Cudy POE100 Manuel utilisateur
POE100/POE500
User Manual • Uživatelský manuál •
Užívateľský manuál • Használati utasítás •
Benutzerhandbuch
2
English
3 –8
Čeština
9 –14
Slovenčina
15 –20
Magyar
21 –26
Deutsch
27 –32
3
The product user guide contains product features, how to use, and the operating
procedure. Read the user manual carefully to get the best experience and avoid
unnecessary damage. Keep this manual for future reference. If you have any questions
or comments about the device, please contact the customer line.
✉www.alza.co.uk/kontakt
✆+44 (0)203 514 4411
Importer Alza.cz a.s., Jankovcova 1522/53, Holešovice, 170 00 Praha 7, www.alza.cz
4
Hardware Connection
Physical Appearance
AC Socket
Power socket
Ethernet device
Powered device (PD)
IP camera
Wireless AP
Smart VoIP
5
LED and Interface Explanation
PORT
Green
PoE injector got 100-240V power input.
Red
The terminal equipment connected to DATA&POWER
OUT port is powered.
AC Socket
Connect with AC cable.
DATA IN
Connect to the Ethernet device with cable to transmit data.
DATA OUT
Connect to the PD device with UTP cable to supply power.
Specifications
Model
POE100/POE500
Power
100-240V AC
Ethernet
POE100: 10/100/1000M
POE500: 10/100/1000M/2.5Gbps
Network
protocol
IEEE802.3 (10Base-T)
IEEE802.3u (100Base-TX)
IEEE802.3ab (1000Base-TX)
IEEE802.3bz (2.5GBase-T)
IEEE802.3x (flow control)
PoE protocol
IEEE802.3af (15.4W)
IEEE802.3at (25.4W)
Industry
standard
EMI: FCC Part 15 CISPR (EN55032) class A
EMS: EN61000-4-2 (ESD), EN61000-4-4 (EFT)
Shock: IEC 60068-2-27
Free Fall: IEC 60068-2-32
Vibration: IEC 60068-2-6
Network
medium
10Base-T: Cat3, Cat4, Cat5 or above UTP (≤100m)
100Base-TX: Cat5 or above UTP (≤100m)
1000Base-TX: Cat5 or above UTP (≤100m)
Working
temperature
0 ~ 40 °C
Storage
temperature
-40 ~ 80 °C
6
Warranty Conditions
A new product purchased in the Alza.cz sales network is guaranteed for 2 years. If you
need repair or other services during the warranty period, contact the product seller
directly, you must provide the original proof of purchase with the date of purchase.
The following are considered to be a conflict with the warranty conditions, for
which the claimed claim may not be recognized:
•Using the product for any purpose other than that for which the product is intended
or failing to follow the instructions for maintenance, operation and service of the
product.
•Damage to the product by a natural disaster, the intervention of an unauthorized
person or mechanically through the fault of the buyer (e.g. during transport, cleaning
by inappropriate means, etc.).
•Natural wear and aging of consumables or components during use (such as
batteries, etc.).
•Exposure to adverse external influences, such as sunlight and other radiation or
electromagnetic fields, fluid intrusion, object intrusion, mains overvoltage,
electrostatic discharge voltage (including lightning), faulty supply or input voltage and
inappropriate polarity of this voltage, chemical processes such as used power
supplies, etc.
•If anyone has made modifications, modifications, alterations to the design or
adaptation to change or extend the functions of the product compared to the
purchased design or use of non-original components.
7
EU Declaration of Conformity
Identification data of the manufacturer's / importer's authorized representative:
Importer: Alza.cz a.s.
Registered office: Jankovcova 1522/53, Holešovice, 170 00 Prague 7
CIN: 27082440
Subject of the declaration:
Title: PoE
Model / Type: POE100/POE500
The above product has been tested in accordance with the standard(s) used to
demonstrate compliance with the essential requirements laid down in the
Directive(s):
Directive No. 2009/125/EC
Directive No. 2014/30/EU
Directive No. 2014/35/EU
Directive No. 2011/65/EU as amended 2015/863/EU
Prague, 26.7.2021
CE Mark Warning
This is a class B product. In a domestic environment, this product may cause radio
interference, in which case the use may be required to take adequate measures.
8
WEEE
This product must not be disposed of as normal household waste in accordance with
the EU Directive on Waste Electrical and Electronic Equipment (WEEE - 2012/19 / EU).
Instead, it shall be returned to the place of purchase or handed over to a public
collection point for the recyclable waste. By ensuring this product is disposed of
correctly, you will help prevent potential negative consequences for the environment
and human health, which could otherwise be caused by inappropriate waste handling of
this product. Contact your local authority or the nearest collection point for further
details. Improper disposal of this type of waste may result in fines in accordance with
national regulations.
9
Vážený zákazníku,
děkujeme Vám za zakoupení našeho produktu. Prosíme, pečlivě si přečtěte následující
instrukce před prvním použitím a uživatelský manuál si uschovejte pro pozdější užití.
Zejména dbejte na bezpečnostní pokyny. Pokud máte jakékoliv dotazy či připomínky
ohledně přístroje, prosíme, obraťte se na zákaznickou linku.
✉www.alza.cz/kontakt
✆+420 255 340 111
Dovozce Alza.cz a.s., Jankovcova 1522/53, Holešovice, 170 00 Praha 7, www.alza.cz
10
Připojení hardwaru
Fyzický vzhled
Zásuvka AC
Napájecí zásuvka
Zařízení Ethernet
Napájené zařízení (PD)
IP kamera
Bezdrátový
přístupový bod
Inteligentní VoIP
