D-Link DCH-M225 Manuel utilisateur

MUSIC EVERYWHERE

DCH-M225

QUICK

INSTALLATION

GUIDE

INSTALLATIONS-ANLEITUNG

GUIDE D’INSTALLATION

GUÍA DE INSTALACIÓN

GUIDA DI INSTALLAZIONE

INSTALLATIEHANDLEIDING

INSTRUKCJA INSTALACJI

INSTALAČNÍ PŘÍRUČKA

TELEPÍTÉSI SEGÉDLET

INSTALLASJONSVEILEDNING

INSTALLATIONSVEJLEDNING

ASENNUSOPAS

INSTALLATIONSGUIDE

GUIA DE INSTALAÇÃO

ΟΔΗΓΟΣ ΓΡΗΓΟΡΗΣ ΕΓΚΑΤΑ

VODIČ ZA BRZU INSTALACIJU

KRATKA NAVODILA ZA UPORABO

GHID DE INSTALARE RAPIDĂ

DCH-M225 3

ENGLISH

CONTENTS OF

PACKAGING

MUSIC EVERYWHERE

DCH-M225

WI-FI CONFIGURATION CARD

If any of these items are missing from your packaging,

contact your reseller.

For the full product manual, please go to

http://www.dlink.com

DCH-M225

ENGLISH

INTRODUCTION

Music Everywhere (DCH-M225) allows you to play music from your smartphone,

tablet or computer wirelessly to your speakers. Simply plug in your speaker jack into

Music Everywhere (DCH-M225) and connect it to your Wi-Fi network. It also has a Wi-

Fi extender built-in to help you eliminate any Wi-Fi black spots in your home. If you

do not have access to a Wi-Fi network, you can also use the direct connect mode to

play music wirelessly, which connects your smart phone, tablet or computer directly to

Music Everywhere.

Play your music from your smartphone, tablet or computer wirelessly to your speakers as

well as extend your Wi-Fi coverage.

Smartphone

Internet Modem

Computer

Router

DCH-M225

Tablet

Speaker

Smartphone

Computer

DCH-M225

Tablet

Speaker

Or play music wirelessly directly from your smartphone, tablet or computer to Music

Everywhere without a Wi-Fi network.

CONNECT TO YOUR WI-FI NETWORK

CONNECT DIRECTLY TO MUSIC EVERYWHERE

DCH-M225 5

ENGLISH

PRODUCT SETUP

SETUP

SELECT YOUR METHOD

There are 3 easy ways to set up Music Everywhere.

1. Download the QRS Mobile app and follow the step by step instructions

2. One button secure connection using Wi-Fi Protected Setup (WPS)

3. Or you can log into Music Everywhere's web conguration using an Internet

browser

1. SET UP MUSIC EVERYWHERE WITH QRS MOBILE APP

First, download and install the QRS Mobile app.

This is available from the Apple App Store or

Google Play. Simply scan the corresponding QR

code below.

Before launching the QRS Mobile app, you must rst connect your smartphone or

tablet wirelessly to Music Everywhere. Music Everywhere's Wi-Fi network name

(SSID) and Wi-Fi password can be found on the Wi-Fi Conguration Card provided

and also on the device label.

Make sure the Wi-Fi functionality on your smartphone or tablet is ON. From your

device's wireless connection settings, search for and select Music Everywhere's Wi-

Fi network name (SSID). Enter the Wi-Fi password to connect to Music Everywhere.

If you are unsure how to do this, please refer to your smartphone or tablet manual for

more information.

QRS

If you are planning to use Music Everywhere without a Wi-Fi network, after you

have connected your smartphone, tablet or computer to Music Everywhere's

Wi-Fi, please go directly to the "PLAYING YOUR MUSIC WIRELESSLY TO

YOUR SPEAKERS" section of this quick installation guide to continue set up.

DIRECT CONNECT MODE

DCH-M225

ENGLISH

PRODUCT SETUP

SETUP

Once your smartphone or tablet is connected to

Music Everywhere, launch the QRS Mobile app.

The Setup Wizard will rst search and list all the

Wi-Fi networks available. Select your home Wi-Fi

network and enter your W-Fi network password.

Music Everywhere is now connected to your home

Wi-Fi network.

For the Wi-Fi extender function, you now have the

option to either keep the existing Wi-Fi network

name (SSID) and password for the extended Wi-

Fi network, or enter a new Wi-Fi network name

(SSID) and password. You can also choose

to create an administrator password to secure

access to Music Everywhere's web-based

configuration. Note: If you choose to change

the SSID and password, it is recommended that

you make a record of this information for future

reference.

A summary of the network settings will then be

displayed. Once you are satised, click Save, and

the setup wizard will reboot Music Everywhere for

the new settings to take effect. Music Everywhere

is now ready for you to wirelessly stream music

to your speakers as well as extending your

existing Wi-Fi network.

DCH-M225 7

ENGLISH

2. SET UP MUSIC EVERYWHERE USING Wi-Fi PROTECTED SETUP (WPS)

NOTE: In order to use the one touch WPS secure wireless connection, please make

sure that your home Wi-Fi router supports WPS and has the corresponding WPS

button.

PRODUCT SETUP

SETUP

Plug Music Everywhere into a wall outlet and wait until

the power LED is blinking amber. Push the WPS button

on your home Wi-Fi router (please refer to your home

Wi-Fi router's manual if necessary) and then push the

WPS button on Music Everywhere within 120 seconds.

The LED will start to ash green.

Music Everywhere is now ready for you to wirelessly

stream music to your speakers as well as extending

your existing Wi-Fi network. If you are connecting to the

extended wireless network that was set up using WPS,

the extended SSID will have the extension “-EXT” added

to the original SSID and the password will be same as

your existing wireless password.

Please allow up to two minutes for the process to nish.

The LED will turn solid green when Music Everywhere

has connected successfully to your home Wi-Fi network.

3. SET UP MUSIC EVERYWHERE USING WEB CONFIGURATION

Music Everywhere can also be congured using the web conguration. After you have

plugged Music Everywhere into a wall outlet and the power LED is blinking amber,

go to wireless utility on your computer, select and connect to Music Everywhere's Wi-

Fi network and enter the Wi-Fi password (both can be found on the included Wi-Fi

Conguration Card and also on the device label). Then open a web browser and type

http://dlinkap.local. By default, the username is Admin, and the password field

should be left blank. Please refer to the product manual, which can be found on the

enclosed CD, for further information on conguring Music Everywhere using the web

GUI.

DCH-M225

ENGLISH

PLAYING YOUR MUSIC WITH APPLE IOS DEVICES

NOTE: The below guide is for iOS 7. For more information on how to enable AirPlay

on devices using iOS versions earlier than iOS 7, please refer to Apple's support

page.

PRODUCT SETUP

PLAYING YOUR MUSIC WIRELESSLY TO YOUR SPEAKERS

1. Make sure Wi-Fi is turned on for your iOS device and that

your iOS device is connected to the same network as

Music Everywhere.

2. Swipe up from the bottom of your screen to access the

‘Control Center’ function of your device.

3. Tap "AirPlay"

4. Choose Music Everywhere (DCH-M225) from the list of

devices.

5. To choose a song to play, press the home button to

navigate and now navigate to the music App (or another

Airplay enabled music App).

PLAYING YOUR MUSIC WITH ANDROID DEVICES

1. In order to stream music from an Android smartphone or tablet to Music

Everywhere, you will need to download and install an AirPlay or DLNA

streaming capable music app, such as BubbleUPnP or iMediaShare.

2. Make sure Wi-Fi is turned on for your Android device and that your Android

device is connected to the same network as Music Everywhere.

3. For instruction on how to stream music from your Android device to Music

Everywhere, please refer to the app's user's guide.

NOTE: D-Link cannot be held responsible or liable for any direct or consequential

damages resulting from the use of third party applications. For more information

relating to any third party applications, please refer to the app information on Apple

App Store or Google Play, or contact the application developer.

NOTE: Music Everywhere plays music from only one device at a time. To switch

devices, stop the current device before playing music on another device.

DCH-M225 9

ENGLISH

PLAYING YOUR MUSIC WITH WINDOWS MEDIA PLAYER

NOTE: The below guide is for Windows Media Player version 12. For more

information on how to enable the "Play To" function in versions earlier than 12,

please refer to Microsoft's support page.

PRODUCT SETUP

PLAYING YOUR MUSIC WIRELESSLY TO YOUR SPEAKERS

1. Make sure your desktop or laptop computer is connected to the same network

as Music Everywhere.

2. Launch Windows Media Player and make sure it's showing the "Play" tab on

the right hand side

3. Select music you want to play if you haven't done so already.

4. Click the "Play To" button at the top of the "Play" tab and select

"DCH-M225".

5. In the "Play To" dialog box, use the playback controls to play, pause, or stop

the media stream, and to change to the next or previous item in the list.

DCH-M225

ENGLISH

PLAYING YOUR MUSIC WITH ITUNES

NOTE: The below guide is for iTunes version 11. For more information on how to

enable the "AirPlay" function in versions earlier than 11, please refer to Apple's

support page.

PRODUCT SETUP

PLAYING YOUR MUSIC WIRELESSLY TO YOUR SPEAKERS

1. Make sure your desktop or laptop computer is connected to the same network

as Music Everywhere.

2. Launch iTunes and select the music you want to play if you haven't done so

already.

3. Click the "AirPlay" icon and select "DCH-M225".
