Crestron TPCS-4SM & TPCS-4SMD
4.3” Touch Screen Control Systems
Configuration Guide
This document was prepared and written by the Technical Documentation department at:
The specific patents that cover Crestron products are listed at www.crestronpatents.com.
Crestron, the Crestron logo and Crestron Toolbox are either trademarks or registered trademarks of Crestron Electronics, Inc. in the
United States and/or other countries. Internet Explorer is either a trademark or registered trademark of Microsoft Corporation in the
United States and/or other countries. Other trademarks and trade names may be used in this document to refer to either the entities
claiming the marks and names or their products. Crestron disclaims any proprietary interest in the marks and names of others.
©2012 Crestron Electronics, Inc.
Crestron TPCS-4SM & TPCS-4SMD Touch Screen Control Systems
Contents
4.3” Touch Screen Control Systems: TPCS-4SM & TPCS-4SMD 1
Access the Setup Screens........................................................................................................... 1
Configure the TPCS-4SM or TPCS-4SMD...............................................................................3
Ethernet Setup .............................................................................................................3
Audio Setup.................................................................................................................8
Display Setup ..............................................................................................................8
Application Setup ......................................................................................................10
Standby Timeout .......................................................................................................11
Diagnostics ................................................................................................................12
About.........................................................................................................................15
Save & Exit ...............................................................................................................15
Configuration Guide – DOC. 7332A Contents •i
Crestron TPCS-4SM & TPCS-4SMD Touch Screen Control Systems
4.3” Touch Screen
Control Systems:
TPCS-4SM & TPCS-4SMD
Access the Setup Screens
The setup screens are the starting point for configuring the TPCS-4SM and
TPCS-4SMD from Crestron®.
NOTE: If no project has been loaded or if an invalid project has been loaded, the
TPCS-4SM and TPCS-4SMD default to the setup screens.
The setup screens enable basic configuration procedures prior to regular operation of
the TPCS-4SM and TPCS-4SMD.
When power is applied for the first time, the screen shown in the following
illustration appears.
Initial Screen
NOTE: Most screens on the TPCS-4SM and TPCS-4SMD are identical. The few
instances where they differ are noted in the text.
Configuration Guide – DOC. 7332A 4.3” Touch Screen Control Systems: TPCS-4SM & TPCS-4SMD •1
Touch Screen Control Systems Crestron TPCS-4SM & TPCS-4SMD
Touch Setup to display the main “TPMC-4SM Setup” (or TPMC-4SMD Setup”)
menu, shown in the following illustration.
“TPCS-4SM Setup” Menu
During regular operation of the touch screen, there are two ways to activate the setup
functions:
1. Place a button on the project main page and assign the reserved join number
(17242) that activates setup.
2. Press hard keys 1, 2, 3 and 4, on the left side of the touch screen display, in
sequence twice (i.e., press 1, 2, 3, 4, 1, 2, 3, 4) within a five second period.
NOTE: For hard key numbering refer to the “Diagnostic – Keypad”
illustration at the bottom of page 12.
The “TPCS-4SM Setup” (or “TPCS-4SMD Setup”) menu is comprised of buttons for
Ethernet Setup, Audio Setup, Display Setup,Application Setup, Standby
Timeout and Diagnostics. In addition, there are buttons that provide information
about the touch screen and a Save & Exit button. The functions of each are detailed
in the next section of this guide.
2 •4.3” Touch Screen Control Systems: TPCS-4SM & TPCS-4SMD Configuration Guide – DOC. 7332A
Crestron TPCS-4SM & TPCS-4SMD Touch Screen Control Systems
Configure the TPCS-4SM or TPCS-4SMD
Ethernet Setup
On the “TPCS-4SM[D] Setup” menu, touch Ethernet Setup to display the “Ethernet
Setup” menu, shown in the following illustration.
“Ethernet Setup” Menu
The “Ethernet Setup” menu displays current settings, such as whether DHCP is on or
off, the touch screen’s Hostname and its IP Address. There are controls for turning
DHCP On or Off as well as controls which allow editing of the Hostname and IP
Address. This menu also contains Link and Ethernet indicators to show the status and
activity of the Ethernet connection. Other controls on this menu are explained in
paragraphs that follow.
To edit the Hostname, touch Edit on the right side of the menu. The “Edit
Hostname” screen opens with its on-screen keyboard, shown in the following
illustration.
“Edit Hostname” Screen with On-Screen Keyboard
Configuration Guide – DOC. 7332A 4.3” Touch Screen Control Systems: TPCS-4SM & TPCS-4SMD •3
Touch Screen Control Systems Crestron TPCS-4SM & TPCS-4SMD
Use the keyboard to enter the new name. Touch Clear to clear any previous entry,
Save to save a new entry or Cancel to return to the previous screen.
To edit the IP Address, touch Edit on the right side of the “Ethernet Setup” menu.
The “Edit IP Address” screen opens with its on-screen numeric keyboard, shown in
the following illustration.
“Edit IP Address” Screen with On-Screen Numeric Keyboard
Use the keyboard to enter the new IP address. Touch Clear to clear any previous
entry, Backspace to delete the last digit, Enter to save a new entry or Cancel to
return to the previous screen.
Touch the ellipsis (…) at the top of the “Ethernet Setup” menu to display additional
Ethernet parameters and the controls which allow their entry, as shown in the
following illustration.
“Ethernet Setup” Menu (Additional Parameters)
The additional parameters are Subnet Mask, Default Router, Mac Address and
Domain. For Subnet Mask, Default Router or Domain, touch Edit on the right side of
the menu to open on-screen keyboards like the ones described above.
After all new settings have been made, touch Reboot at the bottom of the “Ethernet
Setup” menu to reboot the touch screen, so the new settings can take effect.
Touch Advanced Settings to display the “Advanced Ethernet Setup” menu, shown
in the following illustration.
4 •4.3” Touch Screen Control Systems: TPCS-4SM & TPCS-4SMD Configuration Guide – DOC. 7332A
Crestron TPCS-4SM & TPCS-4SMD Touch Screen Control Systems
“Advanced Ethernet Setup” Menu
The “Advanced Ethernet Setup” menu provides controls for enabling or disabling
SSL (Secure Sockets Layer, a protocol for encrypting information over the Internet)
and for editing the CIP Port, Secure CIP Port, CTP Port and Secure CTP Port.
The SSL controls work as follows:
• Off: Disables the SSL capabilities of the TPMC-4SM (or TPMC-4SMD)
• Self: Sets up self signing certificates
• CA: Uses an authority to assign the SSL certificates
NOTE: For more details on SSL settings, refer to the latest version of the 3-Series
Control Systems Reference Guide (Doc. 7150). It is available from the Crestron Web
site at www.crestron.com/manuals.
To edit the CIP Port, Secure CIP Port, CTP Port or Secure CTP Port, , touch Edit
on the right side of the menu to open an on-screen keyboard like the ones described
earlier in this guide.
Touch DNS Servers to display the “DNS Servers” screen, shown in the following
illustration.
“DNS Servers” Screen
Configuration Guide – DOC. 7332A 4.3” Touch Screen Control Systems: TPCS-4SM & TPCS-4SMD •5
Touch Screen Control Systems Crestron TPCS-4SM & TPCS-4SMD
The “DNS Servers” screen provides controls for adding or deleting the IP addresses
of DNS (Domain Name System) registered computers on the network. To add a
server’s IP address, touch New to open an on-screen keyboard.
Use the keyboard to enter the IP address of the new DNS server. Touch Clear to
clear any previous entry, Backspace to delete the last digit, Enter to save a new
entry or Cancel to return to the previous screen.
On the “Advanced Ethernet Setup” menu, touch the ellipsis (…) at the top to display
the On and Off controls which allow enabling or disabling the Webserver and for
editing the Web Port and Secure Web Port.
The default Webserver setting is On. Touching Off disables access to setup from a
Web browser.
To edit the Web Port or Secure Web Port, touch Edit on the right side of the screen
to open an on-screen keyboard like the ones described earlier in this guide.
“Advanced Ethernet Setup” Menu (Webserver)
Touch to return to the main “Ethernet Setup” menu.
On the “Ethernet Setup” menu, touch Ethernet Diagnostics to display the “Ethernet
Diagnostics” screen, shown in the following illustration.
“Ethernet Diagnostics” Screen
6 •4.3” Touch Screen Control Systems: TPCS-4SM & TPCS-4SMD Configuration Guide – DOC. 7332A
