2 D-Link Systems, Inc.

DWL-3200AP Install GuideSystem Requirements

D-Link Air PremierTM DWL-3200AP

Managed Wireless Access Point

Using a power adapter with a different

voltage rating will damage and void the

warranty of this product.

Power Cord Power over Ethernet base unit

Ethernet Cable

Power Adapter-DC 48V, 0.4A

Mounting Plate

CD-ROM with Manual

System Requirements:

Minimum System Requirements:

• CD-ROM Drive

• Computers with Windows, Macintosh, or Linux-based operating systems

• Installed Ethernet Adapter Internet Explorer version 6.0 or Netscape

Navigator version 7.0 and above

Package Contents

D-Link Systems, Inc. 3

DWL-3200AP Install Guide Installing the Hardware

Installing the Hardware

Step 1

Step 2

Connect one end of an Ethernet cable

(included with your package) to the

LAN port on the DWL-3200AP and the

other end of the Ethernet cable to the

port labeled P+DATA OUT on the PoE

base unit.

Connect another Ethernet cable from

the DATA IN port on the PoE base unit

to your router/switch or to a PC.

Attach the power adapter to the connector

labeled POWER IN on the PoE base unit.

Attach the power cord to the power adapter

and into an electrical outlet.

Step 3

4 D-Link Systems, Inc.

DWL-3200AP Install GuideThe Setup Wizard

Open your Web browser

and type http://192.168.0.50

into the URL address box.

Then press the Enter or

Return key.

Click Run Wizard

The logon pop-up screen will

appear.

Type admin

for the username and leave

the password ﬁ eld blank.

Once you have logged in, the

Home screen will appear.

Using the Setup Wizard

D-Link Systems, Inc. 5

DWL-3200AP Install Guide The Setup Wizard

You will see the following

screens.

Click Next

Step 1 - Setup your new

password. You have the

option to establish a password.

Click Next

Step 2 - Set Wireless LAN

Connection.

By default the

DWL-3200AP SSID is set

to default with a Channel

setting of 6.

For 802.11g networks please

do the following:

Click Next

6 D-Link Systems, Inc.

DWL-3200AP Install GuideThe Setup Wizard

For 802.11g networks please

continue as follows:

Click Next

Click Restart

Your Setup is complete!

Step 3 - Encryption

The DWL-3200AP is capable of

three levels of wireless encryption:

64-, 128-, 152-bit, using either

Hexadecimal or ASCII key type.

By default encryption is disabled.

You can change the encryption

settings for more secure wireless

communication.

D-Link Systems, Inc. 7

DWL-3200AP Install Guide The Setup Wizard

When you have completed the steps in this Quick Installation Guide,

your connected network should look similar to this:

Your Setup is Complete!

8 D-Link Systems, Inc.

DWL-3200AP Install GuideNotes

Technical Support

D-Link’s website contains the latest user documentation and software

updates for D-Link products.

D-Link provides free technical support for customers within the United States

and Canada for the duration of the product’s warranty period.

U.S. and Canadian customers can contact D-Link Technical Support through

our website or by phone.

United States

Telephone

(877) 453-5465

Monday to Friday 6:00am - 6:00pm

World Wide Web

http://support.dlink.com

E-mail

suppor[email protected]

Canada

Telephone

(800) 361-5265

Monday through Friday, 7:30am to 12:00am EST.

World Wide Web

http://support.dlink.ca

E-mail

suppor[email protected]

Version 1.0

Revised 01/21/05

speciﬁ cations subject to change without notice.
