Crivit 298895 Caractéristiques techniques
AIR CUSHIONED BIKE SADDLE
IAN 298895
LUFTPOLSTERSATTEL
Montage-, Bedienungs- und
Sicherheitshinweise
AIR CUSHIONED
BIKE SADDLE
Assembly, operating and safety
instructions
ȘA CU PERNĂ DE AER
Indicaţii de montaj-, utilizare- şi siguranţă
ȘA CU PERNĂ DE AER
Indicaţii de montaj-, utilizare- şi siguranţă
GB/CY Assembly, operating and safety instructions Page 5
RO Indicaţii de montaj-, utilizare- şi siguranţă Pagina 15
DE/AT/CH Montage-, Bedienungs- und Sicherheitshinweise Seite 25
60mm
A
B C 1 3 42
1
D5 6
5GB/CY
Introduction..............................Page 6
Intended use...................................Page 6
Description of parts........................Page 7
Technical data................................Page 7
Safety Notes............................Page 7
Assembly....................................Page 10
Inflating .......................................Page 11
Deflating .....................................Page 11
Care, storage..........................Page 12
Disposal.......................................Page 12
Warranty....................................Page 13
6 GB/CY
Air cushioned bike saddle
Introduction
We congratulate you on the purchase of your
new product. You have chosen a high quality
product. Familiarise yourself with the product
before using it for the first time. In addition,
please carefully refer to the operating instruc-
tions and the safety advice below. Only use
the product as instructed and only for the indi-
cated field of application. Keep these instruc-
tions in a safe place. If you pass the product
on to anyone else, please ensure that you
also pass on all the documentation with it.
Intended use
The product is a seat for bicycles. The product
is intended for private use only and is not
suitable for commercial use or for use in other
applications.
7GB/CY
Description of parts
1Nut
2Distance piece
3Block
4Screw
5Valve
6Button
Technical data
Width: HG02361A approx. 17.5cm
HG02361B approx. 21 cm
Safety Notes
PLEASE READ THE INSTRUCTIONS PRIOR
TO USE! PLEASE KEEP THE INSTRUC-
TIONS IN A SAFE PLACE! WHEN PASS-
ING THIS PRODUCT ON TO OTHERS,
ALSO INCLUDE ALL DOCUMENTS.
8 GB/CY
DANGER
TO LIFE AND RISK OF AC-
CIDENTS FOR INFANTS
AND CHILDREN! Never leave children
unsupervised with the packaging mate-
rial. The packaging material poses a suf-
focation hazard. Keep this product out of
the reach of children. This product is not
a toy.
CAUTION! RISK OF INJURY!
Assemble the product correctly and en-
sure that it cannot slip when riding. Do
not adjust the product while riding.
Quick releases must lie on the dropouts
in a closed state. Adjust the quick release
so that you feel some resistance when it
is in a 90° position and pull it tight. If
necessary, consult your specialist dealer.
Check the product before each use for
damage and wear-and-tear. Check that
all screws are tight before each use and
9GB/CY
if necessary, tighten screw connections
again. Only use the product if it is in
flawless condition! Never use a dama-
ged product.
If using a child seat, ensure that all spring
washers under the saddle are covered in
order to prevent the pinching of fingers.
Every type of tear or scratch in the areas
of the saddle subject to high stress (screw
connections) is an indication that the life-
span of that part has expired and the
part must be replaced.
AVOIDANCE OF MATERIAL
DAMAGE!
Ensure that the product does not come in
contact with sharp objects.
Protect the product from extreme weather
influences such as cold, wetness and
direct exposure to the sun.
10 GB/CY
Assembly
Note: Remove all packaging materials from
the product.
Always adjust the saddle to the appropriate
height for you (Max to Max indication as
recommended adjustment range). Observe
the marking on the seat post, which marks
the minimum insertion depth.
The products nuts 1must be tightened
with 24 Newton metres on both sides in
order to be securely fastened to the plug
seat post.
Adjust the product horizontally (Fig. A).
For plug seat posts: Fasten the saddle
with the pre-mounted block 3to the
plug seat post (Fig. B).
Remove the nuts 1on both sides with
14’ open-end wrench. Remove the
