Custom Engineering TG35/58-T Manuel utilisateur

TG35/58-T

Printer version

User Manual

www.custom.it

TG35/58-T

form, whether on paper or electronically, is strictly forbidden. While CUSTOM

ENGINEERING SPA guarantees that the information contained in this manual

has been carefully checked and verified, CUSTOM ENGINEERING SPA and

other resources utilized in its creation assume no responsibility for situations

arising from its use.

Feedback regarding any errors in the manual’s content or suggestions on

how it could be improved would be greatly appreciated. Since its products

are subject to continuous checking and improvement, CUSTOM

ENGINEERING SPA reserves the right to modify the information contained

in this manual without prior notice.

COD. DOME - TG35-58-T VERS. 1.33

CUSTOM ENGINEERING SPA

Str. Berettine 2 - 43010 Fontevivo (PARMA) - Italy

Phone : +39 0521-680111 - Fax : +39 0521-610701

http: www.custom.it http: www.smice.com

To contact our Technical Support :

Phone. : +39 0521-680163 - Fax : +39 0521-680146

Email : [email protected]

TG35/58-T

PRINTER COMPONENTS

A. TG35/58-T - exterior view

1- Printing mechanism

2- Report “Key”

3- Feed “Key”

4- Paper roll support

5- Case

6- Front panel

7- Led

8- Paper output

TG35/58-T

1 2

B. TG35/58-T - rear view

1- Power supply connector

2- Power supply connector and additional signals

3- TTL serial interface connector

TABLE OF CONTENTS

TG35/58-T

INTRODUCTION

MANUAL ORGANIZATION ............................................................................ 1

SYMBOLS USED IN THE MANUAL............................................................... 1

GENERAL SAFETY INFORMATION ............................................................. 1

UNPACKING THE PRINTER ......................................................................... 2

MAIN CHARACTERISTICS ........................................................................... 2

PRINTER DESCRIPTION ............................................................................. 3

1. INSTALLATION AND OPERATION

1.1 CONNECTIONS ................................................................................... 1-1

1.1.1 Power supply and Input/Output ...................................................... 1-1

1.2 SETUP .................................................................................................. 1-2

1.2.1 Configuration of REPORT and FEED keys ................................... 1-3

1.3 AUTOTEST .......................................................................................... 1-3

1.4 CAUTIONS ........................................................................................... 1-3

1.5 MAINTENANCE.................................................................................... 1-4

1.5.1 Using the control discs................................................................... 1-4

1.5.2 Changing the paper roll .................................................................. 1-4

2. INTERFACES

2.1 TTL SERIAL ......................................................................................... 2-1

3. PRINTER FUNCTIONS

3.1 COMMAND DESCRIPTIONS .............................................................. 3-1

3.1.1 ESC/POS Emulation ..................................................................... 3-1

4. TECHNICAL DATA

4.1 TECHNICAL DATA............................................................................... 4-1

4.2 DIMENSIONS ....................................................................................... 4-2

TABLE OF CONTENTS

TG35/58-T ii

APPENDIX A - ACCESSORIES AND SPARE PARTS

A.1 ACCESSORIES................................................................................... A-1

A.1.1 Power supply ................................................................................. A-1

A.1.2 RS232 cable adaptation ................................................................ A-2

A.2 SPARE PARTS .................................................................................... A-5

INTRODUCTION

TG35/58-T

MANUAL ORGANIZATION

In addition to the Introduction which contains information regarding the

symbols used in the manual, general safety information, instructions for

unpacking the printer and a brief description and main characteristics of the

machine, this manual is divided into the following chapters:

Chapter 1: Contains the information required for correct printer installation

and use

Chapter 2: Contains interface data

Chapter 3: Contains a description of printer controls

Chapter 4: Contains printer technical data

Chapter 5: Contains the character sets (fonts) used by the printer

SYMBOLS USED IN THE MANUAL

NOTE

Gives important information or suggestions for printer use.

WARNING

Information indicated by this symbol must be followed carefully to

avoid damaging the printer.

DANGER

Information indicated by this symbol must be followed carefully to

avoid damage or operator injury.

GENERAL SAFETY INFORMATION

•Read and retain the instructions which follow.

•Before cleaning the printer, be sure to pull out the electrical cable.

•Use a damp cloth to clean the printer. Do not use liquid or spray products.

•Do not operate the printer near water.

•When positioning the printer, make sure its cables will not be damaged.

•Use the type of electrical power supply indicated on the printer label. If

uncertain, contact your dealer.

•Do not block the ventilation openings.

INTRODUCTION

TG35/58-T 2

•Do not insert objects inside the printer as this could cause short-circuiting

or damage components that could jeopardize printer functioning.

•Do not spill liquids onto the machine.

•Do not carry out repairs on the machine yourself, except for the normal

maintenance operations given in the user manual.

•Unplug the printer from the electrical mains and call a specialized

repairman if any of the following conditions should arise:

A. the power supply connector is damaged

B. liquid has spilled into the printer

C. the printer has been exposed to rain or water

D. the printer is not functioning normally despite the fact that all

instructions given in the user manual have been followed

E. the printer has been dropped and the cover is damaged

F. printer performance is noticeably reduced

G. the printer is not working

UNPACKING THE PRINTER

Remove the printer from the carton, taking care not to damage the packing

materials which should be retained for future shipping/moving.

Make sure all components listed below are present and not damaged. If any

part is missing and/or damaged, contact customer service.

1. Manual (or CD-rom)

2. Printer

3. Discs control of paper roll

MAIN CHARACTERISTICS

The TG35/58-T printer is the ideal solution for :

• Gaming machines

• Vending machines

• Self-service machines

• Paper tear-off and anti-paper jam system.

• Optional RS232 cable adaptation.

INTRODUCTION

TG35/58-T

PRINTER DESCRIPTION

It is equipped with a 200 dpi thermal print mechanism that uses paper with a

width of 35/58 mm; it has a TTL serial interface (optional RS232 cable) and

is also equipped with a calendar clock (Real Time Clock).

The TG35/58-T printer consists of a case (5) onto which the following

components are fitted: thermal print mechanism (1), paper roll pin (4) front

panel (6) in PPO for installation on Gaming/Vending Machines.

• When the “REPORT” key (2) is pressed, it prints the printer operational

report.

• When the “FEED” key (3) is pressed, the paper can be fed forward

manually.

(Fig. 1)

INTRODUCTION

TG35/58-T 4

• The red Status LED (7) displays a printer hardware error status and the

winnings. The check is carried out“on line”, i.e. in the event of a

malfunctioning, the LED will starts flashing as follows:

DELSUTATSDELSUTATS DELSUTATS DELSUTATSDELSUTATSNOITPIRCSEDNOITPIRCSED NOITPIRCSED NOITPIRCSEDNOITPIRCSED

FFOsyawlAFFOretnirP

NOsyawlAstluafon–NOretnirP

)doirepgnolarofno(gnihsalfwolSdesiarrevocgnitliT

)doireptrohsarofno(gnihsalfwolSegasseMtuOrepaP

(Tab.1)
