Custom Audio Electronics FT190 Manuel utilisateur

FT190

Thermal panel printer

FT190 24/40

User’s manual

www.custom.it

FT190

Printer components

1- Print mechanism

2- Case

3- Paper outfeed

4- Paper loading label

5- Front panel

6- Paper roll compartment

7- Keypad

8- Feed connector

9- Paper winder connector

10- Interface connector

11- Outside “Print” key connector

FT190

in any form whatsoever, whether it be on paper or through computer

processes, is strictly prohibited. Custom Engineering s.r.l. and the resource

teams employed in the making of this manual will not be held responsible for

any problems arising as a result of improper use of this manual, as they

guarantee that the information contained in it has been subjected to careful

inspection.

Any suggestions regarding errors in its contents or possible improvements

will, nonetheless, be greatly appreciated. The products are continuously

checked and improved. For this reason Custom Engineering s.r.l. reserves

the right to modify the information contained in this manual without prior

notice.

COD. DOME-FT190 Revision 1.20

Custom Engineering

Str. Berettine 2 - 43010 Fontevivo (PARMA) - Italy

Tel. : +39 0521-680111 - Fax : +39 0521-610701

http: www.custom.it Email : [email protected]

FT190

ytimrofnoCfonoitaralceD"EC"ytimrofnoCfonoitaralceD"EC" ytimrofnoCfonoitaralceD"EC" ytimrofnoCfonoitaralceD"EC"ytimrofnoCfonoitaralceD"EC"

41054NEdna22ediuGCEI/OSIsdradnatshtiwecnadroccanI41054NEdna22ediuGCEI/OSIsdradnatshtiwecnadroccanI 41054NEdna22ediuGCEI/OSIsdradnatshtiwecnadroccanI 41054NEdna22ediuGCEI/OSIsdradnatshtiwecnadroccanI41054NEdna22ediuGCEI/OSIsdradnatshtiwecnadroccanI :°N 8962030CD

:emans'rerutcafunaM.l.r.sgnireenignEmotsuC

s'rerutcafunaM :sserdda 2enittereBadartS )amraP(ovivetnoF ylatI

:tcudorpehttahtseralceD

:emantcudorPmsinahcemtnirplamrehthtiwretnirplenaP

:emanepyT091TF

:ledoMLTT091TF

:sevitceridgniwollofehthtiwytimrofnocnisi

86/39/CEE;13/29/CEE;633/98/CEEsevitceridytilibitapmoccitengamortcelE

:sdradnatsgniwollofehthtiwecnadroccanI

22055NE BssalC oidarfotnemerusaemfosdohtemdnastimiL noitamrofnifoscitsiretcarahcecnabrutsid tnempiuqeygolonhcet

5991

1-28005NE-ytilibitapmoccitengamortcelE lairtsudnI:2traP.dradnatsytinummilareneG .stnemnorivne

2991

2-4-00016NEstnemeriuqeregrahcsidcitatsortcelE egrahcsidriaVK8,egrahcsidtcatnocVK4 5991

4-4-00016NE.stnemeriuqertsrub/tneisnartlacirtceletsaF VK5.0sniamCD 5991

04105VNEcitengamortceleycneuqerf-oidardetaidaR .stsetytinummI.sdleif MAzHK1%08,zHM0001-zHM08,m/V3

3991

8991enuJ

TABLE OF CONTENTS

FT190i

INTRODUCTION

CONTENTS OF THE MANUAL......................................................................1

CONVENTIONS USED IN THE MANUAL .....................................................1

GENERAL INFORMATION REGARDING SAFETY .....................................1

UNPACKING THE PRINTER .........................................................................3

GENERAL FEATURES..................................................................................3

DESCRIPTION OF THE PRINTER...............................................................4

1. INSTALLATION AND USE

1.1 CONNECTIONS................................................................................... 1-1

1.1.1 Power supply ................................................................................. 1-1

1.1.2 Logic circuitry ................................................................................. 1-2

1.2 CONFIGURATION ............................................................................... 1-5

1.3 AUTOTEST .......................................................................................... 1-6

1.4 HEXADECIMAL DUMP ........................................................................ 1-6

1.5 MAINTENANCE.................................................................................... 1-7

1.5.1 Changing the paper roll.................................................................. 1-7

2. INTERFACES

2.1 TTL SERIAL......................................................................................... 2-1

2.2 TTL PARALLEL.................................................................................... 2-2

2.3 CALENDAR CLOCK (OPTIONAL)...................................................... 2-3

2.3.1 Adjusting the clock through the keypad ......................................... 2-3

3. PRINTER FUNCTIONS

3.1 PRINT DIRECTION ............................................................................. 3-1

3.2 CONTROL CHARACTERS ................................................................. 3-2

4. TECHNICAL SPECIFICATIONS

4.1 TECHNICAL SPECIFICATIONS......................................................... 4-1

4.2 DIMENSIONS....................................................................................... 4-2

5. CHARACTER SETS

5.1 CHARACTER SETS ............................................................................ 5-1

TABLE OF CONTENTS

FT190 ii

ATTACHMENT A - ACCESSORIES AND SPARE PARTS

A.1 ACCESSORIES................................................................................... A-1

A.1.1 PSM05 Power supply .................................................................... A-1

A.1.2 AV03 Rewinder.............................................................................. A-2

A.2 SPARE PARTS.................................................................................... A-3

INTRODUCTION

FT1901

CONTENTS OF THE MANUAL

In addition to the introduction which lists: the conventions used in the manual,

general information relative to safety, unpacking of the printer and a brief

description of the printer itself, highlighting its main features, the manual is

split up into the following chapters:

Chapter 1: Containing the information required for installing and using the

printer correctly

Chapter 2: Containing the specifications of the interfaces

Chapter 3: Containing the description of the printer command set

Chapter 4: Containing the technical specifications of the printer

Chapter 5: Containing the character sets (fonts) used by the printer

CONVENTIONS USED IN THE MANUAL

N.B.

Gives important information or suggestions relative to the use of the

printer

WARNING

The information marked with this symbol must be carefully heeded

to safeguard against damaging the printer

DANGER

The information marked with this symbol must be carefully heeded

to safeguard against injury to the operator

GENERAL INFORMATION REGARDING SAFETY

•Read and keep the following instructions.

•Observe all warnings and follow all instructions attached to the printer.

•Before cleaning the printer, disconnect the feed cable.

•Clean the printer with a damp cloth. Do not use liquid or spray products.

•Do not operate the printer near to water.

INTRODUCTION

FT190 2

•Do not place the printer on unsteady surfaces. It could fall and get

seriously damaged.

•Use the type of electricity supply marked on the printer label. In the event

of uncertainty, contact the seller.

•Position the printer in such a way as to ensure that the cables connected

to it will not be damaged.

•Ensure that the maximum absorbed current of the printer does not

exceed the maximum acceptable current for the type of feed cable used.

•Do not put objects of any kind inside the printer as they could cause a

short circuit or damage parts which could affect its performance.

•Do not spill liquids on the printer.

•Do not carry out technical operations on the printer with the exception of

the scheduled maintenance operations specifically indicated in the user’s

manual.

•Disconnect the printer from the electricity supply and have it repaired by a

specialized technician should any of the following conditions occur:

A. The feed connector has been damaged.

B. Liquid has penetrated to the inside of the printer;

C. The printer has been exposed to rain or water;

D. The printer is not operating normally despite the instructions in

the user’s manual having been followed.

E. The printer has been dropped and its case damaged.

F. The performance of the printer is poor.

G. The printer does not work.

INTRODUCTION

FT1903

UNPACKING THE PRINTER

Remove the printer from the box, taking care not to damage the packing

material, as it could be needed for future transportation of the machine.

Ensure that all the components illustrated are in fact present and that they

are in perfect condition. If this is not the case, contact the after-sales

assistance department immediately.

Printer

Manual (or Cdrom)

Paper roll (inside the printer)

Long screws

N.B.

Before using the long screws, read the note to paragraph 4.2.

GENERAL FEATURES

The FT190 is a printer which, in addition to having an innovative design,

guarantees high performance and is reliable and user-friendly.

For these reasons, it is the ideal solution for applications which require the

immediate printing of data on a ticket, whether they be of an industrial,

professional or laboratory nature. Typical fields of application are: weighing

systems, receipts (not for tax purposes) as well as for security, controlling

and diagnostics purposes.

It has a 200 dpi thermal print mechanism and uses 57.5mm paper rolls. It

can print 24 or 40 characters per line according to the selection made at the

setup stage through the software command.

The FT190 printer is so compact and lightweight that it can be installed

extremely easily on any type of equipment. It is supplied with TTL serial and

parallel interfaces and has a 1Kbyte reception buffer. It can also be

equipped with a Real Time Clock.

(Figure 1)

INTRODUCTION

FT190 4

DESCRIPTION OF THE PRINTER

The FT190 printer has an ABS casing (1) with a front cover (2) which opens

to allow access to the paper roll and print head.

The control panel is located on the front (3) and has a PRINT key, a FEED

key and two LEDs: Power and Status.

•PRINT key. When enabled it outputs, in parallel, the logic state “0” on

pin 4 of J1, while in serial it brings about the transmission of the control

character “$0D”, if this has been enabled at the printer setup stage. In

parallel on PRINT key there is a connector J6 used for the connection

to outside key (figure 1.1).

•FEED key. When this is pressed, the paper feeds forward manually. If

this key is pressed briefly, when the RTCK option is installed, the date

and time of day is printed.

•The POWER LED indicates that the the printer is receiving a digital

power supply.

•The STATUS LED, when flashing, signals that the paper is finished.

When lit steadily, it signals the presence of an error (head power supply

too high or too low or head temperature too high).

(Figure 2)

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Custom Audio Electronics Imprimante

Custom Audio Electronics

Custom Audio Electronics Mini PLUS Manuel utilisateur

Custom Audio Electronics

Custom Audio Electronics Neo Manuel utilisateur

Custom Audio Electronics

Custom Audio Electronics BIGII Touch PC Manuel utilisateur

Custom Audio Electronics

Custom Audio Electronics FT190HACCP Manuel utilisateur

Custom Audio Electronics

Custom Audio Electronics Kube II Manuel utilisateur

Custom Audio Electronics

Custom Audio Electronics PM8024 Manuel utilisateur

Custom Audio Electronics

Custom Audio Electronics K3 Supplément

Custom Audio Electronics

Custom Audio Electronics P190 Manuel utilisateur

Custom Audio Electronics

Custom Audio Electronics K-80 Instructions d'installation

Custom Audio Electronics

Custom Audio Electronics MT2460 Manuel utilisateur

Custom Audio Electronics

Custom Audio Electronics KPM216HII-ETH Manuel utilisateur

Custom Audio Electronics

Custom Audio Electronics TG558 Series Manuel utilisateur

Custom Audio Electronics

Custom Audio Electronics S16SB Manuel utilisateur

Custom Audio Electronics

Custom Audio Electronics s'print DPT100-B Manuel utilisateur

Custom Audio Electronics

Custom Audio Electronics tg2480h Manuel utilisateur

Custom Audio Electronics

Custom Audio Electronics STIMARE STIMA-SML Manuel utilisateur

Custom Audio Electronics

Custom Audio Electronics Plus II Manuel utilisateur

Custom Audio Electronics

Custom Audio Electronics VK80 Manuel utilisateur

Custom Audio Electronics

Custom Audio Electronics TG1260HIII Series Manuel utilisateur

Custom Audio Electronics

Custom Audio Electronics Custom Manuel utilisateur

Custom Audio Electronics

Custom Audio Electronics CMxxx Manuel utilisateur

Custom Audio Electronics

Custom Audio Electronics PP54 Instructions d'installation

Custom Audio Electronics

Custom Audio Electronics DPT100-S Instructions d'installation

Custom Audio Electronics

Custom Audio Electronics PRT 80 Manuel utilisateur

Manuels Imprimante populaires d'autres marques

Lexmark

Lexmark 1400 Series Manuel

Canon

Canon i70 Series Manuel utilisateur

Evolis

Evolis Elypso Manuel utilisateur

Kyocera

Kyocera FS-9530DN Manuel utilisateur

Canon

Canon LASER SHOT LBP-1210 Manuel utilisateur

Samsung

Samsung BIXOLON SRP-350plusF Manuel utilisateur

Canon

Canon PIXMA PRO-1 Series Manuel utilisateur

Canon

Canon PIXMA G3560 Guide de configuration

Dell

Dell Color Laser Printer 2130cn Manuel utilisateur

Tektronix

Tektronix Phaser 840 Manuel utilisateur

Epson

Epson ET-7750 Mode d'emploi

Canon

Canon CLBR 460ps Manuel utilisateur

Eltron

Eltron P210 Guide Manuel utilisateur

Ricoh

Ricoh MD-P1 Manuel utilisateur

Epson

Epson SC-F7100 series Manuel utilisateur

Epson

Epson Stylus C40UX Manuel utilisateur

Canon

Canon imagePASS-A2 Manuel utilisateur

Canon

Canon S820D Manuel utilisateur
