D-Link DI-804HV - Express ENwork Router Manuel utilisateur

Thisproductcanbesetup

usinganycurrentwebbrowser,

i.e., InternetExplorer6or

NetscapeNavigator6.2.3.4-PortBroadband

VPNRouter

5VDC PowerAdapter

BeforeYouBegin

1.If youpurchasedthisroutertoshareyourhigh-speedInternetconnectionwithother

computers,youmusthaveeitheranEthernet-based CableorDSLmodemwithan

establishedInternetaccountfromanInternetServiceProvider(ISP).

2.It’s besttousethe samecomputerthatisconnected toyourmodemforconfiguring

theDI-804HVVPNRouter.TheDI-804HVactsasaDHCPserverand willassignall

the necessaryIPaddress informationon yournetwork.SeeAppendixattheend

ofthisQuick InstallationGuideortheManualon theCD-ROMforsetting each

networkadaptertoautomaticallyobtainanIPaddress.

CheckYourPackage Contents

DI-804HVVPNRouter

CD-ROM(containingManualandWarranty)

Ethernet(CAT5UTP/StraightThrough)Cable

Using apowersupply

withadifferentvoltage

rating will damage and void

the warrantyofthisproduct.

If anyoftheaboveitemsaremissing,pleasecontactyourreseller.

DI-804HV

specificationssubjecttochange withoutnotice.DI-804HV.02212003

ConnectingTheDI-804HVVPNRouterTo

YourNetwork

A.First, connectthe poweradaptertothe receptoratthe backpanelofthe

DI-804HVand thenplugthe otherendofthe poweradaptertoawall outletor

powerstrip.The PowerLEDwillturnONtoindicateproperoperation.

B.1.Poweroff yourCableorDSLmodem;somedevicesmaynothaveaon/

off switchandwillrequireyoutounplugthe poweradapter.Now,theDI-804HV

shouldbe poweredon andthe Cable/DSLmodemshouldbe turnedoff.

2.Cable/DSLmodem(PowerOff)–DI-804HV(PowerOn)

Connectan Ethernetcabletothe Ethernetjacklocatedon the Cable/DSL

modem.Afterthe Ethernetcableissecurelyconnected,poweronthe Cable/

DSLmodembyturningon the unitorplugginginthe poweradapter.

3.Cable/DSLmodem(PowerOn)–DI-804HV(PowerOn)

Insertthe otherend ofthe Ethernetcabletothe WANPORTonthe backpanel

ofthe DI-804HV.The WANLEDlightwill illuminatetoindicateproper

connection.If the WANLEDisnotilluminated,pleasego backand stepBand

repeatitsinstructions.

C.Insertan EthernetcabletoLANport1on thebackpaneloftheDI-804HV

andanavailableEthernetportonthe networkadapterinthecomputeryouwill

usetoconfigurethe DI-804HV.The LEDlightforLANPort1willilluminateto

indicateproperconnection.(Note:The LANPortsonthe DI-804HVareAuto-

MDI/MDIX.Meaningyoucanuseastraight-throughorcrossover-Ethernetcable

tothe LANPorts.)

D.COMPortfordial-upInternetconnection.B.WANPORTThisis

forthe connectionofan

Ethernetcabletothe

CableorDSLmodem

C.LANPORTSThesearethe connectionsfor

EthernetcablestoEthernetenabledcomputers.

D.COMPortUsedto

connecttoanexternal

dial-up modem.

ResetButton

Pressingthisbuttonrestores

the Routertoitsoriginalfactory

defaultsettings.

A.Receptorfor

PowerAdapter.

RestartYourComputer

ConnectingAdditionalComputersTo

TheDI-804HV

UsingadditionalEthernet(CAT5UTP)cables,connectyour

Ethernet-equippedcomputerstothe remainingEthernetLANports

onthe backpaneloftheDI-804HV.

M1LED–willflash

consistentlytoindicate

thattheDI-804HVis

workingproperly.

POWERLED–asolid

lightindicatesaproper

connectiontothe

powersupply.

M2LED–asolidlight

indicatesthatInternet

connectionhasbeen

established.

WANLED–a

solidlightindicates

connectiononthe

WANport. This

LEDblinks during

datatransmission.

LOCALNETWORK

LEDs–asolidlight

ontheportindicatesa

connectiontoan

Ethernetenabled

computeronports1-4.

ThisLEDblinks during

datatransmission.

COMLED–asolid

lightindicatesaproper

connectiontoadial-up

modem.

Whenyou havecompleted the stepsinthisQuick Installation

Guide,yourconnectednetworkshouldlooksimilartothis:

UsingTheSetupWizard

The logonpop-upscreenwillappear.

OpenyourWebbrowserand

type “http://192.168.0.1”intothe

URLaddress box.Thenpressthe

EnterorReturnkey.

Type“admin”forthe usernameand

leavethepasswordfieldblank.

ClickOK

TheSetupWizard(continued)

Onceyou havelogged in,the

Homescreen will appear.

Youwillsee thefollowingscreens

Setup yournewpassword.

Youhavethe optionto

establishapassword.

Click Run Wizard

Click Next

TheSetupWizard(continued)

SelectyourInternet

Connection.Youwill be

promptedtoselectthe type of

Internetconnectionforyour

router.

Click Next

Choose yourtimezonefrom

the drop downlist.

Click Next

If youareunsureofwhichsetting toselect,

pleasecontactyourInternetServiceProvider.

SelectOthersonlyifyouusePPTPinEuropeorBig

PondCableinAustralia.

TheSetupWizard(continued)

If yourISPrequiresaStaticIP

Address,andthisoptionis

selected,then thisscreen will

appear:

Enterthe IPaddress information

originallyprovidedtoyoubyyour

ISP.You willneed tocomplete

allthe requiredfields.

Click Next

If youselected DynamicIP

Address,thisscreenwillappear:

(UsedmainlyforCableInternet

service.)

WhatisaMAC address?Each

networkadapterhasadiscrete

MediaAccess Control(MAC)

address.Notethatsomecomputers

and peripheralsmayalready

include built-innetworkadapters.

Click the “CloneMACAddress”

buttontoautomaticallycopythe

MACaddress ofthe networkadapter

inyourcomputer.You canalso

manuallytype inthe MACaddress.

Click Next

TheSetupWizard(continued)

If yourISP usesPPPoE

(Point-to-PointProtocolover

Ethernet),andthisoptionis

selected,then thisscreen will

appear:(UsedmainlyforDSL

Internetservice.)

Pleasebe suretoremove

anyexisting PPPoEclient

softwareinstalled on your

computers.

Enterinthe usernameand

passwordprovidedtoyouby

yourISP.

Click Next

Configurethissectiononlyif

youhaveananalogdial-up

account. OtherwiseclickNext

toskip.

YourSetupisComplete!

TestInternetConnection.

You willbe returned tothe Hometab.

Foradditionalsettings

orinformation,referto

the Advanced,Tools,

orStatustabsonthe

web-management

interface;ortothe

Manuallocatedonthe

CD.

Thenrelaunchyour

Webbrowser(i.e.,

InternetExploreror

NetscapeNavigator),

tolinktoyourfavorite

Websitetotestyour

Internetconnection.

Click toExit

ClickRestart

Toconnecttothe network,makesurethe networkadapterinyourcomputeris

configuredproperly.Here’showtoconfigurethe networkadaptertoobtainanIP

address automaticallyforthe DI-804HVBroadbandRouter.

ForMicrosoftWindowsXP:

GotoStart>rightclickon

MyNetworkPlaces >

selectProperties >Double-clickon

the NetworkConnection associated

withthe Ethernetadapter

(i.e.,D-LinkDFE-530TX+).

APPENDIX(continued)

Restartyour

computer

ClickOK

Click InternetProtocol(TCP/IP)

ClickProperties

SelectObtainanIPaddress

automatically
