Cub Cadet CC 760 Guide de configuration

CUB CADET LLC, P.O. BOX 361131 CLEVELAND, OHIO 44136-0019

Printed In USA

Il l u s t r a t e d Pa r t s Ma n u a l

Form No. 769-05937

(February 22, 2010)

33” Wide Cut Mowers — CC 760 ES, CC 760

Thank you for purchasing a Cub Cadet Wide Cut Mower. It was

carefully engineered to provide excellent performance when

properly operated and maintained.

All information in this manual is relative to the most recent

product information available at the time of printing. Please be

aware that this Illustrated Part’s Manual may cover a range of

product specifications for various models.

Components listed and/or illustrated in this manual may not be

applicable to all models. We reserve the right to change product

specifications, designs and equipment without notice and

without incurring obligation.

Throughout this manual, all references to right (RH) and left (LH)

are observed from the operating position.

Thank You

0637 Black

4021 Yellow (Cub Cadet)

0499 Beige (Cub Cadet)

0685 Blue (Cub Cadet)

0691 Black Jack (Cub Cadet Commercial)

To The Owner

Drive and Deck ........................................................ 4

CC 760 ES Dash ........................................................ 6

CC 760 Dash............................................................. 8

CC 760 ES Label Map..............................................10

CC 760 Label Map...................................................11

Transmission...........................................................12

CC 760 ES Engine ....................................................14

CC 760 Engine ........................................................ 22

Table of Contents

Record Product Information

To ease in ordering replacement parts, please locate the model

plate on the equipment and record the information in the

provided area to the right. You can locate the model plate by

looking beneath the seat.

Mo d e l nu M b e r

se r I a l nu M b e r

Painted Parts

When ordering painted service parts, a four digit color suffix must be added to the part number (e.g. 783-XXXXX-0637).

Please refer to the table below for current color codes:

This page intentionally left blank.

14 14

3921

940

33 35

53 45

15 59

22 17

Drive and Deck

Ref. Part Number Description

117840 Transaxle Mounting Bracket

2918-04639 4 Speed Drive Assembly, Tecumseh

3710-0176 Hex Head Cap Screw, 5/16-18 x 2.75

4710-0347 Hex Head Cap Screw, 3/8-16 x 1.75

5710-0376 Hex Head Cap Screw, 5/16-18 x 1.00

6710-04187 Screw, 1/4-15 x 0.50

7710-04377 Hex Head Cap Screw, 7/16-20 x 2.75

8710-0513 Hex Head Cap Screw, 1/4-28 x .625

9710-0520 Hex Head Cap Screw, 3/8-16 x 1.50

10 710-3008 Hex Head Cap Screw, 5/16-18 x .75

11 710-3015 Hex Head Cap Screw, 1/4-20 x .75

12 911-1000 Belt Keeper, .25 DIA X 3.0

13 712-04063 Flangelock Nut, 5/16-18

14 712-04064 Flangelock Nut, 1/4-20

15 712-04065 Flangelock Nut, 3/8-16

16 712-0700 Flange Nut, 9/16-18

17 914-0145 Click Pin, .092 x 1.64 LG

18 718-04407 Spline Pulley Hub, 5/8

19 720-0142 Grip, Black

20 731-05766 Trailshield, 8.35 x 19.17

21 732-04409 Extension Spring, Wheel Drive

22 732-04443A Extension Spring, Brake

23 736-0105 Washer, Spring, .401 x .870 x .063

24 736-0270 Washer, Bell, .265 x .75 x .062

25 736-0322 Washer, Flat, .450 x 1.250 x .164

26 736-04256 Washer, Flat, .39 x .87 x .06

27 918-04438B Drive Spindle Assembly

28 738-04166 Spacer, Shoulder, .5000 x .1475

29 747-04635A Belt Keeper Rod

30 747-04673 Coupling Link, .188

31 747-04678A Brake Spring Mounting Rod

32 954-04145A V Belt. 4L 64.2

33 756-04129B Idler Pulley, 4.25 DIA

34 756-04258 Flat Sheave, DIA 7.75

35 756-04260 Engine Pulley, 3.20 x 4.35 DIA

36 756-04280 Idler Pulley, 3.50 DIA

37 787-01469B Lower Shaft Lever

Ref. Part Number Description

38 787-01470A Upper Shaft Lever

39 787-01473 Belt Keeper, .375 x 2.00

40 787-01523A Wheel Drive Idler Bracket

41 918-04439B Spacer Spindle Assembly

42 931-04244 Chute Deector Assembly

43 631-04252 Mulch Cover

44 987-02420 Idler Arm Assembly

45 687-02476 Deck Assembly

46 710-04484 Screw, 5/16-18 x .750

47 710-0451 Bolt, Carriage, 5/16-18 x .750

48 710-0514 Hex Head Cap Screw, 3/8-16 x 1.00

49 710-0560 Screw, Carriage, 3/8-16 x 1.75

50 710-3184A Hex Head Cap Screw, 3/8-16 x 2.00

51 712- 0417A Flange Nut, 5/8-18

52 912-3017 Hex Nut, 3/8-16

53 732-04406 Extension Spring, Timing Belt

54 732-04452 Extension Spring, Deck Brake

55 938-0347 Shoulder Spacer, .625 ID x .169

56 738-04162A Shoulder Spacer, .8840 x .190

57 942-04154A 2 in 1 Blade

58 754-04136 Timing Belt, .315 x .787

59 954-04139 Aramid V Belt, 72.2

60 756-04129B Idler Pulley, 4.25" DIA

61 756-0616 Idler Pulley, V-Type, 5.0 DIA

62 787-01440 Timing Idler Bracket

63 711- 0 4027 Deector Pin

64 726-04009 Push Cap

65 732-04012 Deector Torsion Spring

66 787-01017A Deector Hinge Bracket

67 634-04349-0931 Wheel, 16 x 4 x 8

68 710-0627 Hex Screw, 5/16-24 x .750

69 736-0242 Washer, Bell, .340 x .872 x .060

70 912-0641 Nut, Hex, M16-1.5

71 921-04041 Water Nozzle Adaptor

72 736-0225 Washer, Lock, 5/8

73 737-04003D Deck Water Nozzle

—977S30145 Danger Label (Not Shown)

CC 760 ES Dash

71 70

414

65 7

27 33

CC 760 ES Dash

Ref. Part Number Description

1687-02426 RH Lever Assembly Bracket

2687-02427 LH Lever Assembly Bracket

3710-0572 Screw, Carriage, 5/16-18 x 2.25

4710-0599 Screw, 1/4-20 x 0.500

5710-0606 Hex Screw, 1/4-20 x 1.50

6710-1237 Screw, #10-32 x 0.625

7712-04063 Nut, Flangelock, 5/16-18

8912-0442 Lock Nut Cap, 1/4-20

9720-0274 Grip, 1.0 ID x 5.0 LG

10 720-04072A Star Knob, 5/16-18

11 725-0157 Cable Tie, 3/16 x .05 x 7.4

12 938-0140 Screw, Shoulder, .435 x .178-5/16 x .56

13 938-1226 Screw, Shoulder, .375 x 1.355 x 1/4-20

14 946-04604 Throttle/Choke Cable, 38.0 x 1.1 EXT

15 946-04606 RH Brake Cable, Tecumseh Trans.

16 946-04608 LH Brake Cable, Tecumseh Trans.

17 946-04609 Wheel Clutch Cable

18 946-04610 Deck Clutch Cable

19 749-04330 Lower Handle

20 749-04331 Upper LH Handle

21 749-04332 Upper RH Handle

22 749-04333 Adjustable Handle Brace

23 751B221535 Casing Clamp

24 787-01490A RH Cable Mount Bracket

—787-01491A LH Cable Mount Bracket

25 687-02255B Frame Assembly, Tecumseh

26 687-02265 Front Deck Lift Assembly

27 687-02419 Rear Deck Lift Assembly

28 710-04312 Hex Screw, 5/16-18 x .50

29 710-0604A Screw, 5/16-18 x 0.625

30 710-0627 Hex Screw, 5/16-24 x .750

31 914-0145 Click Pin, .092 x 1.64 LG

32 720 - 0311 Grip Handle, 1/2

33 731-05791 Plastic Spacer, .63 ID x .75 LG

34 732-04418A Deck Height Lever

35 736-0242 Washer, Bell, .340 x .872 x .060

36 736-0343 Washer, Flat, .330 x 1.25 x .120

37 936-0351 Washer, Flat, .760 ID x 1.50 OD

38 937-3000 Drive Lube Fitting, 3/16

39 741-0660A Flange Bearing, .760 x .941 x 1.0

Ref. Part Number Description

40 787-01496 Height Adjustment Bracket

41 787-01507 Fuel Tank Mount Bracket

42 787-01510 Link Pivot Bracket

43 787-01521 Lever Pivot Bracket

44 734-04263 Caster, Wheel, 8 x 1.75

—941-0706 Bearing, Flange w/ftg

45 687-02263 Wheel Caster Bracket

46 712-04065 Nut, Flangelock, 3/8-16

47 738-04216A Bolt, Shoulder, .625 x 2.515 x 3/8-16

48 710-0136 Hex Screw, 1/4-20 x 1.75

49 710-0896 Screw, 1/4-14 x 0.625

50 712-3006 Nut, Hex, 1/4-20

51 931-05684 Belt Cover

52 731-05937 Handle Panel, Black

53 736-0270 Washer, Bell, .265 x .75 x .062

54 936-0463 Washer, Flat, .25 x .630 x .0515

55 787-01548 Hour Meter and Key Handle Panel

56 731-05927 Fuel Tank Cover

57 738-04282 Screw, Shoulder, 1/4-20 x .32 x 1.8

58 951-10514 Fuel Cap

59 951-10541 Fuel Tank

60 710-1315 Screw, 3/8-16 x 1.250

61 726-0205 Hose Clamp, .490 DIA.

62 751-10349 Fuel Hose, Low Permeation, 1/4

63 951-10517A Oil Drain

64 751-3141-14 Extension Hose

65 710-04666 Hex Head Flange, 1/4-20 x .75

66 710-0642 Screw, 1/4-20 x 0.750

67 925-1707D Battery, 155 CCA WET

68 712-0271 Sems Nut, 1/4-20

69 712-04064 Nut, Flangelock, 1/4-20

70 925-04022B Hour Meter

71 925-04228 Key Switch

72 725-04439 Solenoid, 12V, 100 AMP

73 747-04657 Battery Hold Down Strap

74 925-1745A Key

—925-2054A Key, Yellow

—925-04476 Wiring Harness (Not Shown)

—725-04478 Starter Wire (Not Shown)

—712-0266A Nut, Jamlock, 3/8-16 (Not Shown)

CC 760 Dash

414

27 33

CC 760 Dash

Ref. Part Number Description

1687-02426 RH Lever Assembly Bracket

2687-02427 LH Lever Assembly Bracket

3710-0572 Screw, Carriage, 5/16-18 x 2.25

4710-0599 Screw, 1/4-20 x 0.500

5710-0606 Hex Screw, 1/4-20 x 1.50

6710-1237 Screw, #10-32 x 0.625

7712-04063 Nut, Flangelock, 5/16-18

8912-0442 Lock Nut Cap, 1/4-20

9720-0274 Grip, 1.0 ID x 5.0 LG

10 720-04072A Star Knob, 5/16-18

11 725-0157 Cable Tie, 3/16 x .05 x 7.4

12 938-0140 Screw, Shoulder, .435 x .178-5/16 x .56

13 938-1226 Screw, Shoulder, .375 x 1.355 x 1/4-20

14 946-04604 Throttle/Choke Cable, 38.0 x 1.1 EXT

15 946-04606 RH Brake Cable, Tecumseh Trans.

16 946-04608 LH Brake Cable, Tecumseh Trans.

17 946-04609 Wheel Clutch Cable

18 946-04610 Deck Clutch Cable

19 749-04330 Lower Handle

20 749-04331 Upper LH Handle

21 749-04332 Upper RH Handle

22 749-04333 Adjustable Handle Brace

23 751B221535 Casing Clamp

24 787-01490A RH Cable Mount Bracket

—787-01491A LH Cable Mount Bracket

25 687-02255B Frame Assembly, Tecumseh

26 687-02265 Front Deck Lift Assembly

27 687-02419 Rear Deck Lift Assembly

28 710-04312 Hex Screw, 5/16-18 x .50

29 710-0604A Screw, 5/16-18 x 0.625

30 710-0627 Hex Screw, 5/16-24 x .750

Ref. Part Number Description

31 914-0145 Click Pin, .092 x 1.64 LG

32 720 - 0311 Grip Handle, 1/2

33 731-05791 Plastic Spacer, .63 ID x .75 LG

34 732-04418A Deck Height Lever

35 736-0242 Washer, Bell, .340 x .872 x .060

36 736-0343 Washer, Flat, .330 x 1.25 x .120

37 936-0351 Washer, Flat, .760 ID x 1.50 OD

38 937-3000 Drive Lube Fitting, 3/16

39 741-0660A Flange Bearing, .760 x .941 x 1.0

40 787-01496 Height Adjustment Bracket

41 787-01507 Fuel Tank Mount Bracket

42 787-01510 Link Pivot Bracket

43 787-01521 Lever Pivot Bracket

44 734-04263 Caster, Wheel, 8 x 1.75

—941-0706 Bearing, Flange w/ftg

45 687-02263 Wheel Caster Bracket

46 712-04065 Nut, Flangelock, 3/8-16

47 738-04216A Bolt, Shoulder, .625 x 2.515 x 3/8-16

48 710-0896 Screw, 1/4-14 x 0.625

49 931-05684 Belt Cover

50 736-0270 Washer, Bell, .265 x .75 x .062

51 936-0463 Washer, Flat, .25 x .630 x .0515

52 787-01540 Handle Panel

53 938-1225 Screw, Shoulder, .3175 x .188, 1/4-20

54 951-10480 Fuel Tank

55 951-10514 Fuel Cap

56 710-1315 Screw, 3/8-16 x 1.250

57 726-0205 Hose Clamp, .490 DIA.

58 751-10349 Fuel Hose, Low Permeation, 1/4

59 951-10517A Oil Drain

60 751-3141-14 Extension Hose

777D14227

777D13924

777D14283

777I22759

777I22760

777I22793

777I22808

777I22809

777I22814

777I22815

777S30117

777S30145

777X43688

Model CC 760 ES

Autres manuels pour CC 760

Table des matières

Autres manuels Cub Cadet Tondeuse à gazon

Cub Cadet

Cub Cadet Zero-Turn Commercial Riding Mower Manuel d'utilisation

Cub Cadet

Cub Cadet i1046 Manuel utilisateur

Cub Cadet

Cub Cadet Tank SZ Manuel utilisateur

Cub Cadet

Cub Cadet SERIES 3000 TRACTOR GT 3200 Manuel utilisateur

Cub Cadet

Cub Cadet 19A30003100 Manuel utilisateur

Cub Cadet

Cub Cadet LTX 1050 Manuel utilisateur

Cub Cadet

Cub Cadet 1215 Manuel utilisateur

Cub Cadet

Cub Cadet 18M Manuel utilisateur

Cub Cadet

Cub Cadet LTX 1040 Manuel utilisateur

Cub Cadet

Cub Cadet Hydrostatic Zero-Turn Commercial Riding Mower Professional Turf... Manuel d'utilisation

Cub Cadet

Cub Cadet Zero-Turn Commercial Riding Mower Professional Turf... Manuel d'utilisation

Cub Cadet

Cub Cadet XR5 Manuel d'installation

Cub Cadet

Cub Cadet 18M Manuel utilisateur

Cub Cadet

Cub Cadet 436 Series Manuel utilisateur

Cub Cadet

Cub Cadet LTX1050KH Manuel utilisateur

Cub Cadet

Cub Cadet LTX 1140 Manuel utilisateur

Cub Cadet

Cub Cadet GTX 1054 Manuel utilisateur

Cub Cadet

Cub Cadet LTX 1045 Manuel utilisateur

Cub Cadet

Cub Cadet 148 Manuel utilisateur

Cub Cadet

Cub Cadet 188 Manuel utilisateur

Cub Cadet

Cub Cadet 950-959 Manuel utilisateur

Cub Cadet

Cub Cadet Sportsman Forest 800 Manuel utilisateur

Cub Cadet

Cub Cadet 17AF4BFP009 Manuel utilisateur

Cub Cadet

Cub Cadet Z-Force LZ Manuel utilisateur

Manuels Tondeuse à gazon populaires d'autres marques

RHINO

RHINO 1958 Manuel utilisateur

Wolf Garten

Wolf Garten Compact plus 40 B Manuel utilisateur

Craftsman

Craftsman 917.378461 Manuel utilisateur

GGP ITALY SPA

GGP ITALY SPA CR/CS 434 SERIES Manuel utilisateur

Challenge

Challenge CH18V2 Instructions de fonctionnement

TALEN TOOLS

TALEN TOOLS AVR HGM30 Manuel utilisateur

DEWEZE

DEWEZE ATM-725 Manuel d'utilisation

Weed Eater

Weed Eater 180083 Manuel utilisateur

Husqvarna

Husqvarna Poulan Pro PP185A42 Manuel utilisateur

Better Outdoor Products

Better Outdoor Products Quick Series Manuel utilisateur

MTD

MTD 795, 792, 791, 790 Manuel utilisateur

Toro

Toro Groundsmaster 3505-D Manuel utilisateur

Dennis

Dennis FT 610 Manuel utilisateur

AIRFORCE

AIRFORCE F-15 Gen 3 Manuel utilisateur

MTD

MTD 126-220-000 Manuel utilisateur

Toro

Toro 74806 Manuel utilisateur

Stihl

Stihl RMA 443 PV Manuel utilisateur

Yard-Man

Yard-Man 3700-0 Manuel utilisateur
