Cub Cadet Z-FORCE Z-FORCE 48 Manuel utilisateur

FEATURES

Z-FORCE® 48

Z-FORCE® 54

DEsignED FOR HOmEOwnER

usE witH Flat tERRain

up tO 3.5 aCREs

Z-FORCE®

SERIES

UNSURPASSED RESULTS OF

ThE CUb CADET SIgNATURE CUT™

Aerospace engineers designed the heavy-duty, fabricated cutting deck for optimal

results and durability. Featuring a triple-blade cutting system and ﬂoating deck,

along with a pivoting front axle to follow the contours of ground for a smooth

ride, you’re able to achieve a more precise cut on both uneven and ﬂat terrain.

EASY OPERATION MADE TO FIT YOU

By using the foot pedal, you can easily adjust the deck height without

stopping or leaving your seat. Along with the comfort of gel suspension,

you won’t even want to leave the adjustable seat.

ULTRA-MANEUVERAbLE ZERO-TURNINg CAPAbILITIES

The dual hydrostatic rear-wheel transmission allows for easy zero-turn

control. With the ability to turn on a dime, you’ll be able to get the job done

more efﬁciently leaving behind nothing but a professional-quality cut.

cubcadet.com

smaRtER FEatuREs FOR a bEttER ExpERiEnCE. tHat’s tHE CUb CADET ADVANTAgE.

HEavy-Duty ZERO-tuRn RiDERs

48" AND 54"

HEAVY-DUTY

FABRICATED DECK

HIGHLY EFFICIENT

AND DURABLE

DUAL HYDRO-GEAR™

ZT-2800™ TRANSMISSION

4.25-GALLON FUEL TANK

ANTI-SCALPING WHEELS

ADJUSTABLE SEAT WITH

GEL SUSPENSION

PIVOTING FRONT AXLE

FULLY WELDED

STEEL FRAME

ARM RESTS ON

ALL MODELS

PATENTED SMARTJET™

DECK WASH SYSTEM

3-YEAR/180-HR LIMITED

WARRANTY†

†See speciﬁcations for warranty information.

A STEP UP IN POWER AND PERFORMANCE.

The Z-Force® zero-turn rider has an innovative design that marries the toughness of a heavy-duty deck

with powerful performance that allows you to get impeccable results. And that extra power comes with

complete comfort thanks to a high-backed seat. You’ll be mowing blissfully and conﬁdently.

lOCatE a DEalER at

CUbCADET.COM

innOvatiOns nO OnE ElsE Can DElivER. an ExpERiEnCE nO OnE

ElsE Can matCH. pROvE it tO yOuRsElF witH a tEst DRivE.

ENgINE Z-FORCE® 48 Z-FORCE® 54

Engine Type 22 HP* Cub Cadet® professional-grade Kohler® Courage® PRO V-Twin OHV 24 HP* Cub Cadet® professional-grade Kohler® Courage® PRO V-Twin OHV

Engine Displacement/Orientation 725cc/vertical

Engine Start Electric

Lubrication/Filter Full pressure w/spin-on oil ﬁlter

DRIVE SYSTEM

Transmission Dual Hydro-Gear™ ZT-2800™ w/oil reservoir and ﬁlter

STEERINg

Lap Bar Control 3-way adjustable lap bars

ChASSIS

Frame Fully welded steel 1.5" x 2.0" tubular section

Front Axle Pivoting steel

Caster Wheel Pivot Bearings Composite bushing

Rear Tow Hitch Optional

ELECTRICAL SYSTEM

Alternator 12V – 15 amp. regulated

Battery 230 cold crank amp.

Safety Systems Operator presence

OPERATION

PTO Clutch Electronic ﬁngertip engagement

Deck Lift Foot-pedal, spring assisted

Seat High-back w/arm rests and gel suspension

Parking Brake Mechanical

Hour Meter Standard

ADDITIONAL SPECIFICATIONS

Forward Speed 8 mph

Reverse Speed 3.5 mph

Front Tires 13" x 5.0" – 6" (rib)

Rear Tires 20" x 10" – 8" (turf) 20" x 10" – 10" (turf)

Turning Radius Zero

Fuel Tank Capacity Single 4.25-gallon tank

Cup Holder w/Utility Bin Standard

Wheelbase 43"

Overall Length 70"

Approx. Weight 722 lbs. 740 lbs.

MOWER DECK

Cutting Width/Blades 48" triple-blade (high-lift) 54" triple-blade (high-lift)

Greasable Spindles Standard

Deck Cutting Height 1.0" – 4.0" (in .25" increments)

Deck Style/Construction 11-gauge, ﬂoating, fabricated w/7-gauge reinforced top plate

Deck Drive System Belt driven, Kevlar®

Anti-Scalping 2 greasable gauge wheels, 1 front roller, 4 striping rear rollers

Deck Wash Patented SmartJet™ high-pressure deck washing system

Deck Attach/Removal QuickAttach™ in seconds, no tools required

WARRANTY†

3-year/180-hr limited warranty

Z-FORCE® SERIES

hEAVY-DUTY ZERO-TURN RIDERS

This brochure is for advertisement purposes only. The product depictions are not meant to be used or relied upon as a substitute for the safety and use information that is published in the respective operator’s

manual. Before operating the machine, read, understand and follow all instructions in the manual and on the machine. Speciﬁcations and programs are subject to change without notice. Images may not

reﬂect dealer inventory and/or unit speciﬁcations.

ATTAChMENTS makE a smaRt CHOiCE EvEn smaRtER.

Dial up the versatility of your rider by adding attachments that let you tackle more of your outdoor chores with conﬁdence and ease.

Twin bagger, mulch kit, rear hitch, rear spreader, lawn sweeper, steel cart, poly cart, lawn dethatcher, lawn spike and plug aerator,

lawn roller, rear engine guard, light kit and snow blade.
