Cretors E1202 Manuel utilisateur

176 MITTEL DRIVE, WOOD DALE, IL 60191

Models: E1202

Nacho Pequeño

Display Cabinet Manual

100 Volt, Single Phase, 50/60 Hz

120 Volt, Single Phase, 60 Hz (-A)

230 Volt, Single Phase, 50 Hz (-E)

READ and UNDERSTAND these operating and safety

instructions before operating this Cretors machine

Display Cabinet Manual

Revised 11.10.17

TABLE OF CONTENTS

I. Safety Alert Symbol................................................................................... 3

II. Safety First................................................................................................ 3

III. Introduction................................................................................................ 3

IV. Purpose of Manual .................................................................................... 4

V. Product Identification................................................................................. 4

VI. Principles of Display Cabinet Operation..................................................... 4

VII. Control Switch ........................................................................................... 4

VIII. Installation Instructions.............................................................................. 4

IX. Operating Instructions ............................................................................... 5

X. Sanitation Instructions ............................................................................... 5

XI. Service Instructions ................................................................................... 6

XII. Troubleshooting......................................................................................... 6

Display Cabinet Manual

Revised 11.10.17

I. SAFETY ALERT SYMBOL

The symbol shown is used to call your attention to instructions concerning your personal safety and

the safety of others. Watch for this symbol. It points out important safety precautions. It means

ATTENTION! Be Alert! Your personal safety is involved! Read the message that follows and

be alert to the risk of personal injury or death.

II. SAFETY FIRST

The information in this manual is essential for the safe installation and

operation of your Cretors machine. The manual must be read and

understood before installing, and operating the equipment, or equivalent

training must be provided.

The employer shall instruct each employee in the recognition and avoidance

of unsafe conditions, as well as, the regulations applicable to his work

environment and to control or eliminate any hazards or other exposure to

illness or injury. Ref.: 29 CFR 1926.20 (b)(4)(a)(2)

It is understood that safety rules within individual companies vary. If a conflict

exists between the safety procedures contained in this manual and the rules of a

using company, the more stringent rule should take precedence.

III. INTRODUCTION

This manual is filled with time-saving and money-saving information regarding your unit. There is

nothing more important than the safety aids and warnings that are throughout this document. The

Safety Alert Symbol is used to identify topics of primary safety concern wherever they appear.

If, after reviewing this manual, anything is unclear or technical problems are encountered, contact

the distributor from whom you purchased your unit for assistance or contact our Customer Service

Department at (800) 228-1885. Always have the model and serial number of your unit available to

assist in obtaining the correct information.

Display Cabinet Manual

Revised 11.10.17

IV. PURPOSE OF MANUAL

This instruction manual is intended to familiarize owners with the operation and safety

procedures associated with the unit.

It is important that this manual be kept available to operating personnel.

V. PRODUCT IDENTIFICATION

CRETORS POPCORN AND NACHO DISPLAY CABINET

MODEL

NPA_-X; NPE_-X –DISPLAY CABINET

REF. (1202-A/1202-E –DISPLAY CABINET)

Electrical:

100 Volt, 50/60 Cycle, 160 Watts

120 Volt, 60 Cycle, 160 Watts

230 Volt, 50 Cycle, 160 Watts

VI. PRINCIPLES OF DISPLAY CABINET OPERATION

Theory and Observations of Display Cabinet Operation

The Display Cabinets hold nacho chips, popcorn, or other snacks on racks to maximize the sell

ability of snacks. Load and un-load product through the large door on the unit’s front. The unit

features a corrosion-resistant design and tempered glass for easy cleaning; the surface will not

scratch or discolor. The unit’s door is easily-removable, for cleaning. Rubber feet prevent

skidding on counter top surfaces. The cabinet is provided with two lights and a heat pad to

keep product warm.

VII. CONTROL SWITCH

MAIN POWER SWITCH -Controls light and cabinet heat.

VIII. INSTALLATION INSTRUCTIONS

1. Location

Choose a location for your unit to maximize the ease of operation and maintenance

procedures. Check your local building and fire codes for location restrictions.

2. Power Supply

Check the nameplate to determine the required power supply.

Display Cabinet Manual

Revised 11.10.17

Connect the unit only to the correct power source.

Make certain the main power switch on the cabinet is in the 'OFF' position when

plugging into power source.

3. Install the racks

Install the clips in all four corners at the same height, as desired. The unit is provided with

two (2) racks and eight (8) clips which can be installed to accommodate different size

packaging.

IX. OPERATING INSTRUCTIONS

Do not attempt to operate the unit until you have read and understood this manual.

Failure to do so may result in serious injury or death.

Do not attempt to operate your unit unless the installation instructions have been strictly

adhered to. Failure to do so may result in serious injury or death.

Operate the unit only if it is in sanitary condition (SANITATION INSTRUCTIONS).

Failure to do so may result in illness to your customers.

1. Turn on rocker switch to turn on light and heat pad.

2. With racks already installed at desired height, load unit with product. Do not overfill the

cabinet.

3. Dispense product through the front door. Door can be installed on opposite side to open

opposite direction.

X. SANITATION INSTRUCTIONS

Be certain the unit is turned off and the power is unplugged before sanitizing, unless a

specific cleaning procedure requires power to the machine. Failure to do so could

result in serious injury or death.

Do not clean heated surfaces until they have been given sufficient time to cool.

Failure to do so may result in serious burns or scalds.

Do not immerse the unit in water. This will damage the electrical components, and may

cause short circuits, resulting in an electrical shock hazard if power is applied.

Display Cabinet Manual

Revised 11.10.17

1. After unit has been allowed to cool and has been unplugged, remove any excess

product remaining in the bottom.

2. Clean all surfaces with a non-abrasive food safe cleaner.

This appliance should not be cleaned with a water jet.

XI. SERVICE INSTRUCTIONS

Only a qualified person should perform the following diagnostic checks, and, if

necessary, corresponding adjustments and repairs. Many of the following procedures

may present an electrical shock hazard and can cause serious injury or death.

Perform work only on de-energized circuits. Failure to do so may lead to electrical

shock resulting in personal injury or death.

A. Parts

When ordering parts, refer to the recommend spare parts list included with this manual

or wiring diagram. Always supply the serial number and model number of the unit.

B. Check Unit Periodically

Periodically check electrical switch and cord for signs of wear. Check all screws and rivets

for tightness.

C. To Access Electrical Components

To access all electrical components, unplug power cord from outlet, and then lay unit on its

side and remove the four screws from the bottom cover, exposing heating element, switch,

and wiring. THIS UNIT IS NOT FUSED.

D. Troubleshooting

PROBLEM

POSSIBLE CAUSE

ACTION

Unit will not heat.

Unit unplugged or not switched

on.

Plug unit in. Turn on power.

Loose connection to heater.

Repair connection.

Light will not work.

Unit unplugged or not switched

on.

Plug unit in. Turn on power.

Bulb burned out.

Replace bulb with

recommended replacement

part (#EP2053-220)

RECOMMEND SPARE PARTS LIST

PART DESCRIPTION

PART NUMBER

Display Cabinet Manual

Revised 11.10.17

DOOR HINGE

EP4866

LIGHT BULB

EP2053-220

CLIP

16807

RACK

16810

DOOR

EP1904

KNOB

EP4539

MAGNET

EP1820

This unit is not intended for use by persons (including children) with reduced physical, sensory or

mental capabilities, or lack of experience and knowledge, unless they have been given supervision

or instruction concerning the use of the unit by a person responsible for their safety.

Children should be supervised to ensure that they do not play with the unit.

If the supply cord is damaged, it must be replaced by the manufacturer, its service agent or

similarly qualified persons in order to avoid a hazard.

If you have questions regarding the operation or cleaning of your unit, contact your local distributor

or the Customer Service Department at C. Cretors and Company at (800) 228-1885.

Cretors guarantees this machine to be free of defects in parts, materials and workmanship for two

years. Please fill out the factory registration card and return it to activate your warranty. If you have

questions concerning the Cretors’ warranty, please contact your local distributor or the Customer

Service Department at C. Cretors and Company.

C. CRETORS AND COMPANY

176 MITTEL DRIVE

WOOD DALE, IL 60191

PHONE (800) 228-1885, FAX (847) 616-6970

WEB SITE: http://www.cretors.com Email: postmaster@cretors.com
