D-Link DSL-G225 Manuel utilisateur

How to setup the DSL-G225

in Bridge Mode

D-Link Technical Support –How to setup DSL-G225 in Bridge Mode Page 2of 11

This guide is for DSL-G225 with firmware ver. 1.04.

Before proceeding with this setup please set your computer temporarily with a static IP address from

192.168.1.x range (e.g. 192.168.1.99):

Open your Internet browser e.g. Internet Explorer, Firefox, Chrome, Safari, etc. and enter the IP address of your D-

Link modem in the address bar: http://192.168.1.1.

When prompted, type in the Password. If you have not changed the password for the modem administration, the

factory password is “admin”.

D-Link Technical Support –How to setup DSL-G225 in Bridge Mode Page 3of 11

There are two ways to setup your modem in Bridge Mode: using the Setup Wizard and using Manual

Configuration.

Setup using the Setup Wizard

Step 1. After logging into the modem’s configuration pages, go to SETUP > Local Network.

Un-check the “Enable DHCP Server”option.

Click on Save/Apply.

D-Link Technical Support –How to setup DSL-G225 in Bridge Mode Page 4of 11

Step 2. Go to SETUP > Wizard > click on the “Setup Wizard” button.

Follow the steps in the Setup Wizard.

D-Link Technical Support –How to setup DSL-G225 in Bridge Mode Page 5of 11

Choose ADSL or VDSL, depending on the type of technology used for your Internet connection.

Set Protocol to “Bridge”.

It is recommended to disable the modem’s Wi-Fi:

D-Link Technical Support –How to setup DSL-G225 in Bridge Mode Page 6of 11

Click on “Save/Apply” to finish the Setup Wizard. The setup is complete.

D-Link Technical Support –How to setup DSL-G225 in Bridge Mode Page 7of 11

Manual Setup

Step 1. After logging into the modem’s configuration pages, go to SETUP > Local Network.

Un-check the “Enable DHCP Server”option.

Click on Save/Apply.

D-Link Technical Support –How to setup DSL-G225 in Bridge Mode Page 8of 11

Step 2. Go to SETUP > Internet Setup.

If there are any existing profiles listed in the WAN Setup table, delete them.

Choose ADSL or VDSL, depending on the type of technology used for your Internet connection.

Click on “Add”.

Set Protocol to “Bridging” and click on Next.

D-Link Technical Support –How to setup DSL-G225 in Bridge Mode Page 9of 11

Click on “Apply” to finish the setup. The modem setup is complete.

D-Link Technical Support –How to setup DSL-G225 in Bridge Mode Page 10 of 11

Please note that in Bridge Mode the DSL-G225 modem acts as a transparent device. If your Internet

provider requires PPPoE authentication or VLAN tagging, you need to enable these options on the device

connected to the LAN port of the DSL-G225 modem.

After successful VDSL sync
