D-Link DPH-80 Manuel utilisateur
Manual
Building Networks for People
D-Link DPH-80
IPPhone
Version 1.10
2
Contents
PackageContents ................................................................................3
Introduction............................................................................................4
Features andBenefits ...........................................................................5
GettingStarted......................................................................................6
UsingMedia GatewayControlProtocol ...............................................11
UsingSession InitiatedProtocol..........................................................35
UsingH.323 Protocol ..........................................................................61
DPH-80New FirmwareDownload Procedure .....................................87
ConfigurationUpload andDownload ...................................................90
SIPand H.323PhoneBook ................................................................93
TechnicalSpecifications ......................................................................95
Warranty..............................................................................................97
Registration ......................................................................................100
ContactingTechnical Support ............................................................101
3
Package Contents
Operation Requirements:
Contents of Package:
D-Link DPH-80 IP Phone
Handset
Handset cord
Power adapter (9VDC/ 1A)
If any of the above items are missing, please contact your reseller.
Local power outlet
Internet connection (via ISP)
RJ-45 Ethernet Cable
4
Introduction
The D-Link DPH-80 is a fully featured Ethernet business phone that allows
bothbusinessandresidentialcustomerstobenefitfromIPTelephonyservices.
It reduces costs by receiving local and long distance voice services and data
services over a single network connection.
ThiseasytouseIPPhone simply plugs rightinto the local areanetwork through
a standard RJ-45 interface. The DPH-80 utilizes 10/100BASE-TX for Ethernet
connectivity and supports telephone network features such as Call Redial. In
addition, it provides access to a host of features for business applications,
including hold, mute and one-touch dialing.
5
Features and Benefits
Designed for versatility and performance, the DPH-80 IP Phone provides the
following features:
IP address assignment using DHCP (Dynamic Host Configuration
Protocol), PPPoE, or static configuration
QoS support to ensure voice quality
Adaptive jitter buffer for a smooth voice reception
DTMFtonegeneration
Lost packet recovery ability for improved voice quality
Adjustable speaker/ringer volume control
Remote software update support
Easy to install
One-touch dialing (Note: this feature is not a speakerphone. It allows you
todial a number withoutusingthe handset. Once thepartyyou are calling
picks up, you must use the handset to talk.)
Callhold
Last number redial
Mute
Call transfer
Call control protocols: H.323, SIP, MGCP
Voice compression: G.711 (A-Law/W-Law), G.723.1, G729A/AB
WAN connection: through 10/100 Mpbs Fast Ethernet port
H.450 Call transfer/Call on hold (for H.323)
6
Getting Started
Overview
The D-Link DPH-80 is a low cost, simple to use, and extremely versatile IP
phone with the look and feel of a normal PSTN phone.
TheD-Link IPPhonecanoperateunderanyofthethreemainInternettelephony
protocols:Media GatewayControlProtocol (MGCP);SessionInitiation Protocol
(SIP); and the H.323 protocol. These protocols are used for signaling,
maintaining, and tearing down voice calls. The D-Link IP phone allows voice
data to be carried over the same path used by your computer for the Internet or
LocalAreaNetwork(LAN).
TheD-Link DPH-80 phoneis easy toinstalland supports plugand play features
of the IP network. Out of the box, your IP phone will work in any of the above-
mentionedthree protocol infrastructures with minimalconfiguration.Advanced,
customizedconfigurationiseasily achievedthroughaweb-browser configuration
utility.
D-LinkIPphonessupportremotemaintenance,allowingsoftwaretobeupgraded
remotely for new features and any bug fixes. The DPH-80 supports a unique
remote diagnostic feature to monitor phone functions and performance.
Installation
The following are steps will install and power-on your DPH-80 IP phone:
Connect the RJ-45 Ethernet cable from the DPH-80 to a LAN jack.
Plug the power adapter into the appropriate wall outlet.
Plug the power adapter plug into the power jack.
7
Getting Started
Configuring the IP Address
In order to use a Web browser to configure the DPH-80 IP phone, you must
make sure the phone has a valid Ethernet connection to a PC or LAN via its
Ethernet port. We recommend using a recent version of any widely used
browser such as Netscape or Internet Explorer. The browser must have
JavaScriptenabled.The following illustrations use Windows 2000 and Internet
Explorer 5.5.
The DPH-80 comes with a default IP address of 10.1.1.80. Make sure that the
IP address on your Ethernet card is in the same subnet as the DPH-80. You
can do this by changing the IP address of the PC as shown.
In Windows, go to Start/Settings/Control Panel/Network and Dial-
Up Connections.
Right-click on LocalArea Connection (LAN).
Click on Properties.
8
Getting Started
Configuring the IPAddress
In the General Tab, click on Internet Protocol (TCP/IP).
Click on Properties.
9
Getting Started
Configuring the IPAddress
Clickon Use the following IP address, and entera value inthe10.1.1.xx
range. (Do not use the IP address 10.1.1.80; this address is already in
use by the DPH-80 as a default address.) Change your IP address on
your Ethernet adapter to 10.1.1.x, where x is something other than 80.
Makesurethe subnet mask and defaultgatewaymatch the DPH-80. This
should allow you to use the Web interface to configure the IP phone.
Click OK.
Open Internet Explorer. Click on Tools/Internet Options/Connections
Click on LAN Settings.
10
Getting Started
Configuring the IPAddress
Make sure Use a proxy server is disabled.
Click OK.
Advance Configuration
The DPH-80 is highly versatile and can be configured to operate in any of the
three main Internet telephony protocols – MCGP, SIP, and H.323.
The following sections contain configuration details, instructions for use, and a
troubleshooting guide for each protocol.
Loading Factory Defaults
If it is required to reset the DPH-80 and start with default configuration param-
eters, you can do so by pressing ‘*789*#’ while the phone is in the idle state.
The phone will restart in a few seconds with the default parameters. The de-
fault configuration password is ‘12345’. The phone’s Internet access and call-
ing card information must be configured again before it can be used.
Note: Upon pressing ‘*789*#’, the DPH-70 will ask for confirmation.
