Curtis KCR2609 Manuel utilisateur
UNDERCOUNTER CD CLOCK RADIO
MODEL NO. KCR2609
OWNER'S MANUAL
PLEASE READ BEFORE OPERATING THIS EQUIPMENT
TIMER
IR
MHz
FM
J A Z Z
S L E E P
R
1
SAFETY PRECAUTIONS
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE
COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SER-
VICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
The lightning flash with arrowhead symbol within an equilat-
eral triangle is intended to alert the user to the presence of
uninsulated 'dangerous voltage' within the product's enclo-
sure that may be of sufficient magnitude to constitute a risk
of electric shock to persons.
The exclamation point within an equilateral triangle is intend-
ed to alert the user to the presence of important operating
and maintenance (servicing) instructions in the literature
accompanying the appliance.
DANGER:
Invisible and hazardous laser radiation when open and inter-
lock failed or defeated. Avoid direct exposure to beam.
FCC WARNING:
This equipment may generate or use radio frequency energy. Changes
or modifications to this equipment may cause harmful interference
unless the modifications are expressly approved in the instruction man-
ual. The user could lose the authority to operate this equipment if an
unauthorized change or modification is made.
LASER SAFETY: This unit employs a laser. Only qualified service per-
sonnel should attempt to service this device due to possible eye injury.
CAUTION: USE OF CONTROLS, ADJUSTMENTS OR PERFOR-
MANCE PROCEDURE HEREIN MAY RESULT IN HAZARDOUS
RADIATION EXPOSURE.
PLEASE KEEP ALL PACKAGING MA TERIAL FOR AT LEAST 90 DAYS IN
CASE YOU NEED TO RETURN THIS PRODUCT TO YOUR PLACE OF PUR-
CHASE OR CURTIS.
PREPARATION FOR USE
Unpacking and Setup
AC Operation
Unwind the AC cord and extend it to its full length. Insert the AC cord into any
convenient AC 120V~60Hz household outlet.
Carefully remove the unit from the display carton and remove all packing
material from the unit itself.
2
L OC A TION OF C ONTR OL S
1. POWER BUTTON
2. SLEEP BUTTON
3. TIMER BUTTON
4. FUNCTION BUTTON
5. REMOTE SENSOR
6. MEM/CLK SET BUTTON
7. MEM DN BUTTON
8. REPEAT BUTTON
9. SKIP/TUNE DN BUTTON
10.SKIP/TUNE UP BUTTON
11. VOL UP BUTTON
12. VOL DN BUTTON
13. OPEN/CLOSE BUTTON
14. BAND BUTTON
15. PLAY/PAUSE BUTTON
16. EQ BUTTON
17. MEM UP BUTTON
18. CD DOOR
19.DISPLAY BUTTON
20.FM ST BUTTON
21.STOP BUTTON
3
TIMER
IR
MHz
FM
J A Z Z
S L E E P
1 2 345678910
11
12
1314
15
16
17
18
19 20
21
L OC A T ION OF R E MO T E C ONT R OL S
1. FUNCTION BUTTON
2. DISPLAY BUTTON
3. NUMBERDIAL BUTTONS
4. SKIP/TUNE DN BUTTON
5. OPEN/CLOSE BUTTON
6. SKIP/TUNE UP BUTTON
7. FM ST BUTTON
8. MEM DN/REPEAT BUTTON
9. PLAY/PAUSE BUTTON
10.MEM/CLK/SET BUTTON
11.STOP/BAND BUTTON
12. MENU BUTTON
13. ITEM/ENTER BUTTON
14. EQ BUTTON
15. VOLUME DN BUTTON
16. VOLUME UP BUTTON
17. MUTE BUTTON
18.POWER BUTTON
19.SLEEP BUTTON
20.TIMER BUTTON
4
TIMER SLEEP
FUNC
MUTE
REMOTE CONTROL
1 2
3
4 5
6
7 8
9
0
-/--
VOL.
E Q
REP
DSIPLAY
SET
TUNER/SKIP/CH STOP/BANDPLAY/PAUSE/M-UP
ENTER
ITEM/
MENU
MEM/CLK
MEM-DN
OPEN/CLOSE FM ST
1
2
3
4
5
6 7 8 9
10
11
12
13
14
15
16
17
18
1920
P OW E R S OUR C E S
BATTERIES
NOTE:
The button cell battery contains mercury, don't put in the trash. Recycle or
dispose as hazardous waste.
NOTE:
You may need to remove a protective covering from the remote's battery
compartment before using the remote control.
5
(F O R R E MO T E C O NT R O L)
OP E R A T ING INS T R UC T IONS
6
Setting up your radio
For instructions on mounting your radio, see the mounting template that
came with your radio.
Checking AM Radio reception
Your clock radio has a built-in antenna for AM radio. To improve reception,
you need to rotate your clock radio.
Before you mount your clock radio under a counter, tune to an AM station
and rotate your clock radio until you get the best reception.
This is the orientation you need to use when you mount your clock radio.
For more information, see "Improving reception" on page 10.
Installing the backup batteries
Your clock radio uses two AAA backup batteries that store your settings.
You cannot use the batteries to power your clock radio. If your clock radio
does not save your settings, you may need to replace the batteries.
To install the backup batteries:
1. Open the battery compartment located on the left side of your radio.
2. Insert two AAA batteries (not included) into the battery compartment.
Make sure that the + and - symbols on the batteries align with the +
and - symbols in the battery compartment.
3. Close the battery compartment.
O P E R A T ING INS T R U C T IO NS
7
To turn on your radio:
1. Plug the AC Power cord into a power outlet.
2. Press the POWER button to turn on the radio.
Setting the time
To set the time on your radio:
1. With the power off.
2. Press and hold the MEM/CLK SET Button; "12Hr" will blink.
3. Press the SKIP/TUNING Button to set the unit to the 24 hour (24Hr) mode
or 12 hour (12Hr) mode.
4. Press the MEM/CLK SET Button and the hours will blink.
5. Press the SKIP/TUNING Button to set the current hour, then press the
MEM/CLK SET again; the minute digits will blink. Press the SKIP/TUNING
to set the current minutes.
6. Press the MEM/CLK SET Button to confirm the time.
To set the kitchen timer:
1. Press the TIMER button one or more times to select a length of time
in minutes. The initial time is 240 minutes. Each time you press the
TIMER Button, the length of time decreases by 10 minutes.
2. To increase or decrease the length of time from one to nine minutes,
press one of the SKIP/TUNING Button one or more times. Each time
you press a SKIP/TUNING Button the length of time increase or decrease
by one minute.
3. When the alarm sounds, press the TIMER Button for five seconds to
turn off the alarm.
4. To cancel the timer, press the TIMER Button for five seconds.
To activate sleep function:
1.
Press the SLEEP button and "90" will appear and set the unit to turn off after
90 minutes.
Each time you press the SLEEP button, the length of time decreases
by 10 minutes.
2. After five seconds, the Sleep function will activate and the SLEEP indicator will light
solid. Pressing the SLEEP button again until "OFF" appears and turns off the Sleep
feature.
Using your radio
OP E R A T ING INS T R UC T IO NS
8
To listen to your radio:
1. Press the POWER Button to turn on your radio.
2. Press the FUNCTION Button one or more times until TUNER appears on
the display.
3. Press the BAND Button to select AM or FM.
4. Press and hold one of the SKIP/TUNING Buttons to go to an available
radio station.
5. Press one of the VOLUME Buttons to adjust the volume.
Improving reception:
Your clock radio has an FM antenna on the back. If you are listening to an FM
station and the reception is poor, move the antenna until reception improves.
If you are listening to an AM station and reception is not clear, rotate your radio
slightly until reception improves.
Programming radio station presets:
You can program as many as 10 FM and 10 AM radio station presets. After you
program a station, you can tune to the station by pressing one of the SKIP/TUNE
Buttons.
To program a radio station:
1. Press the POWER Button to turn on your radio.
2. Press the FUNCTION Button one or more times until TUNER appears
on the display.
3. Press the BAND Button to select AM or FM.
4. Press and hold one of the SKIP/TUNE Buttons to select a radio station.
5. Press and hold the MEM/CLK SET Button to activate the programming
mode.
6. Press one of the SKIP/TUNING Buttons to select the preset number you
want to assign the station to.
7. Press the MEM/CLK SET Button to store the station with the preset number
you selected.
8. Repeat Steps 4 through 7 to program additional presets.
O P E R A T ING INS T R U C T IO NS
9
To tune to a radio station preset:
1. Press the POWER Button to turn on your radio.
2. Press the FUNCTION button one or more times until TUNER appears on
the display.
3. Press the BAND Button to select AM or FM.
4. Press the MEM DN or MEM UP Button one or more times until the preset
number you want appears on the display.
To select an equalizer mode:
Press the EQ Button one ore more times to select the mode you want
You can select:
* Classic
* Jazz
* Rock
* Pop
To Listen to a CD
Your radio can play audio CDs, CD-Rs and CD-RWs. CD-Rs and CD-RWs
must be finalized before you can play them on your radio.
To listening to a CD:
1. Press the POWER Button to turn on your radio.
2. Press the FUNCTION Button one or more times until "--" appears on
the display.
3. Press the OPEN/CLOSE Button to open the CD tray.
4. Place a CD with the label side up into the CD tray.
5. Press the OPEN/CLOSE Button to close the CD tray.
6. Press the PLAY/PAUSE Button to start playback.
7. To control the CD during playback:
* Press the PLAY/PAUSE Button to pause playback. Press the button
again to resume playback.
* Press one of the SKIP/TUNING Buttons to go to the next or previous
track on the CD.
* Press and hold one of the SKIP/TUNING Buttons to search for a track
on the CD.
8. Press the STOP Button to stop playback.
