D-Link DWL-6600AP Manuel utilisateur

This document will guide you through the basic installation

process for your new D-Link Wireless N Access Point.

DWL-6600AP

Documentation also available on

CD and via the D-Link Website

Quick Installation Guide

Unied Concurrent Dual-Band Access Point

D-Link DWL-6600AP Quick Install Guide

ENGLISH

DWL-6600AP Quick Install Guide

This installation guide provides basic instructions for installing the DWL-6600AP Wireless

Access Point on your network. For additional information about how to use the Access Point,

please see the User’s Manual which is available on the CD included in this package or from

the D-Link support website.

System Requirements

Minimum System Requirements:

• CD-ROM Drive

• Windows®, Macintosh®, or Linux-based operating system

• an Ethernet port, or an installed Ethernet adapter

• Internet Explorer 7.0, Safari 5.0, Firefox 4.0, or later versions of these three browsers

1. Package Contents

DWL-6600AP 802.11n Access Point

Power Adapter

Power Cord

Mounting Ring

Ethernet Cable

Console Cable*

CD-ROM

If any of the above items are missing, please contact your reseller.

Note: Using a power supply with a different voltage than the one included with the

DWL-6600AP will cause damage and void the warranty for this product.

*Console cable is the optional accessory and not included in the package in Armenia,

Azerbaijan, Belarus, Georgia, Israel, Kakistan, Kaliningrad, Kazakhstan, Kyrgyzstan, Latvia,

Lithuania, Moldova, Mongolia, Russia, Turkey, Turkmenistan, Ukraine and Uzbekistan. If any

required, please contact your reseller to order it (Model: ACS-AP-CONSOLE).

Optional Accessories

PoE Base Unit (Model: DPE-101GI)

2.4/5GHz Dual-Band Antenna (Model: ANT70-0500)

Note: These accessories are not included in the package. If any of these items are required,

please contact your reseller to order it.

D-Link DWL-6600AP Quick Install Guide

ENGLISH

2. Hardware Overview

LEDs

5 GHz – When this LED is lit, the access point is operating at 5GHz. It will blink when there

is wireless traffic.

2.4 GHz – When this LED is lit, the access point is operating at 2.4GHz. It will blink when

there is wireless traffic.

LAN – When this LED is lit, the device’s Ethernet port is connected to an active router or

switch. The light will blink when there is traffic going through the port.

POWER – When this LED is lit in red, the access point is during boot-up. When this LED is

lit in green, the access point is ready.

Interfaces

Power Receptor LAN Port (PoE)

Console Port

D-Link DWL-6600AP Quick Install Guide

ENGLISH

Note: The DWL-6600AP has an internal antenna. If you would like to use external antennas,

please slide the selector switch to the “EXT” position and attach the antennas.

Reset Button

Antenna Selector

Switch ("INT" or "EXT")

2.4 GHz/ 5 GHz

Antenna Connectors

D-Link DWL-6600AP Quick Install Guide 5

ENGLISH

Power on the access point

To power on the DWL-6600AP, you can use ONE of the following methods:

1. Connect the supplied power adapter, OR

2. Plug one end of your Ethernet cable into the LAN port of the DWL-6600AP, and

the other end into a port on a PoE switch.

Congure the access point

To set up and manage the DWL-6600AP, use one of the following methods:

1. Connect the access point and your computer directly via a straight-through

Ethernet cable. Manage the access point from the computer.

2. Connect the access point and your computer to the same switch or router. Manage

the access point from the computer.

3. Connect the access point to a Unied Wireless Switch or Wireless Controller.

Connect your computer to the same network as that of the Unied Wireless Switch

or Wireless Controller. Manage the access point from the computer via the Unied

Wireless Switch or Wireless Controller.

Computer

Switch or Router

DWL-6600AP

3. Installation

ComputerDWL-6600AP

Unied Wireless Switch

Wireless Controller

ComputerDWL-6600AP

D-Link DWL-6600AP Quick Install Guide

ENGLISH

Install the access point:

Follow these step-by-step instructions to

install the DWL-6600AP on a wall or ceiling:

Step 1: Place the mounting ring on the

ceiling and position it so that the arrow

symbol (triangle) points in the direction that

the product’s front side should face. Mark

the positions of the four anchor holes with a

pencil. Drill the holes where the marks have

been made. The holes should be at least as

deep as the supplied screw anchor plugs.

Step 2: Insert the provided screw anchor

plugs into the holes.

Step 3: Use the provided screws to attach

the mounting ring to the wall.

Step 4: Place the DWL-6600AP’s male

brackets in the mounting ring’s female

brackets, with the device’s LED lights facing

the desired direction. Rotate the product

clockwise to lock it in position.

Congratulations, you have just successfully

mounted DWL-6600AP product.
