Crompton Integra 1540 Manuel utilisateur

Installation and Operating Manual

Switchboard Integra 1540, 1000, 0640, 0440

0340 & 0240 Digital Metering Systems

http://energy.tycoelectronics.com

Energy Division

Tyco Electronics UK Limited

Crompton Instruments

Freebournes Road, Witham, Essex, CM8 3AH, UK

Tel: +44 1376 509 509

Fax: +44 1376 509 511

Crompton

Switchboard Integra

Multifunctional metering for

Three-phase Electrical Systems

Models 1540, 1000, 0640, 0440, 0340, 0240

Operating Instructions

Important safety information is contained in the seperate installation leaflet.

Installers must familarise themselves with this information before installation

Crompton Instruments

Freebournes Road

Witham

Essex

CM8 3AH

England

Tel: +44 (0) 1376 509 509

Fax: +44 (0) 1376 509 511

E-Mail: [email protected]

Integra 1540, 1000, 0640, 0440, 0340, 0240 Issue 1 04/03

Contents Page

1 Introduction 5

1.1 Unit Characteristics 6

1.1.1 0240 6

1.1.2 0340 6

1.1.3 0440 and 0640 6

1.1.4 1000 7

1.1.5 1540 8

1.2 Maximum Power 9

1.3 Secondary Voltage 9

1.4 Demand Calculation 9

1.5 RS485 Serial Option 10

1.6 Pulse Output Option 10

1.7 Analogue Output Option 10

2 Display Screens 11

2.1 Layout 11

2.2 Start Up Screens 11

2.3 System Screen 12

2.4 System %THD Screen 13

2.5 Line to Neutral Voltages 13

2.6 Line to Neutral Voltage %THD 13

2.7 Line to Line Voltages 14

2.8 Line to Line Voltages %THD 14

2.9 Line Currents 14

2.10 Line Currents %THD 15

2.11 Neutral Current, Frequency and Power Factor 15

2.12 Power 15

2.13 Active Energy (kWh) 16

2.14 Reactive Energy (kVArh) 16

Integra 1540, 1000, 0640, 0440, 0340, 0240 Issue 1 04/03

Contents Page

2.15 Demand 17

2.16 Maximum Demand 17

2.17 Over Range 17

2.18 kWh and kVArh Display Range 18

2.19 Error Messages 18

3 Setting up 18

3.1 Introduction 18

3.2 Number Entry Procedure 19

3.3 Access 21

3.3.1 Access with No Password Protection 21

3.3.2 Access with Password Protection 21

3.4 Changing the Password 23

3.5 Full Scale Current 24

3.6 Potential Transformer Primary Voltage 24

3.7 Potential Transformer Secondary Value 26

3.8 Demand Integration Time 27

3.9 Resets 28

3.10 Pulsed Output, Pulse Duration 29

3.11 Pulse Rate 30

3.12 RS485 Baud Rate 31

3.13 RS485 Parity Selection 32

3.14 RS485 Modbus Address 33

3.15 Analogue Output Set Up 34

3.15.1 Introduction 34

3.15.2 Analogue Output Scaling Example 35

3.15.3 Power Factor 36

3.15.4 Phase Angle 39

3.15.5 Parameters available for analogue outputs 40

3.15.6 Reading (Parameter Selection) - A1r or A2r 41

3.15.7 Reading Top – A1rt or A2rt 42

2Integra 1540, 1000, 0640, 0440, 0340, 0240 Issue 1 04/03

Contents Page

3.15.8 Reading Bottom - A1rb or A2rb 43

3.15.9 Output Top – A1ot or A2ot 43

3.15.10 Output Bottom – A1ob or A2ob 43

4 Specification 44

4.1 Display Only Versions 44

4.1.1 Input 44

4.1.2 Auxiliary Power Supply 44

4.1.3 EMC Standards 44

4.1.4 Safety 45

4.1.5 Insulation 45

4.1.6 Environmental 45

4.1.7 Enclosure 45

4.2 Display/Transducer Combined Versions 45

4.2.1 Inputs 45

4.2.2 Auxiliary Power Supply 46

4.2.3 Measuring Ranges 47

4.2.4 Accuracy 47

4.2.5 Reference conditions of influence quantities 47

4.2.6 EMC Standards 47

4.2.7 Safety 48

4.2.8 Insulation 48

4.2.9 Environmental 48

4.2.10 Enclosure 48

4.3 Display/Tranducer Combined 1000 and 1540 48

4.3.1 Inputs 48

4.3.2 Auxiliary Power Supply 49

4.3.3 Accuracy 49

4.3.4 Reference conditions 50

4.3.5 Reference conditions of influence quantities 50

Integra 1540, 1000, 0640, 0440, 0340, 0240 Issue 1 04/03

Contents Page

4.3.6 Nominal range of use of influence 51

quantities for measurands

4.3.7 Functional ranges 51

4.3.8 Screen 51

4.3.9 Standards 51

4.3.10 Safety 52

4.3.11 Insulation 52

4.3.12 Environmental 52

4.3.13 Enclosure 52

4.3.14 Serial Communications Option 52

4.3.15 Active Energy Pulsed Output Option 53

4.3.16 Integra 1540 Only 53

5 Basis of measurement and calculations 54

6 Serial Communications 56

6.1 RS485 Port - Modbus or JC N2 56

6.2 Modbus® Implementation 56

6.3 RS485 Implementation of Johnson Controls Metasys 60

7. Maintenance 63

8 Appendix A CE Declaration of Conformity 64

4Integra 1540, 1000, 0640, 0440, 0340, 0240 Issue 1 04/03

1 Introduction

This manual provides operating instructions for the Crompton Switchboard Integra series of

Digital Metering Systems. Some versions of the Integra incorporate the metering transducer

that provides the interface for the measurement of power supply parameters such as voltage,

current, power, frequency etc. In other versions, the display and transducer are separate,

interconnected units. The display allows the user to set up metering transducer parameters

and to monitor the measurements. Some Integra models can be supplied as either an integral

or display-only version, while others are only available in one format. This manual provides

user instructions.

A separate leaflet provides installation instructions.

Table1 lists the various models of Integra and shows their distinctive characteristics.

Table 1 Summary of Integra models

Model V A F PF kW kWh THD Analogue Serial Pulse Freq

0240 V F 45-65 Hz

0340 V A 45-65 Hz

0440 V A F

360-400 Hz

0640 V A F 45-65 Hz

1000 V A F PF kW kWh RS485 Pulse 45-65 Hz

option option

1540 V A F PF kW kWh THD Analogue RS485 Pulse

option* option option 45-65 Hz

* When used with an 1560/80 transducer that includes analogue options.

Voltage and current readings are true RMS, up to the 15th harmonic (31st for 1560/80

transducer).

The unit can be powered from an auxiliary a.c. or d.c. supply that is separate from the metered

supply. Versions of each model are available to suit 100-250V 45-65 Hz a.c./d.c. and 12-48V d.c

nominal supplies.

In this manual, the graphic

0240 0340 0440 0640 1000 1540

is used to show the models to which a screen applies. Boxes are greyed out to show models

that do not have that type of screen.

0240 0340 0440 0640 1000 1540

This example indicates that the screen only applies to Models 1000 and 1540.

0240 0340 0440 0640 1000 1540 Option

This indicates that the screen is an option on models 1000 and 1540.

Important safety information is contained in the accompanying installation instructions.

Installers must familarise themselves with this information before installation.

Integra 1540, 1000, 0640, 0440, 0340, 0240 Issue 1 04/03 5

1.1 Unit Characteristics

1.1.1 0240

The 0240 will display the following parameters:

• System voltage (average of all phases)

• System frequency (Hz)

• Voltage line to neutral for each phase (4-wire systems only)

• Voltage line to line for each phase (calculated in 4-wire)

The 0240 has Set-up screens for potential transformer primary

and secondary voltages.

1.1.2 0340

The 0340 will display the following parameters:

• System voltage (average of all phases)

• System current (average of all phases)

• Voltage line to neutral for each phase (4-wire systems only)

• Voltage line to line for each phase (calculated in 4-wire)

• Current in each line.

The 0340 has Set-up screens for:

• Full-scale current value

• Potential transformer primary and secondary voltages.

1.1.3 0440 and 0640

The 0440 operates on a mains frequency of 400 Hz nominal

and the 0640 at 45-65 Hz. The units can measure and display

the following parameters:

• System voltage (average of all phases)

• System current (average of all phases)

• System frequency (Hz)

• Voltage line to neutral for each phase (4-wire systems only)

• Voltage line to line for each phase (calculated in 4-wire)

• Current in each line

The 0440 and 0640 have Set-up screens for:

• Full-scale current value

• Potential transformer primary and secondary voltages.

6Integra 1540, 1000, 0640, 0440, 0340, 0240 Issue 1 04/03

Default display

1.1.4 1000

The 1000 will display the following parameters:

• System voltage (average of all phases)

• System current (average of all phases)

• System frequency (Hz)

• Voltage line to neutral for each phase (4-wire systems only)

• Voltage line to line for each phase (calculated in 4-wire)

• Current in each line

• Neutral current1

• Power Factor

• Active Power (kW)

• Reactive Power (kVAr)

• Apparent Power (kVA)

• Active Energy (kWh)2

• Reactive Energy (kVArh)2

• Total System Current Demand (AD)2

• Total System Active Power Demand (kWD)2

• Maximum Total System Current Demand (AD)2

• Maximum Total System Active Power Demand (kWD)2

The 1000 has Set-up screens for:

• Full-scale current value

• Potential transformer - primary voltages.

• Demand integration time and energy/demand resets

• Pulse output duration and rate divisor (option)

• RS485 serial Modbus parameters (option)

A pulsed relay output, indicating kWh, and an RS485 ModbusTM

output are available as optional extras. The Modbus output

option allows remote monitoring from a Modbus master.

1Neutral referenced parameters are only available when used with 4-wire and single phase

configured transducers.

2All energy and demand measurements are importing only unless connected as exporting unit.

Integra 1540, 1000, 0640, 0440, 0340, 0240 Issue 1 04/03

Default display

1.1.5 1540

The1540 is available either as a display unit operating in

conjunction with a 15xx measurement transducer or as a

self-contained unit incorporating a transducer. The unit can

measure and display the following:

• System voltage (average of all phases)

• System current (average of all phases)

• System frequency (Hz)

• Voltage line to neutral for each phase (4-wire systems only)

• Voltage line to line for each phase (calculated in 4-wire)

• Current in each line.

• Neutral current1

• Power Factor

• Active Power (kW)2

• Reactive Power (kVAr)2

• Apparent Power (kVA)

• Active Energy (kWh)2

• Reactive Energy (kVArh)2

• Total System Current Demand (Admd)2

• Total System Active Power Demand (kWD)2

• Maximum Total System Current Demand (AD)2

• Maximum Total System Active Power Demand (kWD)2

The 1540 has Set-up screens for:

• Full-scale current value

• Potential transformer - primary and secondary voltages

(Dis 1540 and Integra 15xx)

• Potential transformer - primary voltages (self contained)

• Demand integration time and energy/demand resets

• Pulse output duration and rate divisor (option)

• RS485 serial Modbus parameters (option)

• Analogue current output (option, with separate

transducer only)

A pulsed relay output, indicating kWhr (and Kvarh on the two

part Dis 1540 and Integra 15xx combination), and an RS485

ModbusTM output are available as optional extras. The Modbus

output option allows remote monitoring from another display

(not self contained) or a Modbus master.

The Analogue current output option provides a current output

that indicates the value of a chosen parameter.

8Integra 1540, 1000, 0640, 0440, 0340, 0240 Issue 1 04/03

Default display

1Neutral referenced parameters are only

available when used with 4-wire and

single phase configured transducers.

2All energy and demand measurements

are importing only unless connected as

exporting unit.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Crompton Instrument de mesure

Crompton

Crompton integra 1530 Manuel d'utilisation et d'entretien

Crompton

Crompton M244-14L Manuel utilisateur

Crompton

Crompton SL1-01 Manuel utilisateur

Crompton

Crompton Tyco Electronics SWITCHBOARD INTEGRA 1540 Manuel utilisateur

Crompton

Crompton 264 Series Manuel utilisateur

Crompton

Crompton Emotron VSR Series Manuel utilisateur

Manuels Instrument de mesure populaires d'autres marques

Suaoki

Suaoki D40 Manuel utilisateur

Elster

Elster BK-G1.6 Manuel utilisateur

Endress+Hauser

Endress+Hauser Deltabar FMD71 Manuel

Duratool

Duratool D03128 Manuel utilisateur

Vega

Vega VEGAPULS 65 Manuel utilisateur

Tonghui

Tonghui TH2618B Manuel utilisateur

Tenmars

Tenmars TM-801 Manuel utilisateur

MSR

MSR 145 Manuel utilisateur

TPS

TPS WP-82 Manuel utilisateur

ELMETRON

ELMETRON CP-511 Manuel utilisateur

PCB Piezotronics

PCB Piezotronics 003C30 Manuel utilisateur

Tenma

Tenma 72-10465 Manuel utilisateur

Endress+Hauser

Endress+Hauser Proline Promag 50 Caractéristiques techniques

Siemens

Siemens SITRANS F Coriolis FCT030 Manuel de la liste des pièces

KLINGER

KLINGER CMF V Series Manuel utilisateur

EXFO

EXFO FTB-2 Manuel d'exploitation et d'entretien

Keysight

Keysight M8290A Manuel utilisateur

ADTEK

ADTEK MW-5 Manuel utilisateur
