CRT Millenium Manuel utilisateur
millenium
MOBILE CB TRANSCEIVER AM- FM
CITIZEN BAND EUROPEAN MULTI-NORMS
USER MANUAL
copyright CRT France 2017
Downloaded from www.cbradio.nl
2
3
4
1、Introduction
Thank you for your choose and buy the CRT MILLENIUM CB radio . In order
to make your CB Radio to use in the best condition, please read this
manual in detail.CRT MILLENIUM is a small, simple operation and
convenient vehicle CB Radio which has good performance.
Up/down keys on the microphone
Scan channel
LCD display
Auto ASQ/SQ adjustable
RF GAIN
External Speaker
2、Installation instructions
Check the materials before the installation, car charger is
connected to the car's 12 v power supply socket，the radio’s positive
and negative electrode connected to the car charger’s. Power
supply support 12 V to 13.8 V. Check all wiring are in good condition
before starting, ensure do not short circuit, ensure the radio can
boot running normally.
5
3、Control panel function
Front view
No Name Short Press
Function
Long Press
Function
①Microphone
socket
②A/F AM/FM Mode
Switch Scan Function
③LCD Display
④Power On/Off
Volume
6
4、Operation
4.1 Power On/Off the radio
1. Turn VOL switch clockwise to power on the radio, the LCD
full screen display after spectrum model 1 s into the channel
state.
2. Turn the VOL Knob counterclockwise, until it clicks. The
radio is power off.
4.2 Volume Control
Turn clockwise to increase volume, turn counterclockwise to
decreases volume.
4.3 Channel Selection
1. Shortly press microphone【UP】or【DOWN】to change
working channel.
⑤
、
⑥
Channel
UP/DOWN
select
⑦EMG(Emergen
cy Channel ）
9/19 Channel
Switch
⑧RFG Enter RF GAIN
Model
⑨SQ/ASQ
Function Switch
Enter SQ (ASQ)
Level Switch
Switch To ASQ
Mode
7
2.Hold microphone 【UP】or【DOWN】to change working
channel fast.
4.4 Squelch level control
1.Shortly press【SQ】,until LCD shortly displays SQ and then
display X.X。X.X stands for the SQ level
0.F SQ off
0.1 Lowest SQ level
… …
2.8 Highest SQ level
2.Press microphone【UP】/【DOWN】shortly to change SQ
level.
3.Hold microphone【UP】/【DOWN】to change the SQ level
fast.
4.Hold【SQ】or wait for 3 seconds to store and exit.
4.5 ASQ control（9 level）
1. Hold【SQ】key，until LCD display AQ，the ASQ function
is turned on. The LCD will display A.X。X stands for the
ASQ level。
A.1 Lowest ASQ level
…
…
A.9 Highest ASQ level
8
LC »
2. Shortly press microphone【UP】/【DOWN】to change
ASQ level.
3. Hold microphone【UP】/【DOWN】to change ASQ level
fast.
4. Hold【SQ】or wait for 3 seconds to store and exit.
4.6 Modulation Type
Shortly press【A/F】key to switch between AM/FM mode
and the LCD displays the selected mode.
4.7 RF GAIN control
1.Shortly press【RFG】key，LCD displays R and the present
RF GAIN level flashes.
2.Shortly press microphone【UP】/【DOWN】to change the
level.
3.Shortly press【RFG】key to exit RF GAIN level control.
4.8 Emergency Channel
1.Shortly press【EMG】key to choose CH9，the channel
number flashes.
2.Shortly press 【EMG】key again to choose CH19，the
channel number flashes.
3. Shortly press【EMG】key third time to return to last normal
channel.
9
4.9 Key Lock
1.Hold【EMG】key for over 2 seconds to lock the keys, LCD
displays “LC”.
2.Hold【EMG】for over 2 seconds again to unlock the keys,
LCD displays “OF”.
4.10 Scan Function
1.Hold【A/F】to start scan function，LCD displays“SC”.
2.Press microphone【UP】/【DOWN】can choose scanning
clockwise or counterclockwise.
3.Press【A/F】or【PTT】key to exit scan function.
4.11 Changing the CB-Standard
1. Hold【A/F】while powering the radio on, until LCD
displays the norms.
2.Press microphone【UP】/【DOWN】to choose wanted
Norms.
3.Power off and power on again
Standard Channels Fequency Range
EU 40FM/40AM 26.965-27.405MHZ
CE 40 FM 26.965-27.405MHZ
UK 40 FM 27.60125-27.99125MHZ
