Cypress CWF-901SP Manuel utilisateur
CWF-901 & SP
WiFi Smart
Player to TV
Operation Manual
CWF-901SP
Disclaimers
The information in this manual has been carefully checked and
is believed to be accurate. Cypress Technology assumes no
responsibility for any infringements of patents or other rights of third
parties which may result from its use.
Cypress Technology assumes no responsibility for any inaccuracies
that may be contained in this document. Cypress also makes
no commitment to update or to keep current the information
contained in this document.
Cypress Technology reserves the right to make improvements to this
document and/or product at any time and without notice.
Copyright Notice
No part of this document may be reproduced, transmitted,
transcribed, stored in a retrieval system, or any of its part translated
into any language or computer le, in any form or by any means
- electronic, mechanical, magnetic, optical, chemical, manual,
or otherwise - without express written permission and consent from
Cypress Technology.
© Copyright 2011 by Cypress Technology.
All Rights Reserved.
Version VR1.0 July 2011
Trademark Acknowledgments
All products or service names mentioned in this document may be
trademarks of the companies with which they are associated.
Safety Precautions
Please read all instructions before attempting to unpack or install or
operate this equipment, and before connecting the power supply.
Please keep the following in mind as you unpack and install this
equipment:
Always follow basic safety precautions to reduce the risk of
re, electrical shock and injury to persons.
To prevent re or shock hazard, do not expose the unit to rain,
moisture or install this product near water.
Never spill liquid of any kind on or into this product.
Never push an object of any kind into this product through
module openings or empty slots, as you may damage parts.
Do not attach the power supply cabling to building surfaces.
Do not allow anything to rest on the power cabling or allow it to
be abused by persons walking on it.
To protect the equipment from overheating, do not block the
slots and openings in the module housing that provide ventilation.
Revision History
Version No Date Summary of Change
VR0 20111230 Preliminary Release
VR1 20120204 Add 901's function
Table of Contents
1. Introduction..................................................................................1
2. Applications.................................................................................1
3. Package Contents ......................................................................1
4. System Requirements..................................................................1
5. Features........................................................................................2
6. Specification................................................................................2
7. Operation Controls and Functions.............................................3
7.1 Upper Panel.....................................................................3
7.2 Lower Panel.....................................................................3
7.3 Left Panel.........................................................................3
7.4 Top Panel.........................................................................4
7.5 USB Dongle......................................................................4
8. Software installation and un-installation from computer ........5
8.1 Computer Software Installation.....................................5
8.2 Uninstall the Computer Software...................................8
9. Configuring your application to use Wi-Fi Receiver.................8
9.1 Computer Easy Connection...........................................9
9.2 Smart Phone Easy Connection ......................................9
9.3 Access Point Application..............................................10
10. Connection and Installation.....................................................11
11. Acronyms................................................................................... 11
1
1. Introduction
The WiFi Smart Player to TV can send video/audio signals from a smart phone,
PC or Notebook through Wi-Fi to a TV and use it as the primary display. The
SmartPlayer is designed as a DLNA DMR (Digital Media Renderer) which means
users can easily send audio, video and pictures from a computer wirelessly to
TV. This device can also act as a Wi-Fi Access Point for users to access a wired
internet connection with their laptops or smart phones. Displaying audio, video
and pictures through network streaming the WiFi Smart Player is a simple yet
incredibly useful device for sharing content throughnetwork streaming.
2. Applications
• Wireless PC/NB to TV
• Wireless Smart phone to TV
• Wire PC/NB to TV
• Wi-Fi Access Point
3. Package Contents
• WiFi Smart Player
• USB Dongle
• 5V/2.6A DC power adaptor
• CD Driver (Operation Manual include inside)
4. System Requirements
In order to run the application smoothly, please refer to the following hardware
recommendation.
Desktop/Workstation PC:
• CPU: Intel Core 2 Duo 2.0G or better
• Chipset: Intel 965 series chipset or better
• Memory: DDR2-800, 2GB or better
• Graphic Card: NVIDIA GeForce 8400GS / ATI Radeon X300 or better
• Network: 802.11 g/n Wi-Fi and/or 100/1000 Mbps Ethernet
Notebook/Laptop PC:
• CPU: Intel Core 2 Duo 2.0G or better
• Chipset: Intel 965 series chipset or better
• Memory: DDR2-800, 2GB or better
• Graphic: Chipset integrated (Intel X3100 Graphic) or better or NVIDIA
GeForce Go 8200M / ATI Radeon Mobility X300 standalone graphic chip
or better
• Network: 802.11 g/n Wi-Fi and/or 100/1000 Mbps Ethernet
Supported OS:
• Windows 7, x86 and x64
• Windows Vista (Service Pack 1 or later), x 86 and x 64
Windows XP (Service Pack 3 or later)
2
5. Features
• Support PC to TV and Smart Phone to TV
• Can be a Wi-Fi AP
• WiFi Smart Player is a device that designed as a DLNA DMR
(Digital MediaRenderer) device.
• Display various picture, audio, and video contents through network streaming.
• USB port for Mouse / Keyboard.
• USB ash disk for rmware upgrade.
6. Specications
Host Interface 1 x 802.11n Wi-Fi and 100/1000Mbps Ethernet
Output port 1 x HDMI
Extender Port 3 x USB (Keyboard and Mouse only)
Video Supports (DLNA DMR) WMV, AVI, MPEG-1/2/4, 3GP & MOV with
2CH with bit-rate under 15Mbps
Audio Supports (DLNA DMR) LPCM, MPEG-1, WMA, WAV, MPEG-4, AAC,
OGG, 3GP & MP3 with 2CH
Resolution Supports DLNA DMR: Up to 1920 x 1080
PC to TV: Up to 1280 x 720 or
Up to 1920 x 1080 with Sandy Bridge
BridgeESD Protection Human body modell: ±8kV (air-gap discharge)
± 4kV (contact discharge)
Power Supply 5V/2.6A DC (US/EU standards, CE/FCC/UL certied)
Dimensions (mm) 100 (W) x 70 (D) x 20 (H)/SP, 56(W) x 20 (D) x 9 (H)
Weight(g) 100/SP, 8
Chassis Material Plastic
Silkscreen Color White
Operating Temperature 0°C ~ 40°C/32°F ~104°F
Storage Temperature -20°C ~ 60°C/-4°F ~140°F
Relative Humidity 20~90%RH (non-condensing)
Power Consumption 5.5W
3
7. Operation Controls and Functions
7.1 Upper Panel
1 2 3
HDMI Out Ethernet5V DC
①DC 5V: Plug the 5V DC power supply into the unit and connect the
adaptor to AC wall outlet.
②HDMI out: Connect the output port to the HDMI TV/display.
③Ethernet IN: This slot is to connect with CAT5e/6 cable from your network
system or PC/Laptop for a wire connection of input signal sending.
7.2 Lower Panel
1
USB Port
2
1
①USB Port 1 & 2: These slots are to connect with Wi-Fi module and USB
devices such as Keyboard and Mousel.
7.3 Left Panel
USB Port
3
1
4
①USB Port 3: This slot is to connect with Wi-Fi module and USB devices such
as keyboard and mouse for control.
7.4 Top Panel
1
①Power LED: This blue LED will illuminate when the device is connected
with power supply.
7.5 USB Dongle
①USB Dongle: Plug this Wi-Fi dongle into the Smart Player's USB port for
signal transmission.
5
8. Software installation and un-installation
The following sections describe the procedures for installing the PC2TV
device’s drivers. Insert the provid CD driver into the input source’s CD-
ROM driver then begin the installation.
8.1 Software Installation
Insert the CD driver included in the package and double click on the
PC2TV execute le ” ” to start the setup process.
Browse the folder where the les should be unpacked and click “Con
tinue” to start Installation.
InstallShield Wizard will install PC2TV on your input source device and
click “Next” to continue.
6
Add program icons to the program folder. You may type a new
folder name or select one from the existing folders list and click
“Next” to continue.
Press “Analysis” to evaluate your computer system.
