D-Link DES-2108 Manuel utilisateur

DES-2108

8-port 10/100

Fast Ethernet Switch

User’s Guide

2007/6/13

CE Mark Warning

This is a Class B product. In a domestic environment, this product

may cause radio interference in which case the user may be required

to take adequate measures.

Warnung!

Dies ist ein Produkt der Klasse B. Im Wohnbereich kann dieses

Produkt Funkstoerungen verursachen. In diesem Fall kann vom

Benutzer verlangt werden, angemessene Massnahmen zu ergreifen.

Precaución!

Este es un producto de Clase B. En un entorno doméstico, puede

causar interferencias de radio, en cuyo case, puede requerirse al

usuario para que adopte las medidas adecuadas.

Attention!

Ceci est un produit de classe B. Dans un environnement domestique,

ce produit pourrait causer des interférences radio, auquel cas

l`utilisateur devrait prendre les mesures adéquates.

Attenzione!

Il presente prodotto appartiene alla classe B. Se utilizzato in ambiente

domestico il prodotto può causare interferenze radio, nel cui caso è

possibile che l`utente debba assumere provvedimenti adeguati.

TABLE OF CONTENTS

About This Guide ................................................................................1

Terms 1

Overview of this User’s Guide1

Introduction..........................................................................................2

Fast Ethernet Technology 2

Switching Technology 2

Switch Description 3

Features 4

Ports 5

Unpacking and Setup...........................................................................6

Unpacking 6

Setup 6

Mounting the Switch on aWall 7

Power on 8

Identifying External Components........................................................8

Front Panel Components 8

Rear Panel 9

LED Indicators 9

Power and CPU LEDs 10

10/100M Fast Ethernet Ports Status LEDs 10

Introduction To Switch Management ................................................10

Management Options11

SmartConsole Utility 11

Web-based Management Interface 11

Command Line Interface (CLI) 11

SNMP-Based Management 12

Configuration The Switch..................................................................12

SmartConsole Utility 12

Installing SmartConsole Utility..........................................12

Discovered Devices ...........................................................13

Monitor List.......................................................................14

Device Setting....................................................................16

Toolbar...............................................................................18

Configuring the Switch using Web Browsers 19

Setup Menu........................................................................22

System > System Setting....................................................22

System > Trap Setting........................................................24

System > Port Setting.........................................................25

System > SNMP Setting ....................................................26

System > Password Access Control...................................28

System > Syslog.................................................................28

iii

System > SNTP Settings....................................................29

Configuration > 802.1Q VLAN.........................................30

Configuration > Trunk.......................................................32

Configuration > IGMP Snooping.......................................33

Configuration > 802.1D Spanning Tree.............................36

Configuration > Port Mirroring .........................................38

QoS > 802.1p Default Priority...........................................39

Security > Trusted Host.....................................................39

Security > Storm Control...................................................40

Security > Bandwidth Control...........................................40

Security > 802.1x Settings.................................................41

Security > MAC Address Table > Static MAC .................43

Security > MAC Address Table > Dynamic Forwarding

Table ..................................................................................44

Monitoring > Statistics.......................................................45

Configuring the Switch using the CLI 46

IP Address of the Switch....................................................46

Using the CLI via Telnet interface.....................................47

Command Syntax...............................................................48

Basic Switch Commands ...................................................49

Basic IP Commands...........................................................56

Switch Port Commands......................................................57

VLAN Commands .............................................................61

Port Mirroring Commands.................................................64

Trap Commands.................................................................67

Spanning Tree Commands.................................................72

SNMP Commands .............................................................77

IGMP Snooping Commands..............................................83

Static MAC Commands.....................................................91

Trusted Host Commands....................................................95

Trunk Commands...............................................................97

SNTP Commands...............................................................99

System Log Commands ...................................................106

802.1x Commands ...........................................................110

Technical Specifications..................................................................117

ABOUT THIS GUIDE

This user’s guide will show you how to install your DES-2108, and

how to connect it to your network.

Terms

For simplicity, this documentation uses the terms “Switch” (first letter

upper case) to refer to the DES-2108, and “switch” (first letter lower

case) to refer to all Ethernet switches, including the DES-2108.

Overview of this User’s Guide

Introduction Describes the Switch and its features.

Unpacking and

Setup Helps you get started with the basic

installation of the Switch.

Identifying

External

Components

Describes the front panel, rear panel, and

LED indicators of the Switch.

Configuration the

Switch Show how to configure the management

functions of the Switch.

Technical

Specification Lists the technical specifications of the

Switch.

INTRODUCTION

This section describes the features of the DES-2108, as well as giving

some background information about Fast Ethernet and Switching

technology.

Fast Ethernet Technology

The growing importance of LANs and the increasing complexity of

desktop computing applications are fueling the need for high

performance networks. A number of high-speed LAN technologies

are proposed to provide greater bandwidth and improve client/server

response times. Among them, Fast Ethernet, or 100BASE-T, provides

a non-disruptive, smooth evolution from 10BASE-T technology.

100Mbps Fast Ethernet is a standard specified by the IEEE 802.3

LAN committee. It is an extension of the 10Mbps Ethernet standard

with the ability to transmit and receive data at 100Mbps, while

maintaining the Carrier Sense Multiple Access with Collision

Detection (CSMA/CD) Ethernet protocol.

Switching Technology

Another key development pushing the limits of Ethernet technology is

in the field of switching technology. A switch bridges Ethernet

packets at the MAC address level of the Ethernet protocol transmitting

among connected Ethernet or Fast Ethernet LAN segments. Switching

is a cost-effective way of increasing the total network capacity

available to users on a local area network. A switch increases capacity

and decreases network loading by making it possible for a local area

network to be divided into different segments, which are not

competing with each other for network transmission capacity, and

therefore decreasing the load on each segment. The Switch acts as a

high-speed selective bridge between the individual segments. Traffic

that needs to go from one segment to another (from one port to

another) is automatically forwarded by the Switch, without interfering

with any other segments (ports). This allows the total network

capacity to be multiplied, while still maintaining the same network

cabling and adapter cards. For Fast Ethernet or Gigabit Ethernet

networks, a switch is an effective way of eliminating problems of

chaining hubs beyond the "four-repeater limit." A switch can be used

to split parts of the network into different collision domains, for

example, making it possible to expand your Fast Ethernet network

beyond the 205-meter network diameter limit for 100BASE-TX

networks. Switches supporting both traditional 10Mbps Ethernet and

100Mbps Fast Ethernet are also ideal for bridging between existing

10Mbps networks and new 100Mbps networks. Switching LAN

technology is a marked improvement over the previous generation of

network bridges, which were characterized by higher latencies.

Routers have also been used to segment local area networks, but the

cost of a router and the setup and maintenance required make routers

relatively impractical. Today's switches are an ideal solution to most

kinds of local area network congestion problems.

Switch Description

The DES-2108 is equipped with unshielded twisted-pair (UTP) cable

ports providing dedicated 10 or 100 Mbps bandwidth. The Switch has

8 UTP ports and Auto MDI-X/MDI-II convertible ports that can be

used for up-linking to another switch. These ports can be used for

connecting PCs, printers, servers, hubs, routers, switches and other

networking devices. The dual speed ports use standard twisted-pair

cabling and are ideal for segmenting networks into small, connected

sub-networks for superior performance. Each 10/100 port can support

up to 200 Mbps of throughput in full-duplex mode. This stand-alone

Switch enables the network to use some of the most demanding

multimedia and imaging applications concurrently with other user

applications without creating bottlenecks. The built-in Light-

Management engine can be configure the Switch's settings for priority

queuing, VLANs, and port monitoring, and port speed.

Features

The DES-2108 was designed for easy installation and high

performance in an environment where traffic on the network and the

number of users increase continuously.

The Switch features include:

IEEE 802.3 10BASE-T compliant.

IEEE 802.3u 100BASE-TX compliant.

IEEE 802.3x flow control in full duplex mode.

IEEE 802.1Q VLAN & Port_based VLAN.

IEEE 802.1D Spanning Tree.

Port_based QoS.

System Log Support.

High performance switching engine performs forwarding and

filtering at full wire speed.

Full- & Half- duplex operation for both of 10Mbps and

100Mbps and connections. Full duplex allows the switch port

to simultaneously transmit and receive data. It only works

with connections to full-duplex-capable end stations and

switches.

Non-blocking store and forward switching scheme capability

to support rate adaptation and protocol conversion.

Efficient self-learning and address recognition mechanism

enables forwarding rate at wire speed.

Support port-based enable and disable.

Address table: Supports up to 4K MAC addresses per device.

Autres manuels pour DES-2108

Table des matières

Autres manuels D-Link Changer

D-Link

D-Link xStack DGS-3427 Manuel utilisateur

D-Link

D-Link DES-1018MP Manuel utilisateur

D-Link

D-Link DIR 601 - Dlink Wireless N 150 Home Router Manuel utilisateur

D-Link

D-Link DES-1008F Manuel utilisateur

D-Link

D-Link DGS-3308 Series Manuel utilisateur

D-Link

D-Link DHP-342 Manuel utilisateur

D-Link

D-Link EasySmart DES-1100-16 Mode d’emploi

D-Link

D-Link DKVM-4K - KVM Switch Manuel utilisateur

D-Link

D-Link DES-3326SRM Manuel utilisateur

D-Link

D-Link DKVM-2/4 Manuel utilisateur

D-Link

D-Link DXS-3400 SERIES Manuel utilisateur

D-Link

D-Link mydlink DCH-G022 Manuel utilisateur

D-Link

D-Link DES-3528 - xStack Switch - Stackable Manuel utilisateur

D-Link

D-Link DGS-3024 Manuel utilisateur

D-Link

D-Link DES-1210-08P Manuel utilisateur

D-Link

D-Link DSS-100 Manuel utilisateur

D-Link

D-Link DUB-H7 - Hub - USB Manuel utilisateur

D-Link

D-Link DGS-3100 SERIES Manuel utilisateur

D-Link

D-Link H4SMK - DSB Hub Manuel utilisateur

D-Link

D-Link DES-3326SR Manuel utilisateur

D-Link

D-Link 55443 Manuel utilisateur

D-Link

D-Link DGS-1100-05PDV2 Manuel utilisateur

D-Link

D-Link DWS-3160-24TC Manuel utilisateur

D-Link

D-Link DGS-1248T - Switch Manuel utilisateur

Manuels Changer populaires d'autres marques

URC

URC Total Control MFS-8 Manuel utilisateur

Azbil

Azbil HPQ-D11 Manuel utilisateur

Sony

Sony DFS-900M Manuel utilisateur

SICK

SICK i17S Manuel utilisateur

F&F

F&F SZR-277 Manuel utilisateur

Shure

Shure UAMS/BK Manuel utilisateur

Dräger

Dräger X-zone Switch Off Manuel utilisateur

Asco

Asco Joucomatic 349 Series Manuel utilisateur

BT Mini Hub Manuel utilisateur

Johnson Controls

Johnson Controls FS80-C Manuel utilisateur

Alcatel-Lucent

Alcatel-Lucent 7450 ESS-12 Manuel utilisateur

MicroNet

MicroNet SP1200A Manuel utilisateur

Ruijie

Ruijie RG-PF2920 Series Manuel d'installation et d'exploitation

Altinex

Altinex DA1914SX Manuel utilisateur

MiLAN

MiLAN MIL-SM2401M Manuel utilisateur

RJM

RJM MASTERMIND PBC/6X Manuel utilisateur

Atlas

Atlas MMK-KVM8 Manuel utilisateur

Cabletron Systems

Cabletron Systems GIGAswitch GSR-16 Manuel utilisateur
