FEATURES

TANK SZ 54

TANK SZ 60

DESIGNED FOR

PROFESSIONAL DAILY USE

ON CHALLENGING TERRAIN.

IDEAL FOR PROPERTIES

UP TO 20 ACRES.

TANK™ SZ

SERIES

†See speciﬁcations for warranty information.

INCREDIBLE MANEUVERABILITY AND CONFIDENCE

With unrivaled stability and precision control, there’s no terrain the TANK SZ

can’t handle. Steering wheel control and four-wheel steering gives more

conﬁdence on hills than ever before. By delivering a quality cut at angles other

riders can’t handle, it’s easy to see what makes the TANK SZ the smartest

choice in commercial zero-turns.

MORE POWER FOR UNMATCHED RESULTS

Kawasaki FX series commercial-grade engines deliver higher horsepower and

maximum torque for enhanced performance. Heavy-duty, remote canister air

ﬁltration system and premium cooling system provide a durable, long-life design.

cubcadet.com

FOUR-wHEEL STEER COmmERCIAL ZERO-TURN RIDERS

IT’S NOT JUST THE TOUGHEST COMMERCIAL

ZERO-TURN. IT’S THE SMARTEST.

Hills once considered impossible to mow on a zero-turn rider are no match for this commercial zero-turn.

With steering wheel control and four-wheel steering, the Cub Cadet TANK SZ offers truly unmatched stability

on all types of terrain. Whether you’re facing two acres or twenty, it easily delivers a professional-grade cut

like never before. There’s truly nothing else on earth like the TANK SZ.

ZERO-TURN WITH

STEERING WHEEL

CONTROL AND FOUR

WHEEL STEERING

POWER STEERING

54" OR 60" FABRICATED

COMMERCIAL-GRADE

SLOPED-NOSE DECK

COMMERCIAL-GRADE

KAWASAKI® FX SERIES

ENGINES

INDUSTRY-LEADING

SUSPENSION COMFORT

SEAT WITH LUMBAR

ADJUST ANGLED BACK

AND ARM RESTS

INDUSTRY’S STRONGEST

HEAVY-DUTY RAIL FRAME

QUICK-ADJUST

STEERING COLUMN

PIVOTING FRONT AXLE

LIMITED 3-YEAR

COMMERCIAL WARRANTY†

WITH NO HOUR LIMITATION

SmARTER FEATURES FOR A bETTER ExPERIENCE. THAT’S THE CUB CADET ADVANTAGE.

UNBEATABLE CORROSION PROTECTION AND DURABILITY

Provides twice the protection against unforgiving environmental conditions

while ensuring even the most complex parts are thoroughly and evenly

coated inside and out with an electronically-applied dual layer of eCoat

and powder. Now that’s a smart investment.

YOUR INDEPENDENT DEALER— EXPERT SERVICE. LOCALLY OWNED.

THE ADVICE, SELECTION AND SUPPORT YOU NEED TO FIND THE RIGHT FIT IS

AT YOUR LOCAL CUB CADET DEALER.

TANK™ SZ SERIES

FOUR-WHEEL STEER COMMERCIAL ZERO-TURN RIDERS

ENGINE TANK SZ 54 TANK SZ 60

Engine Type Commercial-grade Kawasaki® FX Series V-Twin OHV

Engine Displacement/Orientation 852cc/Vertical

Engine Horsepower 27 HP*

Engine Fuel Gasoline

Lubrication/Filter Full pressure w/ spin-on ﬁlter

Cooling System Air

Air Cleaner Heavy-duty canister air ﬁlter

Alternator 12V – 20 amp regulated

Fuel Capacity Twin 7.5-gal. tanks (15-gal. total)

Fuel Gauge Standard (mounted on tank)

DRIVE SYSTEM

Drive System PARKER™ Torqpact 14cc pumps and 280cc wheel motors

Ground Speed Fwd: 11 mph/Rev: 5 mph

Hydraulic Fluid Castrol Edge w/ Syntec Power 5W-50

Hydraulic Fluid Capacity 7 qt. total

Hydraulic Oil Filter Individual ﬁlter cartridges standard

Controls Quick-adjust steering column

Return to Neutral Standard

Braking/Parking Brake Dynamic drum, hand lever control

STEERING

Caster Wheel Pivot Bearings Tapered roller, greasable

Front Axle Pivoting, steerable front wheel w/ cast-iron

CHASSIS

Frame Heavy-duty rail frame 3/8" x 5" laser cut steel w/ tie-down slots

TIRES

Front Tire Size 15" x 6.5" – 8" (turf)

Rear Tire Size

24" x 12"

–

12" (turf) (wide track, smart traction tread/self clean)

DIMENSIONS

Length/Width/Height 86.5" / 49.5" / 73.5" 86.5" / 61.5" / 74"

Wheelbase

54"

Front Track Width 43"

Rear Track Width 50" 52"

Weight (approx.) 1,250 lbs. 1,300 lbs.

MOWER DECK

Deck Size/Type 54" sloped-nose 60" sloped-nose

Deck Style/System Floating

Deck Blades Triple-blade/High-lift blade (standard)

Deck Construction 10-gauge fabricated with 7- and 10-gauge reinforcements

Deck Drive Belt – Kevlar® B-section

Deck Lift Single pedal, spring-assisted

Deck Height Adjustment 1" – 5" (in .25" increments)

Blade Spindle Construction Cast-aluminum

Deck PTO Electronic ﬁngertip engagement

Front Anti-Scalping Wheels/

Nose Roller 2 standard, greasable/2-nose wheels

Rear Anti-Scalp Rollers/Striper Full width, adjustable w/ stability rod

ADDITIONAL SPECIFICATIONS

ROPS

Standard, foldable/2-position lock (ISO 21299, OSHA 1928)

Monitor/Hour Meter

Standard

Seat Type High-back, premium suspension with lumbar adjust angled back

and Elasticity Vibration Control (EVC) comfort control seat w/ arm rests

Cup Holder Standard

Storage Box Standard

Rear Bumper & Hitch Heavy-duty rear bumper w/ hitch standard

WARRANTY†

3-year limited commercial warranty (no hour limitation)

• •

ALSO AvAILAbLE:

• mULCH KIT

• CASTER wHEEL KIT

POWER LIFT

LIGHT KIT

ULTRA

TRACTION

TIRE/RIM

12-VOLT

OUTLET KIT

72" SNOW

BLADE

TRIPLE

BAGGER/DUMP

HOPPER WITH

POWER ASSIST

This brochure is for advertisement purposes only. The product depictions are not

meant to be used or relied upon as a substitute for the safety and use information

that is published in the respective operator’s manual. Before operating the machine,

read, understand and follow all instructions in the manual and on the machine.

Speciﬁcations and programs are subject to change without notice. Images may not

reﬂect dealer inventory and/or unit speciﬁcations.

* As rated by Kawasaki, horsepower tested in accordance with SAE J1995

and rated in accordance with SAE J2723 and certiﬁed by SAE International

† See your local Cub Cadet Independent Dealer for warranty details.

Cub Cadet commercial products are intended for professional use.

ATTACHmENTS

THAT BOOST PRODUCTIVITY

ALL YEAR ROUND

Whether you’re working through the heat of

summer or the dead of winter, our attachments

are made to boost your earning potential the

whole year through. So you can maximize your

proﬁts while getting the best results possible.
