Crestron CN-WP12F and CN-WP12N Source and Numeric Keypads

Operations Guide - DOC. 5788A Contents •• i

Contents

Source and Numeric Keypads: CN-WP12F and CN-WP12N 1

Description 1

Functional Description 1

Physical Description 1

Leading Specifications 3

Setup 3

Custom Switch Cap Installation 3

Network Wiring 6

Keypad Installation 7

Identity Code 7

Programming with SIMPL™ Windows8

How the Program Works 8

How to Create the Program 9

Problem Solving 12

Troubleshooting 12

Further Inquiries 12

Return and Warranty Policies 13

Merchandise Returns / Repair Service 13

CRESTRON Limited Warranty 13

Crestron CN-WP12F and CN-WP12N Source and Numeric Keypads

Operations Guide - DOC. 5788A Source and Numeric Keypads: CN-WP12F and CN-WP12N •• 1

Source and Numeric Keypads:

CN-WP12F and CN-WP12N

Description

Functional Description

The Source and Numeric Keypads, CN-WP12F and CN-WP12N, are wall-mounted

user-interface devices designed to work with the CNX-PAD8 Professional Audio

Distribution Processor. The keypads are installed into the physical rooms of a building

to control the CNX-PAD8 and its audio source devices.

The CN-WP12F serves as the source keypad. It consists of six source selector buttons,

an ON/OFF button, a MUTE button, device transport control and volume control

buttons. The CN-WP12N is an optional numeric keypad that is used to expand the

capabilities of the source keypad. It contains a CLEAR button, an ENTER button, and

numeric digit buttons 0 through 9. The keypad is ideal for audio device functions such

as selecting a particular track number of a CD or a certain disc of a CD changer.

Both keypads are standard Cresnet devices and may be programmed as desired using

SIMPL Windows. In addition, a set of pre-programmed modules is available from

Crestron to facilitate easier programming of the keypads and the CNX-PAD8. These

modules are referred to as the CrestronHome Programming Kit and can be obtained

from the Downloads page (MACROS Library) of Crestron’s website

(www.crestron.com).

Physical Description

The CN-WP12F and CN-WP12N keypads are shown on the next page. Each keypad

has 12 buttons and on the CN-WP12F, the top eight buttons contain LEDs for user

feedback indicators. The SIMPL™ Windowsprogram determines the state of the

indicators, either off, on, or flashing. The CN-WP12N has an LED for the ENTER

button only.

The CN-WP12F is available in either ivory or white (part numbers CN-WP12FI and

CN-WP12FW, respectively). The CN-WP12N is also available in ivory or white

(CN-WP12NI and CN-WP12NW). Wall-plates are not supplied.

The CN-WP12F has standard source selector switch caps installed and a kit of custom

switch caps is provided.

Source and Numeric Keypads Crestron CN-WP12F and CN-WP12N

2•• Source and Numeric Keypads: CN-WP12F and CN-WP12N Operations Guide - DOC. 5788A

CN-WP12F and CN-WP12N Source and Numeric Keypads

VOL

ON/OFF MUTE

TAPE AUX

CD 2 DSS

FMCD

ENTER

CLEAR

1.74 in

(4.42 cm)

CN-WP12F

CN-WP12N

4.10 in

(10.41 cm)

SOURCE

SELECTOR

BUTTONS WITH

LED INDICATORS

ON/OFF AND

MUTE BUTTONS

WITH LED

INDICATORS

TRANSPORT

CONTROL

AND VOLUME

BUTTONS

(WITHOUT LEDs)

CLEAR BUTTON

(WITHOUT LED)

AND ENTER

BUTTON WITH

LED INDICATOR

NUMERIC

DIGITS 0

THROUGH 9

BUTTONS

(WITHOUT LEDs)

1.74 in

(4.42 cm)

4.10 in

(10.41 cm)

1.55 in

(3.94 cm)

1.90 in

(4.83 cm)

(SIDE VIEW OF BOTH

CN-WP12F AND CN-WP12N)

NETWORK

WIRING

CONNECTOR

KEYPAD

MOUNTING

ASSEMBLY

CN-WP12F Custom Switch Cap Kit

AMAM

FM 2FM 2

SAT 2SAT 2

SATSAT

DSS 2DSS 2

AUXAUXAUXAUX

DVDDVD

TVTV

TUNERTUNER

(NOT DRAWN

TO SCALE)

Crestron CN-WP12F and CN-WP12N Source and Numeric Keypads

Operations Guide - DOC. 5788A Source and Numeric Keypads: CN-WP12F and CN-WP12N •• 3

Leading Specifications

The table below provides a summary of leading specifications for the CN-WP12F

and CN-WP12N. Dimensions and weight are rounded to the nearest hundredth unit.

Leading Specifications of the CN-WP12F and CN-WP12N

SPECIFICATION

DETAILS

Power Requirements 24 VDC, Load Factor of 2 Watts 1

Default Network IDs 4C for the CN-WP12F and

48 for the CN-WP12N

SIMPL Windows Version 1.30.01 or later

with library

update file smwlib45.exe and library

update document smwlib45.txt or later.

CNX Upgrade File

Version 5.04.11x.upz or later

CNHome.zip

Version 1.0. or later

Dimensions & Weight

1Height: 4.10 in (10.41 cm)

Width: 1.74 in (4.42 cm)

Depth: 1.90 in (4.83 cm)

Weight: 5.50 oz (.16 kg)

1The listed details apply to the CN-WP12F or the CN-WP12N as individual units

not as a pair or set.

2The latest software versions can be obtained from the Downloads page

(SIMPLWIN and MACROS Libraries) of Crestron’s website

(www.crestron.com). New users are required to register in order to obtain access

to the FTP site.

3Filenames for CNX upgrade files have a UPZ extension and can be obtained

from the Downloads

As of the date of manufacture, these units have been tested and found to comply with

specifications for CE marking.

NOTE: These devices comply with part 15 of the FCC rules. Operation is subject to

the following two conditions: (1) these devices may not cause harmful interference,

and (2) these devices must accept any interference received, including interference

that may cause undesired operation.

Setup

Custom Switch Cap Installation

On the CN-WP12F, the top six buttons serve the function of source selector buttons.

The keypad has standard source selector switch caps installed and a kit of custom

switch caps is also supplied. The following procedure describes how to install the

custom switch caps (or re-arrange the standard switch caps) onto the keypad:

1. If applicable, remove the designer or decorator wall-plate from the

CN-WP12F.

Source and Numeric Keypads Crestron CN-WP12F and CN-WP12N

4•• Source and Numeric Keypads: CN-WP12F and CN-WP12N Operations Guide - DOC. 5788A

2. Grasp the lower-sides of the keypad and gently pull the bottom of the

keypad outwards as shown below.

Keypad Removal

CAUTION: To avoid damage to the keypad shell during the next step, do not use

excessive force when prying the shell outwards.

NOTE: The position of each switch cap is important to the CNX-PAD8 program.

Notice the location of each switch cap before disassembly.

3. Using a small flat-tip screwdriver or your fingers, pry the sides of the

keypad shell outwards until the four retainer tabs (shown below)

recede from the sides of the shell. Separate the keypad shell from the

keypad PCB and base.

Rear View of Keypad

RETAINER

TABS

RETAINER

TABS

KEYPAD

SHELL

KEYPAD

PCB AND BASE

UPPER-TAB

Crestron CN-WP12F and CN-WP12N Source and Numeric Keypads

Operations Guide - DOC. 5788A Source and Numeric Keypads: CN-WP12F and CN-WP12N •• 5

4. As shown below, remove the switch cap to be replaced from the rubber

button actuator. Make sure that the indicator lens of the custom switch

cap is above the LED and install the custom switch cap onto the button

actuator.

Install Custom Switch Cap

VOL

ON/OFF MUTE

TAPE AUX

CD 2 DSS

DSS 2

LED

5. Position the keypad shell so that the upper-tab faces upwards (as the

switch caps are readable) and lower it onto the keypad PCB and base.

6. Move the switch caps as necessary to align them into the shell openings

and gently squeeze the shell onto the PCB and base until the four

retainer tabs click into place.

7. Position the keypad and the keypad mounting assembly as shown

below.

Alignment Points for Re-assembly

MOUNTING

ASSEMBLY

UPPER-SLOT

KEYPAD

UPPER-

TAB

KEYPAD

18-PIN

PLUG

MOUNTING

ASSEMBLY

18-PIN SOCKET

VOL

ON/OFF MUTE

TAPE AUX

CD 2 DSS

FMDSS 2

Source and Numeric Keypads Crestron CN-WP12F and CN-WP12N

6•• Source and Numeric Keypads: CN-WP12F and CN-WP12N Operations Guide - DOC. 5788A

CAUTION: To avoid damage to the pins of the plug, do not use excessive force

when seating the keypad into the keypad mounting assembly. When properly

aligned, the 18-pin plug inserts easily into the socket

8. As shown below, insert the keypad upper-tab into the keypad mounting

assembly upper-slot. Align the keypad 18-pin plug with the assembly

18-pin socket and gently push the keypad inward until it is fully

seated.

Install Keypad

9. If applicable, re-install the designer or decorator wall-plate onto the

CN-WP12F.

Network Wiring

NOTE: When making category 5 wire connections, refer to the latest revision of the

Cresnet Mini Network Cat 5 Interconnect Data Sheet (Doc. 5819).

When calculating the wire gauge for a particular network run, the length of the run

and the load factor of each network unit to be connected must be taken into

consideration. If network units are to be daisy-chained on the run, the load factor of

each network unit to be daisy-chained must be added together to determine the load

factor of the entire chain. If the network unit is a home-run from a Crestron system

power supply network port, the load factor of that network unit is the load factor of

the entire run. The length of the run in feet and the load factor of the run should be

used in the following resistance equation to calculate the value on the right side of

the equation.

Resistance Equation

R = Resistance (refer to next table).

L = Length of run (or chain) in feet.

LF = Load factor of entire run (or chain).

R < L x LF

40,000 Where:

The required wire gauge should be chosen such that the resistance value is less than

the value calculated in the resistance equation. Refer to the table on the next page:
