Краткое руководство по установке

5 Мп внешняя купольная антивандальная сетевая камера с

ИК-подсветкой до 20 м, PoE, варио окальным объективом, WDR

и слотом microSD

Quick Installation Guide

This installation guide provides basic instructions for installing the DCS-6517. For

additional information about how to use the camera, please see the User Manual which is

available on the CD included in this package or from the D-Link support website.

Package ontents

•DCS-6517 5 Megapixel H.265 Outdoor Dome Network Camera

•Ethernet Cable

•Extension Adapter

•Mounting Plate and Screws

•Sun Shield

•Side Cover

•Alignment Sticker

•Manual and Software on CD-ROM

•Quick Installation Guide

If any of the above items are missing, please contact your reseller.

Safety Notice:

Installation and servicing should be done by certified technicians so as to conform to all

local codes and prevent voiding your warranty.

D-Link DCS-6517 Quick Installation Guide

Hardware Overview

1 IR LEDs Provide illumination for low-light environments.

2 Tilt Lock Screw Can be loosened to adjust the camera's tilt angle.

3 amera Lens Camera lens to record video of the surrounding area.

4 Power/Status LED Indicates the camera's current status.

5 Light Sensor Measures lighting conditions and switches between day

and night mode accordingly.

6 Horizontal Lock Screw Can be loosened to adjust the horizontal rotation of the

camera.

7 microSD ard Slot Accepts a microSD card for onboard storage of

snapshots and video.

8 Ethernet Jack Connects to an RJ45 Ethernet port. Can be used with

PoE to provide power to the camera.

9 able hannels Allow cables to exit the camera from the back or side.

10 able Harness Port Connects to the optional cable harness (not included).

1. 12V IN

2. GND

3. AUD IN

4. AUD GND

5. AUD OUT

6. 12V OUT

7. GND

8. RESET

9. DI

10. DO

D-Link DCS-6517 Quick Installation Guide

Optional able Harness (not included)

11 able Harness

onnector

Connects to the DCS-6517. For more details on

connecting the A/V cable, refer to the User Manual.

12 DI/DO

onnector

I/O connectors for external devices.

(12 V DC output not supported for the DCS-6517)

13 Reset Button Press and hold the button for 10 seconds to reset the

camera back to the factory default settings.

14 24 V Power

onnector

Not supported for the DCS-6517.

15 Power

onnector

Power connector for a 12 V DC power adapter (not

included).

16 Audio Out

(Green)

Connects to a speaker.

17 Audio In

(Red)

Connects to a microphone.

18 BN onnector Not supported for the DCS-6517.

D-Link DCS-6517 Quick Installation Guide

onnecting the Optional able Harness

Remove the sun shield by lifting it off of the

camera. Use the included security wrench to

remove the 4 screws from the top of the camera,

then remove the camera cover.

Remove a waterproofing plug from the side or

bottom of the camera depending on how you want

the cables to exit the camera.

Push the camera connector and cable through the

hole, and insert the cable's waterproofing plug.

Make sure the plug is inserted properly to ensure a

good seal.

For side cable exit:

Attach the side cover via the provided screws.

Slide the cover over the cable ports.

For bottom cable exit:

Attach the protective side cover via the provided

screws.

Connect the camera connector to the camera.

Reattach the camera cover using the security

wrench to tighten the 3 screws, and reattach the

sun shield.

D-Link DCS-6517 Quick Installation Guide

microSD ard Installation

Remove the sun shield by lifting it off of the

camera. Use the included security wrench to

remove the 4 screws from the top of the camera,

then remove the camera cover.

Insert the microSD card with the gold contacts

facing the outside of the camera. To eject the

microSD card, push the card into the slot.

Reattach the camera cover using the security

wrench to tighten the 4 screws, and reattach the

sun shield.

Mounting the amera on the eiling

Locate a suitable position on the ceiling that is

capable of supporting the weight of the camera.

Attach the alignment sticker to the ceiling or wall.

Align the mounting plate to the drilled holes in the

ceiling surface then tighten the screws.

Align the camera to the mounting plate and screw

the camera body to the plate tightly.

Adjusting the amera's Lens

Adjust the Camera’s Lens gimbal; turn the lens module left and right, up and down and the

orientation until the desired position is achieved. Tighten the pan, tile and the adjustment

screw once completed.

D-Link DCS-6517 Quick Installation Guide

Installing the Pendant Mount (Optional)

Attach the mounting plate to the bracket cap using

the three included screws.

Locate a suitable position on the ceiling for a 34

mm (+2 / -0 mm) hole to be cut. Use the included

template to mark and cut the mounting holes.

Locate a suitable position on the ceiling for a 34

mm (+2 / -0 mm) hole to be cut. Use the included

template to mark and cut the wiring hole.

Drill four 6 mm holes corresponding to the holes in

the mounting template and insert the plastic

anchors into these holes.

Place the rubber seal between the pendant bracket

and the ceiling to ensure a waterproof seal between

the ceiling and the bracket.

Attach the pendant bracket to the ceiling using the

screws provided.

Attach the bracket cap to the bottom of the pendant

bracket by rotating the cap counterclockwise to

tighten it into place.

Insert the screw into the base of the pendant

bracket at the top of the bracket cap to secure the

bracket cap into place.

D-Link DCS-6517 Quick Installation Guide

Thread an Ethernet cable and the power cable

through the pendant bracket.

Place the camera body onto the bracket cap and

attach the dome to the base of the camera using

the four long screws and the security screw.

Installing the Right-Angle Mount (Optional)

Attach the mounting plate to the bracket cap using

the included three screws.

Locate a suitable position on the ceiling for a 34

mm (+2 / -0 mm) hole to be cut. Use the included

template to mark and cut the mounting holes.

Drill four 6 mm holes corresponding to the holes in

the mounting template and insert the plastic

anchors into these holes.

D-Link DCS-6517 Quick Installation Guide

Place the rubber seal between the right-angle

bracket and the ceiling to ensure a waterproof seal

between the ceiling and the bracket.

Attach the right-angle bracket to the ceiling using

the screws provided.

Attach the bracket cap to the bottom of the right-

angle bracket by rotating the cap counterclockwise

to tighten it into place.

Insert the screw into the base of the right-angle

bracket at the top of the bracket cap to secure the

bracket cap into place.

Thread an Ethernet cable and the power cable

through the pendant bracket.

Place the camera body onto the bracket cap and

attach the dome to the base of the camera using

the three long screws and the security screw.

onnecting the amera

onnection with a PoE Switch

•Connect the Ethernet cable to your PoE

switch or injector. The Ethernet cable will

provide the camera with both power and a

network connection.

If you have the optional cable harness, you can

also use the following connection method:

General onnection Using 12 V D Power

Adapter (not included)

•Connect the Ethernet cable to your network.

•Connect your power adapter to the camera's

power connector, then plug in the power

adapter.

D-Link DCS-6517 Quick Installation Guide

onfiguring the amera

Insert the DCS-6517 CD into your computer's CD-ROM drive to begin the installation. If

the Autorun function on your computer is disabled, or if the D-Link Launcher fails to start

automatically, run D:\autorun.exe, where D: represents the drive letter of your CD-ROM

drive.

Click Setup Wizard to begin the installation.

After clicking Setup Wizard, the following window

will open.

Click Next to continue.

Click Yes to accept the License Agreement.

To start the installation process, click Next.

Note: The installation may take several minutes to

finish.

Click Finish to complete the installation.
