D-Link DCF-650BT Manuel utilisateur

D-Link Bluetooth

Compact Flash Card

DCF-650BTDCF-650BT

DCF-650BT

This product can be used with:This product can be used with:

This product can be used with:

Windows XP, Me, 2000, 98 SecondWindows XP, Me, 2000, 98 Second

Windows XP, Me, 2000, 98 Second

EditionEdition

Edition

Check Your Package Contents

These are the items included with your purchase:

If any of the below items are missing, please contact your reseller.

Before You Begin

You must have at least the following:

•Windows XP/Me/2000/98 Second Edition

•One Available USB Port

•CD-ROM Drive

•MicrosoftActiveSync 3.0 or above

(free download from www.microsoft.com)

PDA

•Type 1 Compact Flash Card Slot

•Windows CE 3.0 (Pocket PC 2000/2002)

•Type A USB Connector

• DCF-650BT Bluetooth Compact Flash

Adapter

• Driver, Application Software, and

Installation Guide on CD-ROM

Installing the DCF-650BT

On Your PDA

System Requirements

•Pentium Class PC 200Mhz or above

•Microsoft Windows XP, 2000, Me, or 98 Second

Edition

•CD-ROM drive

•Microsoft ActiveSync Version 3.0 or above

•PDA with an available Compact Flash Port

Insert the DCF-650BT into your

handheld device.

Connect your PDA to the computer

you are using to install the drivers

using the type A USB cable pro-

vided with your PDA.

Installing the Bluetooth

Software on Your PC

Insert the driver DCF-650BT

Driver CD into your CD-ROM

drive. You will see the following

screen.

Before proceeding, make sure that you have ActiveSync

installed on the computer that you are using to install the

drivers. ActiveSync will sync your computer and PDA

and enable you to install the drivers on your PDA. You can

download ActiveSync for free from Microsoft’s website

www.microsoft.com.

Note: If the connection between the PDA and the computer is not ON, an error

message will appear. Check if your cable connections are secure and that

ActiveSync has established a connection before proceeding.

If the Autorun screen does not automatically start, click on Start > Run, enter

“D:\Autorun.exe” and click OK. “D” represents the letter of your CD-ROM drive.

Replace it if your CD-ROM drive is a different letter.

Click Install Drivers

Note: Screens will vary

slightly from the

screens shown

depending on your

Windows Operating

System.

Click Yes

Click Next

Click OK

When this next screen is

displayed, follow the on-

screen instructions on your

PDA to complete the driver

installation.

Click Finish

Completing the Driver

Installation

Be sure to RESET your PDA to complete the driver

installation.

The Bluetooth software will

automatically be downloaded

to your PDA. This screen will

appear to indicate successful

installation.

Select Add a shortcut in

the Start menu for easy

access to the Bluetooth

Manager. Click OK to exit

this screen.

Tips

Once you have reset your PDA, a Bluetooth icon appearing in the

lower right corner of your PDA’s main screen will indicate that your

DCF-650BT is on.

Go to Start -> Bluetooth Manager to configure and set your Bluetooth

connections. Please refer to the manual on this CD-ROM for detailed

instructions on configuring your Bluetooth devices.

A typical Bluetooth personal area network is shown below using the DCF-

650BT with a PDA.

Technical Support

You can find the most recent software and user

documentation on the D-Link website.

D-Link provides free technical support for customers

within the United States for the duration of the warranty

period on this product.

U.S. customers can contact D-Link technical support

through our web site or by phone.

D-Link Technical Support over the Telephone:

(877) 45D-LINK

(877) 453-5465

24 hours a day, seven days a week

D-Link Technical Support over the Internet:

http://support.dlink.com

email: [email protected]

their respective holders. Software and specifications subject to change without notice. DCF-650BT.011403
