D-Link DES-1316K Manuel utilisateur

D-Link DES-1316

Web-Smart 8-Port 10/100Mbps Ethernet Switch with 8

10/100Mbps 802.3af Power Over Ethernet Ports

Manual

First edition

Building Networks for People

FCC Warning

This equipment has been tested and found to comply with the limits

for a Class A digital device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable protection against

harmful interference when the equipment is operated in a commercial

environment. This equipment generates, uses, and can radiate radio

frequency energy and, if not installed and used in accordance with this

manual, may cause harmful interference to radio communications.

Operation of this equipment in a residential area is likely to cause

harmful interference in which case the user will be required to correct

the interference at his own expense.

CE Mark Warning

This is a Class A product. In a domestic environment, this product

may cause radio interference in which case the user may be required

to take adequate measures.

Warnung!

Dies ist ein Produkt der Klasse A. Im Wohnbereich kann dieses

Produkt Funkstoerungen verursachen. In diesem Fall kann vom

Benutzer verlangt werden, angemessene Massnahmen zu ergreifen.

Precaución!

Este es un producto de Clase A. En un entorno doméstico, puede

causar interferencias de radio, en cuyo case, puede requerirse al

usuario para que adopte las medidas adecuadas.

Attention!

Ceci est un produit de classe A. Dans un environnement domestique,

ce produit pourrait causer des interférences radio, auquel cas

l`utilisateur devrait prendre les mesures adéquates.

Attenzione!

Il presente prodotto appartiene alla classe A. Se utilizzato in ambiente

domestico il prodotto può causare interferenze radio, nel cui caso è

possibile che l`utente debba assumere provvedimenti adeguati.

VCCI Warning

BSMI Warning

TABLE OF CONTENTS

About This Guide...........................................................................................6

Purpose........................................................................................................6

Terms/Usage...............................................................................................6

Introduction.....................................................................................................7

Fast Ethernet Technology.........................................................................7

Switching Technology..............................................................................7

VLAN (Virtual Local Area Network)....................................................8

Power over Ethernet (PoE).......................................................................9

Features........................................................................................................9

Unpacking and Installation.........................................................................11

Unpacking.................................................................................................11

Installation.................................................................................................11

Rack Mounting.........................................................................................12

Connecting Network Cable ....................................................................13

AC Power..................................................................................................13

Identifying External Components.............................................................14

Front Panel................................................................................................14

Rear Panel.................................................................................................15

Understanding LED Indicators..................................................................16

Power and CPU LEDs.............................................................................16

Ports 1~8 PoE portstatus LEDs............................................................16

Ports 9~16 Ethernet port status LEDs ..................................................17

Configuration................................................................................................18

Installing the Web Management Utility...............................................18

Discovery List..........................................................................................20

Monitor List..............................................................................................20

Device Setting..........................................................................................22

Toolbar.......................................................................................................25

Configuring the Switch...........................................................................26

Setup Menu...............................................................................................29

Configuring Setup Setting......................................................................30

Port Settings.........................................................................................30

VLAN Settings (Virtual Local Area Network)..............................32

Trunk Setting .......................................................................................33

Mirror Setting ......................................................................................34

PoE Setting...........................................................................................35

Device Status.......................................................................................36

Statistic..................................................................................................37

System Setting.....................................................................................39

Trap Setting..........................................................................................40

Set Password........................................................................................41

Backup Setting.....................................................................................42

Reset Setting........................................................................................43

Logout........................................................................................................43

Technical Specifications.............................................................................44

ABOUT THIS GUIDE

Congratulations on your purchase of the 8-Port 10/100Mbps Ethernet

Web Smart Switch with 8-Port PoE. This Switch integrates 100Mbps

Fast Ethernet and 10Mbps Ethernet network capabilities in a highly

flexible package. Since this Switch’s Port-1 to Port-8 are Power over

Ethernet (PoE) ports, it will automatically detect the presence of IEEE

802.3af-compliant devices and will provide power through Port-1 to

Port-8. The Switch provides 15.4Watts per port and can be connected

to WLAN access point, IP phone, video camera,and other PD devices.

The Switch will automatically detect the network appliance’s

requirements, and the Switch will supply the requiredpower current to

each appliance.

Purpose

This guide discusses how to install your Web-Smart16-Port

10/100Mbps Ethernet Switch.

Terms/Usage

In this guide, the term “Switch” (first letter upper case) refers to your

Web-Smart 8-Port 10/100Mbps Ethernet Web-Smart Switch with 8

10/100Mbps PoE ports and “switch” (first letter lower case) refers to

other Ethernet switches.

INTRODUCTION

This chapter describes the features of the Web Smart Switchand some

background information about Ethernet/Fast Ethernet switching

technology.

Fast Ethernet Technology

The growing importance of LANs and the increasing complexity of

desktop computing applications are fueling the need for high

performance networks. A number of high-speed LAN technologies

have been proposed to provide greater bandwidth and improve

client/server response times. Among them, 100BASE-T (Fast Ethernet)

provides a non-disruptive, smooth evolution from the current

10BASE-T technology. The non-disruptive and smooth evolution

nature, and the dominating potential market base, virtually guarantees

cost-effective and high performance Fast Ethernet solutions.

100Mbps Fast Ethernet is a standard specified by the IEEE 802.3

LAN committee. It is an extension of the 10Mbps Ethernet standard

with the ability to transmit and receive data at 100Mbps, while

maintaining the CSMA/CD Ethernet protocol. Since the 100Mbps

Fast Ethernet is compatible with all other 10Mbps Ethernet

environments, it provides a straightforward upgrade and takes

advantage of the existing investment in hardware, software, and

personnel training.

Switching Technology

Another approach to pushing beyond the limits of Ethernet technology

is the development of switching technology. A switch bridges

Ethernet packets at the MAC address level of the Ethernet protocol

transmitting among connected Ethernet or Fast Ethernet LAN

segments.

Switching is a cost-effective way of increasing the total network

capacity available to users on a local area network. A switch increases

capacity and decreases network loading by dividing a local area

network into different segments, which do not compete with each

other for network transmission capacity.

The switch acts as a high-speed selective bridge between the

individual segments. The switch, without interfering with any other

segments, automatically forwards traffic that needs to go from one

segment to another. By doing this the total network capacity is

multiplied, while still maintaining the same network cabling and

adapter cards.

Switching LAN technology is a marked improvement over the

previous generation of network bridges, which were characterized by

higher latencies. Routers have also been used to segment local area

networks, but the cost of a router, the setup and maintenance required

make routers relatively impractical. Today switches are an ideal

solution to most kinds of local area network congestion problems.

VLAN (Virtual Local Area Network)

A VLAN is a group of end-stations that are not constrained by their

physical location and can communicate as if a common broadcast

domain, a LAN. The primary utility of using VLAN is to reduce

latency and the need for routers, using faster switching instead. Other

VLAN utilities include:

Security:Security is increased with the reduction of opportunity in

eavesdropping on a broadcast network because data will be switched

to only those confidential users within the VLAN.

Cost Reduction:A VLAN can be used to create multiple broadcast

domains, thus eliminating the need of expensive routers.

802.1Q VLAN:The VLAN tagging option is a standard set by the

IEEE to facilitate the spanning of VLANs across multiple switches.

(Reference: IEEE Std 802.1Q-1998 Virtual Bridged Local Area

Networks.)

Power over Ethernet (PoE)

Power over Ethernet (PoE) integrates power and data onto one single

cabling infrastructure, eliminating the need to have AC power

available at all locations.

Power and Data are integrated onto the same cable. Supporting

category 5/5e up to 100 Meters, PoE will provide power to PoE

compatible device, such as IP telephones, wireless LAN access points,

and IP security cameras.

PoE is already widely adopted in the market, saving up to 50% of

overall installation costs by eliminating the need to install separate

electrical wiring and power outlets.

Features

u8×10/100Mbps Auto-negotiation Fast Ethernet RJ45 ports with 8-

port PoE function (port-1 ~ port-8)

uCompliant with 802.3af specification

uSupports PoE power maximum 15.4W for each PoE port

uSupports PoE Powered Device (PD) classificationidentify

uEach port supportsauto MDI/MDIX, so there is no need to use

cross-over cables or an up-link port

uFull-/half-duplex transfer mode for each port

uWire speed reception and transmission

uStore-and-Forward switching scheme capability to support rate

adaptation and ensure data integrity

uUp to 4K unicast addresses entities per device, self-learning, and

table aging

u512KBytes packet buffer

uSupports IEEE 802.3x flow control for full-duplexmode ports

uSupports Back-pressure flow control for half-duplexmode ports

uSupports 802.1Q VLAN

uSupports Port based Trunking

uSupports Port-mirroring

uSupports Port-settingsfor Speed/Duplex, Flow control and Port

based QoS (Quality of Service)

uEasy configuration via Web Browser

uEasy setting via Web Management Utility

uStandard 19” Rack-mount size

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels D-Link Routeur réseau

D-Link

D-Link Xtreme N L7-N-R2000 Manuel utilisateur

D-Link

D-Link DSL-520B Manuel utilisateur

D-Link

D-Link DSL-124 Manuel utilisateur

D-Link

D-Link DSL-2500U Manuel utilisateur

D-Link

D-Link DSR-250V2 Manuel utilisateur

D-Link

D-Link DI-300 series Manuel utilisateur

D-Link

D-Link DIR-850L Instructions d'utilisation et de sécurité

D-Link

D-Link DIR-605L Manuel utilisateur

D-Link

D-Link SharePort DIR-825 Manuel utilisateur

D-Link

D-Link DSL-2750U Manuel utilisateur

D-Link

D-Link AirPlus DWL-810+ Manuel utilisateur

D-Link

D-Link 790069450846 Manuel utilisateur

D-Link

D-Link DSL-2875AL Manuel utilisateur

D-Link

D-Link DIR-120 Manuel utilisateur

D-Link

D-Link xtreme n duo dap-1522 Manuel utilisateur

D-Link

D-Link DSL-2750E Manuel utilisateur

D-Link

D-Link DFL-260 - NetDefend - Security Appliance Manuel utilisateur

D-Link

D-Link DSL-224 Manuel utilisateur

D-Link

D-Link DGS-1210-12TS/ME Manuel utilisateur

D-Link

D-Link DIR-300 - Wireless G Router Manuel utilisateur

D-Link

D-Link Verizon DSL-2750B Manuel utilisateur

D-Link

D-Link DIR-875 Manuel utilisateur

D-Link

D-Link DIR-615+ Manuel utilisateur

D-Link

D-Link DIR-853 Manuel utilisateur

Manuels Routeur réseau populaires d'autres marques

Allnet

Allnet ALL0333AU Manuel utilisateur

HomeSeer

HomeSeer HT-SEL Manuel utilisateur

Sercomm

Sercomm Genesis OC3505D Manuel utilisateur

Billion

Billion BIPAC 5102 Series Manuel utilisateur

TP-Link

TP-Link TD-8817 Manuel utilisateur

Motorola

Motorola MR1900 Manuel utilisateur

Digi

Digi IX14 Manuel utilisateur

Cisco

Cisco NCS 540 Manuel

XAVi

XAVi X8821e Manuel utilisateur

BEC

BEC 6200WZL Manuel utilisateur

MikroTik

MikroTik hAP ac3 Series Manuel utilisateur

Korenix

Korenix JetNet 5428G Series Manuel utilisateur

NETGEAR

NETGEAR FS526T - Switch Manuel utilisateur

Korenix

Korenix JetNet 5710G Series Manuel utilisateur

Automated Logic

Automated Logic ZN551 Manuel du propriétaire

Cisco

Cisco ASR 1000 Series Manuel de l'opérateur

EnGenius

EnGenius ESR-9710 Manuel utilisateur

Cisco

Cisco 805 Series Instructions d'utilisation et de sécurité
