D-Link DWA-192 Manuel utilisateur

DWA-192

Quick Install Guide

AC1900 Wi-Fi USB 3.0 Adapter

If any of the above items are missing, please contact your reseller.

Minimum Requirements

DWA-192 AC1900 Wi-Fi USB 3.0 Adapter

USB 3.0 Cable

Package Contents

Quick Install Guide

CD with drivers and documentation

• A desktop or laptop computer with an available USB port*

• Windows® 8 or 7 (32/64-bit)

• 300MHz processor and at least 64MB of RAM

• CD-ROM drive

• An 802.11ac or 802.11n wireless network

* For best performance, connect to a USB 3.0 port.

ENGLISH

Product Overview

USB 3.0 Connector

LED Ring

WPS Button

LED On/O

Button

LED Ring

A solid blue light indicates a proper connection to a

wireless network. This LED will blink if it is not connected

to a wireless network.

LED On/O

Button Press to turn the LED on or o.

USB 3.0

Connector

Connect the supplied USB 3.0 cable here and the other

end to your computer.

WPS Button

Press to start the WPS process. You will need to press

the WPS button on your wireless router within two

minutes. The light will turn solid blue when successfully

connected.

Before You Begin

Before installing your new D-Link wireless adapter, please verify the following:

• Remove any previous installations of wireless adapters.

• Uninstall any 3rd party wireless utility software.

• Disable any built-in wireless adapters.

• Verify the settings such as the wireless network name (SSID) and security settings

of the network(s) you want to connect to.

Do NOT plug the adapter into your computer before installing the

drivers.

Insert the DWA-192 CD in the CD-ROM drive. When the autorun screen

appears, click Setup.

Note: If the CD Autorun function does not automatically start on your computer,

go to Start > Run. In the run box type “D:\autorun.exe” (where D: represents the

drive letter of your CD-ROM drive) and click OK.

If your computer does not have a CD-ROM drive, you can download the drivers

from support.dlink.com.

Installation

2Select your language and click Next to continue.

ENGLISH

3When the welcome screen appears, click Next to continue.

4Select the installation location and click Next to continue.

5Connect the USB 3.0 cable to the adapter and then plug the other end into

an available USB port on your computer. Click Next to continue.

Note: The LED will not turn on until the drivers are installed.

6Allow 2-3 minutes to install. Ignore any Windows installation bubbles in

the lower right-hand corner. Once nished, click Finish to complete the

installation. The LED on the adapter should now turn on and blink.

ENGLISH

7You can now connect to your wireless network by using one of the two

methods shown below:

When your adapter has successfully connected to a wireless network, the

LED will turn solid blue.

A. Open your wireless utility and select the network you want to connect

to. If the network is secure you will be prompted to enter the Wi-Fi

password.

B. If your wireless router or access point supports WPS, press the WPS

button on the back of the adapter and then initiateWPS on your wireless

router or access point within two minutes.

WPS Button

Technical Support

This guide is for initial setup. Refer to the user manual to learn more or

visit our support website:

http://support.dlink.com/DWA-192

USA

http://support.dlink.ca/DWA-192

Canada

Version 1.00(NA)_85x120

April 23, 2015

6WA191NAQ001G

of D-Link. All other third-party marks mentioned herein may be trademarks of their respective

owners. Product specications, size and shape are subject to change without notice, and

actual product appearance may dier from that depicted on the packaging. Visit dlink.com

(USA) or dlink.ca (Canada) for more details.

DWA-192

Guide d’installation rapide

Adaptateur USB 3.0 Wi-Fi AC 1900

Communiquez avec votre revendeur s'il manque l'un des éléments

ci-dessus.

Exigences minimales

Adaptateur USB 3.0 Wi-Fi AC 1900 DWA-192

Câble USB 3.0

Contenu de la boîte

Guide d’installation rapide

CD avec les pilotes et la documentation

• Ordinateur de bureau ou portable avec un port USBdisponible*

• Windows® 8 ou 7 (32/64-bit)

• Processeur à 300MHz et au moins 64Mo de RAM

• Lecteur de CD-ROM

• Réseau sans l 802.11ac ou 802.11n

* Pour les meilleures performances, connectez-vous à un port USB 3.0.

ANGLAIS
