CTX PV511 Manuel utilisateur

English

Usage Notice

Precautions................................................................................... 2

Introduction

About the Product ......................................................................... 3

Package Overview ....................................................................... 4

Installation

Product Overview ......................................................................... 5

Start Your Installation.................................................................... 7

User Controls

Front Bezel Controls ..................................................................... 10

How to Use the OSD Menus ........................................................ 12

On-Screen Display Menus........................................................... 13

Appendices

Troubleshooting ............................................................................ 16

Product Dimensions ..................................................................... 17

Compatibility Modes ..................................................................... 18

Pivot Function (Optional) .............................................................. 19

Table of Contents

English

Usage Notice

Warning- To prevent the risk of fire or shock hazards, do not

expose this product to rain or moisture.

Warning- Please do not open or disassemble the product as this

may cause electric shock.

Precautions

Follow all warnings, precautions and maintenance as recom-

mended in this user’s manual to maximize the life of your unit.

Do:

qTurnofftheproductbeforecleaning.

qUse only a dry soft cloth or clean room wiper when cleaning the

LCDpanelsurface.

qUse a soft cloth moistened with mild detergent to clean the

display housing.

qUseonlyhigh quality andsafetyapprovedAC/DCpower

adapter.

qDisconnect the power plug from AC outlet if the product is not

used for a long period of time.

Don’t:

qDo not touch the LCD panel surface with sharp or hard objects.

qDo not use abrasive cleaners, waxes or solvents for your

cleaning.

qDo not operate the product under the following conditions:

- Extremely hot, cold or humid environment.

- Areas susceptible to excessive dust and dirt.

- Near any appliance generating a strong magnetic field.

- Place in direct sunlight.

English

Introduction

AbouttheProduct

Having a 15.1” inch flat panel screen with an active, thin-film

transistor (TFT) liquid crystal display (LCD) , this product also demon-

strates following outstanding features.

qDirect analog RGB input

q15.1” diagonal screen size

q16.7 million displayable colors

q1024 x 768 resolution

qXGA/ SVGA/ VGA/ VESA/ Mac/ NEC PC-98 compatible

q24~60kHz horizontal scan

q56~75Hzhighrefreshrate

qAuto adjustment capability

qHigh quality full screen re-scaling

qMultilingual OSD menus in five languages: English, French,

German,Spanish,and Italian

qUSB hub with 1 upstream and 4 downstream ports on the

stand base

qVESA DDC 1/2B data communication

qVESA DPMS power saving

qStand with tilt and swivel functions

-Cablemanagementdevice

qPivot function: landscape and portrait display mode (optional,

needpivotsoftware)

English

Package Overview

LCDDisplay

VGA Signal Cable

USBUpstream Cable

Installation Diskette

(forDDC1/2B) Pivot®Software

(optional) NECPC-98

Adapter(optional)

PowerAdapter

PowerCord

User’sManual WarrantyCard

MacMutliform

Adapter(optional)

English

Power

Installation

Product Overview

uMain Unit

uRear View

LCD Display

Stand UserControls

CableManagement

Device

English

uConnection Ports

Display Rear Connectors

Display Stand Back USB Hub Ports

USB Upstream Port

4 USB Downstream

Ports

Display Input-B

DC Power-In

Display Input-A

English

StartYourInstallation

Notice: To ensure the LCD display can work well with your computer,

please configure the display mode of your graphic card to make it

less than or equal to 1024 x 768 resolution and make sure timing

of the display mode is compatible with the LCD display. We have

listed the “Compatibility Modes” of this LCD display in appendices

for your reference.

* For Macintosh, use the Mac adapter.

VGA Cable

Power Adapter

Power Cord

Mac Adapter *

uConnecting the Display

To setup this display, please refer to the following figure and procedures.

1. Be sure all equipment is off.

2. Connect the VGA signal cable from display input-A or display input-B

connector to the 15-pin connector of your host computer and tighten the

screws.

3. Connect the power adapter to the power connector; plug one end of the

power cord into the power adapter, and then the other end into an electri-

cal outlet.

English

uUSB Hub Port Descriptions





USB Downstream Ports

These four USB ports are available for connecting USB type peripheral

devices such as keyboard, mouse, printer and so on.

USB Upstream Port

This Port is for connecting the USB Upstream cable to computer’s or

other hub’s USB port.

English

uCable Management

1. Route the cables through the cable management device.

2. Connect the cables to their respective connectors on the back panel of

the display.

CableManagement

Device

English

User Controls

FrontBezel Controls

No./ Icon Control Function

MENU Menu button To pop up the OSD menus.

SELECT/AUTO Select/Auto

Select

- To select the adjust-

ment items from OSD menus.

Auto

- To activate the “Auto

Adjustment” function to obtain

an optimum image.

3Brightness Minus/Minus 1.Decreases the brightness of

the display image.

2. Decreases value of the

adjustment items.

4Brightness Plus/Plus 1.Increases the brightness of

the display image.

2. Increases value of the

adjustment items.

  
