D-Link DCS-71 Series Manuel utilisateur
This document will guide you through the basic installation
process for your new D-Link 7" Outdoor Dome Housing.
DCS-71 Series
Quick Installation Guide
DCS-71 Series Outdoor Dome Housing
Quick Installation Guide
Руководство по быстрой установке
Guía de Instalación Rápida
Guia de Instalação Rápida
快速安裝指南
Petunjuk Pemasangan Cepat
D-Link DCS-71 Series Quick Installation Guide
2
ENGLISH
DCS-71 Series Quick Installation Guide
This installation guide provides basic instructions for installing the DCS-71 Series
7" Outdoor Dome Housing. The DCS-71 series are dome-type enclosures designed for
use with D-Link’s motorized pan and tilt cameras. This IP66-certied enclosure protects
your camera against dust and heavy jets of water. These models include a heater and
a blower for a wider range of temperature-sensitive environments. The DCS-71 series
consists of the DCS-71, DCS-71P and DCS-71W.
Installation
1. Verify the package contents against the list below.
2. Hardware Overview
3. Hardware Installation
1. Package Contents
7" Metal Housing
7" Dome Cover
Wall Mount Bracket
Screws
2 Wireless Antennas (for DCS-71W only)
2 Antenna Holders (for DCS-71W only)
Quick Installation Guide
If any of the above items are missing, please contact your reseller.
D-Link DCS-71 Series Quick Installation Guide 3
ENGLISH
2. Hardware Overview
Wireless Antenna
(for DCS-71W only)
DCS-71W
24 V AC Power Cable
Connects to 24 V AC
power
Dome Cover
Protects the camera
from dust and water
DCS-71
Metal Housing
Covers the camera
Mount Bracket
Connects metal
housing unit to wall
24 V AC Power Cable
Connects to 24 V AC
power
DCS-71P
D-Link DCS-71 Series Quick Installation Guide
4
ENGLISH
3. Hardware Installation
Step 1
Pull the Ethernet cable (DCS-71, DCS-71P) through the wall mount bracket and the
center of the housing.
Step 2
Turn the metal housing upside down and open it. Rotate the base of the camera to lock
it onto the bracket in the inside top surface of the metal housing.
Pull cable through bracket
and into the metal housing.
Cable as seen in inner
top of metal housing.
D-Link DCS-71 Series Quick Installation Guide
5
ENGLISH
Step 3
Plug in the power and external Ethernet cable to the camera.
Connect the 12 V DC power cable and Ethernet cable's RJ45 connector to the camera.
For DCS-71
For DCS-71P
Connect the external Ethernet cable to the housing's PoE covert board and the onboard
RJ45 connector to the camera. The Ethernet cable is used to provide an Ethernet
connection and to power the camera using PoE. If the camera is not a PoE type, please
connect the 12 V DC connector to the camera.
RJ45 (connects to external Ethernet
cable)
RJ45 connector for PoE to Camera
12 V DC Output Power Cable to Camera
Camera Rear Panel
Camera Rear Panel
RJ45 Connector for Ethernet
12 V DC Output Power Cable to Camera
(only used if PoE function is not
supported by camera)
D-Link DCS-71 Series Quick Installation Guide
6
ENGLISH
Wireless Connector
Wireless Connector
12 V DC Output Power Cable to Camera
For DCS-71W
Connect the 12 V DC power cable and wireless connectors to the camera.
Camera Rear Panel
D-Link DCS-71 Series Quick Installation Guide
7
ENGLISH
Step 4
Place the dome cover over the metal housing and secure it by tightening the screws.
Tighten by screw Tighten by screw
Step 5
Mount the metal housing to the bracket.
Tighten by screw
D-Link DCS-71 Series Quick Installation Guide
8
ENGLISH
2. Attach the antenna holders to the housing and tighten them in place.
Step 7
Install Wireless Antennas (for DCS-71W only)
1. Connect the wireless antenna to the metal housing.
Step 6
Install the mount bracket onto the wall.
D-Link DCS-71 Series Quick Installation Guide
9
ENGLISH
Model DCS-71 DCS-71P DCS-71W
CAT Mid-Span, End-Span
Data
Transmission
Rate
10/100 Mbps
Transmission
Distance
<100 m
Ethernet Data
Line
TIA/EIA-568, Cat-5 Cable
Heater On: below 0°; Off: above 10° C
Blower On: above 40°; Off: below 30° C
Weatherproof IP66 Certied
Power
Consumption
35 W 29.5 W 55 W
Power Source
for Camera
12 V DC 12 V DC
802.3at PoE
12 V DC
Power Source
for Enclosure
24 V AC 802.3at PoE 24 V AC
4. Specications
Step 8
Connect the 24 V AC power cable (DCS-71, DCS-71W) to a power adapter or Ethernet
cable (DCS-71P) to a PoE device.
24 V AC Power Cable
D-Link DCS-71 Series Quick Installation Guide
10
ENGLISH
5. Dimensions
Model DCS-71 DCS-71P DCS-71W
Operating
Temperature
-20° ~ 70° C
Humidity 5%-95%
Certications CE, FCC
Supported
Camera
DCS-5605 A1
version
DCS-5605
A2 version or
above
DCS-5635
A2 version or
above
