Crestron Green Light DIN-HUB Comment utiliser

CrestronGreenLight™

DIN-HUB

DINRailCresnet®DistributionHub

Operations & Installation Guide

This document was prepared and written by the Technical Documentation department at:

Crestron Electronics, Inc.

15 Volvo Drive

Rockleigh, NJ 07647

1-888-CRESTRON

All brand names, product names and trademarks are the property of their respective owners.

Crestron DIN-HUB DIN Rail Cresnet®Distribution Hub

Contents

Crestron Green Light™ DIN Rail Cresnet®Distribution Hub: DIN-HUB 1

Introduction ...............................................................................................................................1

Features and Functions................................................................................................1

Applications.................................................................................................................3

Specifications ..............................................................................................................4

Physical Description....................................................................................................5

Industry Compliance ...................................................................................................8

Setup..........................................................................................................................................9

Network Wiring...........................................................................................................9

Installation...................................................................................................................9

Hardware Hookup .....................................................................................................11

Problem Solving ......................................................................................................................13

Troubleshooting.........................................................................................................13

Check Network Wiring..............................................................................................14

Reference Documents................................................................................................15

Further Inquiries........................................................................................................16

Future Updates ..........................................................................................................16

Return and Warranty Policies..................................................................................................17

Merchandise Returns / Repair Service ......................................................................17

CRESTRON Limited Warranty.................................................................................17

Operations & Installation Guide – DOC. 6671A Contents •i

Crestron DIN-HUB DIN Rail Cresnet®Distribution Hub

Crestron Green Light™ DIN Rail

Cresnet®Distribution Hub:

DIN-HUB

Introduction

The DIN-HUB is a DIN rail-mounted Cresnet®hub designed to facilitate

the configuration of large Cresnet networks. DIN rail mounting enables

modular installation alongside Crestron®DIN Rail lighting and

automation control modules and other third party DIN rail mountable

devices.

Features and Functions

• Three-segment Cresnet hub

• Recommended for large Cresnet networks*

• Configurable power distribution

• No programming required

• 6M wide DIN rail mounting

* Use of a DIN-HUB is advised whenever the number of Cresnet devices on a

network is greater than 20 or when the combined total length of Cresnet cable

exceeds 914 meters (3000 feet).

Operations & Installation Guide – DOC. 6671A DIN Rail Cresnet Hub: DIN-HUB •1

DIN Rail Cresnet®Distribution Hub Crestron DIN-HUB

Three-Segment Cresnet Hub

Cresnet is the communications backbone for Crestron lighting modules,

wall box dimmers, shade controllers, thermostats, keypads, touchpanels,

and many other devices. This flexible 4-wire bus normally supports

approximately 20 Cresnet devices without requiring a hub. Larger

systems are easily enabled by adding the DIN-HUB. The DIN-HUB

features three isolated Cresnet segments, each supporting an additional

20 devices, allowing for systems of approximately 80 devices total

(including the “host” segment). More hubs may be added to allow up to a

maximum potential of 252 devices.*

* The actual number of possible devices per segment and per network may vary

depending upon the amount of data traffic, the length and geometry of network

wiring, and the power requirements of every device. A general rule of thumb

suggests approximately 20 devices, an aggregate of 914 meters (3000 feet) of

cable, and up to a 75 Watt load per segment (wiring and devices permitting). In

any case, 252 is the maximum number of possible devices on a complete Cresnet

network. Contact Crestron True Blue Support

(www.crestron.com/true_blue_support) for further design assistance.

Cresnet Power Distribution

In addition to data, Cresnet carries 24 Volts DC for powering the devices

connected to it. The DIN-HUB provides an easy way to manage the

distribution of power for a complete Cresnet network. Each segment can

be configured to receive its power from the “host” power source or from

another power supply. Separate power supplies may be dedicated to each

segment, or a single supply can be shared amongst multiple segments as

needed. Each segment supports up to 75 Watts.

DIN Rail Installation

The DIN-HUB is designed to snap onto a standard DIN rail for

installation in a wall mount enclosure or mounted on a wall panel. Wiring

connections are made using detachable screw terminals positioned along

the top and bottom, clearly accessible from the front for easy installation

and servicing. Diagnostic indicators are positioned on the center front

panel. When installed in an enclosure utilizing 45 mm cutouts, the

DIN-HUB’s front panel stays visible while the connections are

concealed.

2 •DIN Rail Cresnet Hub: DIN-HUB Operations & Installation Guide – DOC. 6671A

Crestron DIN-HUB DIN Rail Cresnet®Distribution Hub

Applications

The following diagram shows a DIN-HUB in a typical application.

DIN-HUB in a Typical Application

Operations & Installation Guide – DOC. 6671A DIN Rail Cresnet Hub: DIN-HUB •3

DIN Rail Cresnet®Distribution Hub Crestron DIN-HUB

Specifications

Specifications for the DIN-HUB are listed in the following table.

DIN-HUB Specifications

SPECIFICATION DETAILS

Power Requirements

Cresnet Power Usage

0.6 Watts

(0.03 Amp @ 24 Volts DC)

Maximum Load per

Segment 75 Watts

(3.13 Amps @ 24 Volts DC)

Environmental

Temperature

Humidity

Heat Dissipation

0° to 40°C (32° to 104°F)

10% to 90% RH (non-condensing)

2 BTU/Hr

Enclosure Light gray polycarbonate housing

with polycarbonate label overlay,

UL94 V-0 rated, 35 mm DIN EN

60715 rail mount, DIN 43880 form

factor for enclosures with 45 mm

front panel cutout, occupies 6 DIN

module spaces (108 mm)

Dimensions

Height

Width

Depth

94.2 mm (3.71 in)

106 mm (4.17 in)

58.0 mm (2.28 in)

Weight 155 g (5 oz)

Available Accessories

DIN-BLOCK

DIN-PWS50

DIN Rail Cresnet Distribution

Block

DIN Rail 50 Watt Cresnet Power

Supply

4 •DIN Rail Cresnet Hub: DIN-HUB Operations & Installation Guide – DOC. 6671A

Crestron DIN-HUB DIN Rail Cresnet®Distribution Hub

Physical Description

This section provides information on the connections, controls and

indicators available on your DIN-HUB.

DIN-HUB Physical View

DIN-HUB Overall Dimensions

106 mm

(4.17 in)

94.2 mm

(3.71 in)

90 mm

(3.54 in)

58 mm

(2.28 in)

Operations & Installation Guide – DOC. 6671A DIN Rail Cresnet Hub: DIN-HUB •5

DIN Rail Cresnet®Distribution Hub Crestron DIN-HUB

Connectors, Controls & Indicators

# CONNECTORS1,

CONTROLS &

INDICATORS

DESCRIPTION

1 NET PWR INPUT

(A/B/C) (3) 3-pin 3.5 mm detachable

terminal blocks

Cresnet power selection

connectors for each segment

Connect to external Cresnet

power supplies, or to “host”

power source via jumpers, to

power devices connected to the

NET A/B/C ports

Max Wire Size:

1.5 mm2(16 AWG)

Maximum Load per Segment:

75 Watts

(3.13 Amps @ 24 Volts DC)

2 NET HOST and LEDs

(2) 4-pin 3.5 mm detachable

terminal blocks, paralleled

Connects to Master NET port of

DIN-AP2 or other control

system, and loops through to

additional DIN Rail Cresnet

devices

Max Wire Size:

1.5 mm2(16 AWG)

Pin 1 (24): Power (24 VDC)

Pin 2 (Y): Data

Pin 3 (Z): Data

Pin 4 (G): Ground

(1) Green LED indicates

Cresnet power is supplied to

unit via either NET HOST port

(Continued on following page)

6 •DIN Rail Cresnet Hub: DIN-HUB Operations & Installation Guide – DOC. 6671A
