properly, and shoes having

little or no heel should be worn.

CORRECT ATTIRE

●Always make sure to wear helmet for safety. Wear

gloves and safety goggles.

●Do not wear uniforms which might hinder operation. It is

dangerous if the uniform is caught by brake lever.

**SL-125OWNERS(1~49) 02.11.5 4:21 PM 페이지6

●Modification of vehicle structure or function deteriorates

manipulability or causes exhaust noise to become louder

shortening the vehicle life. These modifications are not only

prohibited by law but also are the acts harmful to other

people. Modifications are not covered by warranty.

●Except designated attachment by DAELIM MOTOR CO.,

LTD., don’t attach any extra lighting device, because it may

cause an early discharging of battery.

MODIFICATION ATTACHMENT

●Pay particular attention to fellow passenger so that he/she

can prevent getting burnt by the hot muffler during travel.

MUFFLER

**SL-125OWNERS(1~49) 02.11.5 4:21 PM 페이지7

PARTS LOCATION

TRUNK

BACK REST

TIRE

MUFFLER PILLION STEP BAR

SEAT

BAG HOLDER

BACK MIRROR

FRONT BRAKE LEVER

BRAKE DISK

**SL-125OWNERS(1~49) 02.11.5 4:21 PM 페이지8

BATTERY

FUSE

REAR BRAKE LEVER

HEADLIGHT

FRONT CUSHION

FUEL TANK LID

(BENEATH THE SEAT)

SIDE STAND MAIN STAND KICK START PEDAL

**SL-125OWNERS(1~49) 02.11.5 4:21 PM 페이지9

Table des matières

Autres manuels DAELIM Scooter

DAELIM

DAELIM S2 125 Manuel utilisateur

DAELIM

DAELIM BESBI SC125 - Manuel utilisateur

DAELIM

DAELIM A-FOUR - Manuel utilisateur

DAELIM

DAELIM B-BONE Manuel utilisateur

DAELIM

DAELIM S1 125 - SERVICE Manuel utilisateur

DAELIM

DAELIM CORDI - Manuel utilisateur

DAELIM

DAELIM NS125III - SERVICE Manuel utilisateur

DAELIM

DAELIM CITI ACE 110 - Manuel utilisateur

DAELIM

DAELIM A-FOUR - Manuel utilisateur

DAELIM

DAELIM BESDI 125 - SERVICE Manuel utilisateur

DAELIM

DAELIM S-FIVE - Manuel utilisateur

DAELIM

DAELIM Q2 Manuel utilisateur

DAELIM

DAELIM S4 50cc Manuel utilisateur

DAELIM

DAELIM BESBI - Manuel utilisateur

DAELIM

DAELIM DELFINO Manuel utilisateur

DAELIM

DAELIM S2 250 - Manuel utilisateur

DAELIM

DAELIM S-FIVE - Manuel utilisateur

DAELIM

DAELIM S2 250 - Manuel utilisateur

DAELIM

DAELIM NS 125 DLX Manuel utilisateur

DAELIM

DAELIM S2 125 Manuel utilisateur

DAELIM

DAELIM DELFINO Manuel utilisateur

DAELIM

DAELIM S-FIVE - Manuel utilisateur

DAELIM

DAELIM NS125DLX Manuel utilisateur

DAELIM

DAELIM E-FIVE Manuel utilisateur

Manuels Scooter populaires d'autres marques

TEKTRO

TEKTRO CHEETAH Manuel utilisateur

Douglas

Douglas Vespa Sprint Guide d'installation

PLAYTIVE

PLAYTIVE AS-2448 Manuel utilisateur

Ebinger

Ebinger DONKEY XL Manuel utilisateur

Flyer

Flyer Mountain Guide de l'utilisateur

BackCountry eBikes

BackCountry eBikes Storm Manuel utilisateur

equipmed

equipmed FreeRoam II Manuel utilisateur

Yoto

Yoto Lion Manuel utilisateur

WESTHILL BIKES

WESTHILL BIKES LINK Manuel utilisateur

BAnff

BAnff eProdigy series Manuel utilisateur

Winther

Winther 475 Manuel utilisateur

Jetson

Jetson JBZL17 Manuel utilisateur

First Choice Mobility

First Choice Mobility Roma Medical Corella S741 Manuel utilisateur

Carrera

Carrera impel Manuel utilisateur

Afikim

Afikim Superlight SL-3 Manuel utilisateur

CareCo

CareCo ZOOM Manuel utilisateur

Douglas

Douglas Vespa G.S. Manuel utilisateur

Gazelle

Gazelle with BOSCH System Manuel utilisateur
