D-Link DAP-1320 Manuel

-1-

FAQ : How To Connect Range Extender to existing router via WPS setup Version 1.00

Technical Support Setup Procedure

FAQ : How To connect Range Extender to existing router via

WPS Setup

Release date : 1/06/2015

Model Support : DAP-1320

H/W:A1 , B1

S/W:1.x , 2.x

-2-

FAQ : How To Connect Range Extender to existing router via WPS setup Version 1.00

Technical Support Setup Procedure

*Firmware 1.10 and higher

DAP-1320 Push Button WPS Configuration

Note : DAP-1320 WPS router/access point 



1 : DAP-1320 

Note : 

-3-

FAQ : How To Connect Range Extender to existing router via WPS setup Version 1.00

-4-

FAQ : How To Connect Range Extender to existing router via WPS setup Version 1.00

2 : WPS router/AP 5-7 

3 : WPS DAP-1320 2LED 

LED 

-5-

FAQ : How To Connect Range Extender to existing router via WPS setup Version 1.00

4 : 

Note: DAP-1320 



-6-

FAQ : How To Connect Range Extender to existing router via WPS setup Version 1.00

5 : DAP-1320 

SSID configuration note 



-7-

FAQ : How To Connect Range Extender to existing router via WPS setup Version 1.00

Technical Support Setup Procedure

*Firmware 1.10 and higher

DAP-1320 Push Button WPS Configuration

Note: In order to setup the DAP-1320 using WPS, you must have a WPS compatible

router/access point

Step 1: Plug in the DAP-1320

Note: The light should turn red and then start blinking orange

-8-

FAQ : How To Connect Range Extender to existing router via WPS setup Version 1.00

Step 2: Press the WPS button on your router/AP (usually for about 5-7 seconds)

Step 3: Press and hold the WPS button on the DAP-1320 for 2 seconds. The LED should start to blink

green. Once it makes connection with your router the LED will stop flashing and turn solid GREEN.

-9-

FAQ : How To Connect Range Extender to existing router via WPS setup Version 1.00

Step 4: Unplug and place the DAP-1320 approx half way between the router and the desired

connection area.

Note: Correct placement of the DAP-1320 is very important. It needs to be positioned in an area

that still receives good signal from your router. A good starting point is approx half way between

the router and the area you want to get signal to.

Step 5: To connect wireless to the DAP-1320, Scan for available wireless networks on your wireless

device and connect using the Wi-Fi Network Name (SSID) and Wi-Fi Password information located on

your configuration note.

-10-

FAQ : How To Connect Range Extender to existing router via WPS setup Version 1.00

Setup is Complete.
