D-Link DI-524UP Manuel utilisateur

Contents

Package Contents..........................................................................................................iv

Introduction.....................................................................................................................1

Connections ....................................................................................................................2

LEDs.................................................................................................................................3

Features...........................................................................................................................4

Wireless Basics...............................................................................................................6

Standards-Based Technology .....................................................................................7

Installation Considerations...........................................................................................7

Getting Started................................................................................................................8

Using the Configuration Wizard..................................................................................10

Home > Wireless .......................................................................................................11

Home > WAN.............................................................................................................16

Home > LAN..............................................................................................................24

Home > DHCP...........................................................................................................25

Advanced > Virtual Server.........................................................................................26

Advanced > Applications ...........................................................................................29

Advanced > Filters.....................................................................................................30

Advanced > Parental Control.....................................................................................33

Advanced > Firewall ..................................................................................................36

Advanced > DMZ.......................................................................................................38

Advanced > DDNS.....................................................................................................39

Advanced > QoS........................................................................................................41

iii

Advanced > Performance..........................................................................................49

Tools > Admin............................................................................................................52

Tools > Time..............................................................................................................54

Tools > System..........................................................................................................55

Tools > Firmware.......................................................................................................56

Tools > Misc...............................................................................................................58

Tools > Cable Test.....................................................................................................60

Status > Device Info...................................................................................................61

Status > Log...............................................................................................................63

Status > Statistics......................................................................................................65

Status > Wireless Info................................................................................................66

Status > Printer Info...................................................................................................67

Status > Active Session.............................................................................................68

Help............................................................................................................................70

Technical Specifications..............................................................................................71

Appendix........................................................................................................................75

WCN and the Wireless Setup Wizard........................................................................75

Installing a Printer on your DI-524UP for Windows XP.............................................78

Installing a Printer on your DI-524UP for Windows 2000..........................................84

Package Contents

Contents of Package:

•D-Link DI-524UP Wireless Router

•Power Adapter-DC 5V, 2A

•Manual and Warranty on CD

•Quick Installation Guide

•Ethernet Cable (All the DI-524UP’s Ethernet ports are

Auto-MDIX)

Note: Using a power supply with a different voltage rating than the one included with the

DI-524UP will cause damage and void the warranty for this product.

If any of the above items are missing, please contact your reseller.

Introduction

The D-Link DI-524UP Wireless Router is an 802.11b/g high-performance, wireless

router that supports high-speed wireless networking at home, at work or in public

places.

The 802.11g standard is backwards compatible with 802.11b products. This means that

you do not need to change your entire network to maintain connectivity. You may

sacrifice some of 802.11g’s speed when you mix 802.11b and 802.11g devices, but you

will not lose the ability to communicate when you incorporate the 802.11g standard into

your 802.11b network. You may choose to slowly change your network by gradually

replacing the 802.11b devices with 802.11g devices.

In addition to offering faster data transfer speeds when used with other 802.11g

products, the DI-524UP has the newest, strongest, most advanced security features

available today. When used with other 802.11g WPA or WPA2 (WiFi Protected Access)

and 802.1x compatible products in a network with a RADIUS server, the security

features include:

•WPA Wi-Fi Protected Access authorizes and identifies users based on a secret

key that changes automatically at a regular interval. WPA uses TKIP (Temporal

Key Integrity Protocol) to change the temporal key every 10,000 packets (a packet

is a kind of message transmitted over a network.) This insures much greater

security than the standard WEP security. (By contrast, the older WEP encryption

required the keys to be changed manually.)

•WPA2, based on the IEEE 802.1i Wi-Fi certified standard, goes a level beyond

the previous WPA by enhancing security with a new encryption code.

Employing AES (Advanced Encryption Standard), and yet still backwards

compatible with WPA, WPA2 utilizes 802.1X and EAP (Extensible

Authentication Protocol) to verify users on the wireless network using a

Pre-Shared Key. Once all users on the LAN have been authenticated, there can

be a securely encrypted flow of information between all parties on the LAN.

For home users that will not incorporate a RADIUS server in their network, the security for

the DI-524UP, used in conjunction with other 802.11g products, will still be much

stronger than ever before. Utilizing the Pre Shared Key mode of WPA, the DI-524UP will

obtain a new security key every time it connects to the 802.11g network. You only need

to input your encryption information once in the configuration menu. No longer will you

have to manually input a new WEP key frequently to ensure security, with the DI-524UP,

you will automatically receive a new key every time you connect, vastly increasing the

safety of your communications.

The DI-524UP also comes equipped with one USB 1.1 port on the rear panel that

supports printer sharing.

Connections

USB 1.1 Connection

Use this port to

connect your USB

printer.

All Ethernet Ports (WAN and LAN) are auto MDI/MDIX, meaning you can

use either a strai

ht-throu

h or a crossover Ethernet cable.

Auto MDI/MDIX LAN Ports

Connect the Ethernet

cable from computers on

your LAN to these ports.

WAN Port

Connect the Ethernet

cable from your ADSL

modem to this port.

Factory Reset Button

Pressing this button

will restore the router

to its factory default

settings.

Power Adapter

Connect your

5V 2A power

adapter here.

LEDs

Power LED

A solid light

indicates a valid

connection to

the power

supply.

Status LED

A blinking LED

indicates the

DI-524UP is

functioning

properly.

WAN LED

An active LED

indicates a link

has been

established. A

blinking LED

indicates

activity on the

WAN port.

WLAN LED

An active LED indicates

a link has been

established. A blinking

LED indicates activity

on the WLAN

ort.

USB LED

An active LED indicates

a link has been

established. A blinking

LED indicates activity

on the USB port.

LAN LEDs

An active LED indicates

a link has been

established. A blinking

LED indicates activity on

the LAN port.

Features

•Fully compatible with the 802.11g standard to provide a wireless data rate of up

to 54Mbps

•Backwards compatible with the 802.11b standard to provide a wireless data rate

of up to 11 Mbps

•WPA authorizes and identifies users based on a secret key that changes

automatically at a regular interval, for example, TKIP (Temporal Key Integrity

Protocol), in conjunction with a RADIUS server, changes the temporal key every

10,000 packets, ensuring greater security

•Pre Shared Key mode means that the home user, without a RADIUS server, will

obtain a new security key every time the he or she connects to the network,

vastly improving the safety of communications on the network

•New WPA2 enhanced wireless security authenticates using 802.1X and a

Pre-Shared key, and encrypts the data with the AES encryption standard. Wi-Fi

certified, WPA2 is also compatible with WPA and can be used for a large

network or for the SOHO environment

•802.1x Authentication in conjunction with the RADIUS server verifies the identity

of would be clients

•Utilizes OFDM technology (Orthogonal Frequency Division Multiplexing)

•User-friendly configuration and diagnostic utilities

•Operates in the 2.4GHz frequency range

•Connects multiple computers to a Broadband (Cable or DSL) modem to share

the Internet connection

•Advanced Firewall features

•Supports NAT with VPN pass-through, providing added security

•MAC Filtering

•IP Filtering

•URL Filtering

•Domain Blocking

•Scheduling

•DHCP server supported enables all networked computers to automatically

receive IP addresses

•Web-based interface for Managing and Configuring

•Access Control to manage users on the network

•Supports special applications that require multiple connections

•Equipped with four 10/100Mbps Ethernet ports, one WAN port, Auto MDI/MDIX

•Equipped with one USB 1.1 port at the rear of the router used to connect with a

USB printer

•VPN Pass-Through

•DMZ and DDNS functions

•Stateful Packet Inspection for protection against unwanted packets

•Quality of Service (QoS) for prioritizing ports and IP addresses

•Supports IGMP

•Multiple users and administrators with configurable privileges for each

•Intrusion detection for ICMP, SYN, UDP flood, Land, IP spoof, Ping of Death,

Port Scan, Smurf, Steal Fin, Syn with data, Tear Drop, and UDP bomb attacks

•Statistics for all main functions on the router

Wireless Basics

D-Link wireless products are based on industry standards to provide easy-to-use and

compatible high-speed wireless connectivity within your home, business or public

access wireless networks. D-Link wireless products will allow you access to the data

you want, when and where you want it. You will be able to enjoy the freedom that

wireless networking brings.

A WLAN is a cellular computer network that transmits and receives data with radio signals

instead of wires. WLANs are used increasingly in both home and office environments, and

public areas such as airports, coffee shops and universities. Innovative ways to utilize

WLAN technology are helping people to work and communicate more efficiently.

Increased mobility and the absence of cabling and other fixed infrastructure have proven to

be beneficial for many users.

Wireless users can use the same applications they use on a wired network. Wireless

adapter cards used on laptop and desktop systems support the same protocols as

Ethernet adapter cards.

People use wireless LAN technology for many different purposes:

Mobility -Productivity increases when people have access to data in any location

within the operating range of the WLAN. Management decisions based on real-time

information can significantly improve worker efficiency.

Low Implementation Costs –WLANs are easy to set up, manage, change and

relocate. Networks that frequently change can benefit from WLANs ease of

implementation. WLANs can operate in locations where installation of wiring may be

impractical.

Installation and Network Expansion -Installing a WLAN system can be fast and

easy and can eliminate the need to pull cable through walls and ceilings. Wireless

technology allows the network to go where wires cannot go - even outside the home or

office.

Scalability –WLANs can be configured in a variety of topologies to meet the needs

of specific applications and installations. Configurations are easily changed and range

from peer-to-peer networks suitable for a small number of users to larger infrastructure

networks to accommodate hundreds or thousands of users, depending on the number of

wireless devices deployed.

Inexpensive Solution -Wireless network devices are as competitively priced as

conventional Ethernet network devices.

Autres manuels pour DI-524UP

Table des matières

Autres manuels D-Link Routeur réseau

D-Link

D-Link DSL-2520U Manuel utilisateur

D-Link

D-Link DES-1008PA Manuel utilisateur

D-Link

D-Link AC1200 Manuel utilisateur

D-Link

D-Link DES-1016D - Switch Manuel utilisateur

D-Link

D-Link DIR-300S Manuel utilisateur

D-Link

D-Link DWR Series Manuel utilisateur

D-Link

D-Link DWR-712 Manuel utilisateur

D-Link

D-Link DIR-879 Manuel utilisateur

D-Link

D-Link DSL-2540U Manuel utilisateur

D-Link

D-Link M15-2PK Manuel utilisateur

D-Link

D-Link Express Ethernetwork DI-704P Manuel utilisateur

D-Link

D-Link DES-2108 Manuel utilisateur

D-Link

D-Link DIR-610N+ Manuel utilisateur

D-Link

D-Link Air Premier DAP-2695 Manuel utilisateur

D-Link

D-Link DSR-250N Manuel utilisateur

D-Link

D-Link DSL-2600U Manuel utilisateur

D-Link

D-Link DFL-260 - NetDefend - Security Appliance Manuel utilisateur

D-Link

D-Link DIR-859 Manuel utilisateur

D-Link

D-Link DXN-W224 Manuel utilisateur

D-Link

D-Link DSL-245GR Manuel utilisateur

D-Link

D-Link DES-1016D - Switch Manuel utilisateur

D-Link

D-Link DSR-250 Manuel utilisateur

D-Link

D-Link DSL-2500U Manuel utilisateur

D-Link

D-Link DIR-505 Manuel utilisateur

Manuels Routeur réseau populaires d'autres marques

Allnet

Allnet ALL0333AU Manuel utilisateur

HomeSeer

HomeSeer HT-SEL Manuel utilisateur

Sercomm

Sercomm Genesis OC3505D Manuel utilisateur

Billion

Billion BIPAC 5102 Series Manuel utilisateur

TP-Link

TP-Link TD-8817 Manuel utilisateur

Motorola

Motorola MR1900 Manuel utilisateur

Digi

Digi IX14 Manuel utilisateur

Cisco

Cisco NCS 540 Manuel

XAVi

XAVi X8821e Manuel utilisateur

BEC

BEC 6200WZL Manuel utilisateur

MikroTik

MikroTik hAP ac3 Series Manuel utilisateur

Korenix

Korenix JetNet 5428G Series Manuel utilisateur

NETGEAR

NETGEAR FS526T - Switch Manuel utilisateur

Korenix

Korenix JetNet 5710G Series Manuel utilisateur

Automated Logic

Automated Logic ZN551 Manuel du propriétaire

Cisco

Cisco ASR 1000 Series Manuel de l'opérateur

EnGenius

EnGenius ESR-9710 Manuel utilisateur

Cisco

Cisco 805 Series Instructions d'utilisation et de sécurité
