D-Link DWL-AG132 Manuel utilisateur
DWL-AG700AP Install Guide
D-Link Systems, Inc. 2
DWL-AG700AP Install Guide Contacting Technical Support
DWL-AG700AP
Install Guide
Contacting Technical Support
DWL-AG132 Install Guide System Requirements
System Requirements
Minimum System Requirements:
Computers with Windows XP/2000 operating system with
an available USB 2.0 port
Internet Explorer version 6.0 or Netscape Navigator
version 7.0 and above
Manual on CD
Cradle
D-Link AirPremier AG DWL-AG132
Wireless AG USB 2.0 Adapter
Package Contents
DWL-AG700AP Install Guide
Connecting to your networkDWL-AG132 Install Guide Installing the Drivers
D-Link Systems, Inc.
3
DWL-AG
132
Install Guide
Installing the Drivers
DWL-AG132 Install GuideInstalling the Drivers
Installing the Drivers
The step-by-step instructions that follow are shown in Windows XP.
The steps and screens are similar for the other Windows operating
systems.
Turn on the computer and insert the D-Link AirPremier AG®
DWL-AG132 Driver CD in the CD-ROM drive. The installation
Wizard will automatically appear.
Installing the Drivers
Do NOT install the DWL-AG132 Wireless AG USB Adapter into
your computer before installing the driver software from the D-Link
CD!
Click Install Drivers
Click Next
Click Next
If the Installation Wizard does
not automatically start on your
computer, type “D:\Drivers\setup.
exe.” If the Wizard does start,
proceed to the next screen.
Installing the Drivers
4
DWL-AG700APUsing the Setup Wizard
D-Link Systems, Inc. 4
DWL-AG700AP
Using the Setup Wizard
DWL-AG132 Install GuideInstalling the Drivers
Installing the Drivers (continued)
Click Next
Click Finish
Click ‘Yes, I want to
restart my computer
now.’
You have completed the installation of the drivers!
DWL-AG132 Install GuideConnecting the DWL-AG132
D-Link Systems, Inc.5
Begin by pressing
down on the cover
with your thumb.
USB Port - used
to connect the
DWL-AG132 to your
computer.
Link/Power LED
Link - indicates that
the DWL-AG132 is
properly installed.
Activity - blinks
when data is being
transmitted through the
wireless connection.
Remove the protective covering from the DWL-AG132.
Pull the cover away from
the DWL-AG132.
Optional: If desired or needed,
attach the cradle between the
DWL-AG132 and your computer.
Insert the DWL-AG132 into
an available USB port on
your computer.
Connecting the DWL-AG132
6
DWL-AG700APUsing the Setup Wizard
D-Link Systems, Inc. 6
DWL-AG700AP
Using the Setup Wizard
DWL-AG132 Install GuideThe Found New Hardware Wizard
Click Continue
Anyway.
The Found New Hardware Wizard
Click Next
Select Install the
software automatically
(Recommended).
After connecting the DWL-AG132, the Found New Hardware
Wizard (Windows XP) screen will appear:
DWL-AG132The Found New Hardware Wizard
D-Link Systems, Inc.
7
DWL-AG
132
The Found New Hardware Wizard
DWL-AG132 Install GuideThe Found New Hardware Wizard
Click Next
Select Install the
software automatically
(Recommended).
Click Continue
Anyway.
Click Finish to complete
the installation.
D-Link AirPremier AG DWL-AG132 USB Adapter
DWL-AG132Your Installation is Complete!
D-Link Systems, Inc. 8
DWL-AG
132
Your Installation is Complete!
DWL-AG132 Install GuideYour Installation is Complete!
If the utility icon does
not appear, double-click
the shortcut icon that
has appeared on your
desktop.
After completing the Found New Hardware Wizard, the D-Link
AirPremier AG DWL-AG132 Confi guration Utility will automatically
start and the utility icon will appear in the bottom right hand corner of
the desktop screen (system tray). If this icon appears GREEN, then
you have successfully installed the DWL-AG132, are connected to
a wireless network, and are ready to communicate!
Your Installation is Complete!
Double-click the utility icon
to use the configuration
utility.
DWL-AG132 Install Guide Appendix A
For Windows XP, if you wish to use the AirPremier AG utility, please
do the following:
D-Link Systems, Inc.
9
Using the Utility in Windows XP
Click the XP networking
icon to use the Zero
Confi guration Wireless
Settings.
Click Advanced.
Uncheck Use
Windows to
confi gure my
wireless network
settings.
Click OK.
DWL-AG132 Install Guide Appendix B
D-Link Systems, Inc. 10
Using the AirPremier AG Utility
Status: Displays the MAC Address of the access point that is
associated with the DWL-AG132.
SSID: Displays the Service Set Indentifi er assigned to the wireless
network.
Frequency: Displays the current frequency used by the adapter.
Wireless Mode: Displays the wireless mode. The default is
Infrastructure.
Encryption: Displays whether Encryption is enabled or disabled.
Connection Info: Displays the adapter’s connectivity to the
network.
Tx Rate: Displays the current data transmission rate.
