Quick Installation Guide
sales@ctcu.com
ICR-W401
4G LTE WiFi IEEE 802.11b/g/n 2T2R Router
1
ICR-W401 QIG
Version 0.9 October, 2019
2019 CTC Union Technologies Co., LTD.
All trademarks are the property of their respective owners.
Technical information in this document is subject to change without notice.
CTC Union Technologies Co.,Ltd.
Far Eastern Vienna Technology Center
(Neihu Technology Park)
8F, No. 60 Zhouzi St.,
Neihu, Taipei 114, Taiwan
3
Table of Contents
Introduction..................................................................................4
Package List.................................................................................4
Features........................................................................................4
Specifications...............................................................................5
Panel .............................................................................................7
Earth Ground Connection............................................................8
LED Indicators..............................................................................8
CLI & Web Basic Operation.........................................................9
Installation..................................................................................10
Regional Code and Band Information.......................................11
Application..................................................................................11
4
Introduction
ICR-W401 are compact, lightweight and high performance 4G-LTE
(Long-Term Evolution) routers with IEEE 802.11b/g/n WiFi function. They
are equipped with one Ethernet port and one WAN port for fast
Ethernet connections and also support uplink to 2G/3G/4G mobile
networks.
Integrated with WAN, LAN, SIM, VPN, Firewall, built-in DI/DO and
serial port services, ICR-W401 routers are easy to be configured through
embedded Web user interface. Additionally, they adopt higher level of
industrial grade design which is the ideal solution for Industrial Internet
of Things (IIoT) and M2M (Machine-to-Machine) applications, such as
remote controlling and monitoring, bus ticketing collection system, CCTV,
SCADA, digital signage, kiosk and intelligent traffic systems.
Package List
One ICR-W401 device
Two WiFi antennas
Two LTE antennas
One GPS antenna
DIN Rail kit
Features
Full native mode performance
Optical connectors: LC / UPC
Passive model requires no power
Protocol transparent, no limitation
Utilizes industry standard ITU CWDM wavelength
High isolation WDM
Low insertion loss
Wide operation wavelength range
Environmentally stable
5
Specifications
Interface
1 x Micro SIM card slot (push-push type)
2 x SMA connectors for detachable LTE antenna
2 x RP-SMA for WiFi antenna
1 x WAN (10/100Base-TX) RJ-45
1 x LAN (10/100Base-TX) RJ-45
1 x DI (non-isolated) and 1 x DO (non-isolated)
1 x RS-232 for serial COM port or console configuration
1 x GPS detachable antenna
Reset push button
LTE Interface
4G LTE: FDD-LTE, TDD-LTE
3G: WCDMA
2G: GSM/EDGE
GNSS: GPS
LTE Data Rate: Cat 4; 150Mbps (Download), 50Mbps (Upload)
1 x Micro SIM card slot (push-push type)
WiFi Interface
IEEE802.11b/g/n WiFi standard
Support AP or Station mode
2 x RP-SMA for WiFi antenna
2T2R 300Mbps wireless operation rate
2.4GHz radio for wireless
6
Power
Support removable terminal block
Power input: 12/24/48VDC (9.6~60VDC)
Power consumption: 7W (Max.)
Mechanical
IP30 grade housing protection
Fanless design
Dimensions: 30 mm (W) x 92 mm (H) x 75 mm (D)
Mounting: DIN rail mounting or Wall mounting (Optional)
Weight: 400g
Environmental
Operating Temperature: -30°C~70°C
Storage Temperature: -40°C~85°C
Humidity: 10%~95% (Non-condensing)
MTBF (MIL-HDBK-217): 271,952 Hours
Certification
EMC: CE
EMI: EN301 489, FCC
EMS: EN301 489
Radio: EN301511, EN301908-1, EN301908-2, EN301908-13, EN300328,
EN303413, EN62311
Shock: IEC 60068-2-27
Freefall: IEC 60068-2-32
Vibration: IEC 60068-2-6
7
Panel
Index No.
Description
1
Fast Ethernet RJ-45 LAN port
2
Fast Ethernet RJ-45 WAN or LAN port
3
Terminal block for PWR, DI, DO, RS232
4
LED indicators (PWR, Mobile, FN)
5
Micro SIM card slot
6
Mobile MAIN connector
7
Mobile AUX connector
8
GPS connector
9
Earth grounding
10
WPS/Reset push button
11
SMA antenna connectors
3
2
1
4
11
10
11
9
7
5
6
8
Figure 1. Front Panel
Figure 2. Left Side Panel
Figure 3. Right Side Panel
8
Earth Ground Connection
An earth ground connector is provided on the left side panel.
Grounding the device can help to release leakage of electricity to the
earth safely so as to reduce injuries from electromagnetic interference
(EMI). Prior to connecting to the power, it is important to connect the
ground wire to the earth. Follow steps below to install ground wire:
Step 1. Prepare one appropriate ground screw and one grounding cable.
Step 2. Attach the grounding screw to the ring terminal of the grounding
cable. Make sure that the grounding cable is long enough to
reach the earth.
Step 3. Use a screwdriver (or other tools) to fasten the grounding screw
on the earth ground hole securely.
LED Indicators
LED
Color
Status
Meaning
PWR
Green
On
The system is receiving power and
up.
Off
The system is down.
Mobile
Green
On
High signals.
Slow Blinking
Medium signals or reset
Fast Blinking
Low signals or reset to default
Heart Beat
WPS processing
Off
Error
FN
Green
On
VPN connected.
Slow Blinking
Internet connected or reset
Fast Blinking
System rebooting or reset to
default
Heart Beat
WiFi connected
Figure 4. Grounding the Device
Ring-type
terminal
Fork-type
terminal
9
CLI & Web Basic Operation
ICR-W401 are 4G-LTE cellular routers with WiFi function for
industrial uses. Initial assignment of IP address may be accomplished via
Command Line Interface (CLI). Once the desired IP address has been
configured, a web browser can be used to configure the device through
a more easy-to-use graphical user interface (GUI).
To use CLI, you need to prepare a RS232/DB9 console cable. First,
connect one end of the RS-232 cable correctly to the terminal block (TXD,
RXD, GND pins for RS232) and the other end to PC COM port for RS-232
signal input. If your PC does not have a RS-232 signal input interface, a
USB converter is needed. Then, apply power to the router. Configure the
terminal emulation software (such as PUTTY) as follows:
115200 speed, 8 data bits, no parity, 1 stop bit, no flow control
At the "Username:" prompt, enter 'admin' (lower case, no quotes).
Just press Enter when prompted for password.
To set the desired IP address and subnet mask (For Example: sets
IP to 192.168.0.5, subnet to 255.255.255.0), issue the following
commands:
ICR-W401# lan
ICR-W401/ lan#ipv4
ICR-W401/ lan/ipv4#ip
ICR-W401/ lan/ipv4/ip#addr 192.168.0.5
ICR-W401/ lan/ipv4/ip#mask 255.255.255.0
ICR-W401/ lan/ipv4/ip#apply
Then, press Enter.
Once the desired IP address has been configured, you can login
the device via web browser using the configured IP address. For
complete operation of the device via Web GUI, please refer to the
manual.
NOTE: The factory default IP address is 10.1.1.1 with mask
255.255.255.0
10
Installation
The router can be installed on the DIN rail or mounted on the wall.
When installing the DIN rail or wall-mounting bracket, be sure to
correctly align the orientation pin.
Figure 5. DIN Rail Figure 6. Wall Mount
The router with DIN Rail bracket has a steel spring in the upper rail
of the bracket. This spring is compressed for mounting and un-mounting
by applying downward force.
Figure 7. Mounting Figure 8.Un-mounting
