Crestron UC-M150-Z Manuel utilisateur

The Crestron® Flex Tabletop UC Video Conference System for Zoom

Rooms™ software (UC-M150-Z) delivers a powerful solution for

knowledge workers who want the Zoom Rooms software experience in

small to midsize meeting and conference rooms.

MinimumRequirements

lA video display, connected to the UC-ENGINE-Z.The system supports

a second display if desired.

lA Zoom Rooms account or activation code

View the Crestron Flex Pre-Deployment Checklist to help plan your

Crestron Flex installation.

Optional

lCCS-UCA-SMK Swivel Mount Kit

lCCS-UCA-MIC KIT Microphone Pods

In the Box

UC-BRKT-100-Z-ASSY, UC Engine Bracket Assembly

1 UC-BRKT-100-Z-ASSY (6511049)

1 Power cord

Mounting Hardware

CCS-UC-1, Crestron Mercury® Tabletop UC Video Conference

Device

1 CCS-UC-1 (6508227)

1 Cable, USB 2.0 A - Micro B, 6 ft (1.8 m) (2047803)

1 Cable, CAT5e, RJ-45 Male - RJ-45 Male, 12 ft (3.6 m)

(2033988)

Cable Management Hardware

Accessory Box

1 CCS-CAM-USB-F-400, Huddly IQ™ Collaboration Camera

(6510482)

1 CCS-UCA-MEM-USB, USBDrive (6509548)

1 PW-2420RU, Power Supply (6500187)

1 CBL-CAT5E-7, CAT5e cable RJ-45-to-RJ-45, Black,

7 ft (2.1 m) (6509924)

1CBL-HD-THIN-HS-6, Thin HDMI® cable, 6 ft (1.8 m) (6510946)

1 CBL-HD-20, HDMI cable 20 ft (6.1 m) (6503567)

1 CBL-USBC-HD-9, USB 3.0 to HDMI Converter cable,

9 ft (2.7 m) (6510718)

1 CBL-USB-A-EXT-15 USBExtension Cable, Type A

Male-to-Female, 15 ft (4.6 m) (6508260)

1 UC-CAM-WMK, Wall Mount Kit for Crestron Cameras

(6510998)

UC-M150-Z QuickStart

Crestron® Flex Tabletop UC Video Conference System for Zoom Rooms™ Software

Overview

The following diagram illustrates system connections.

UC-M150-Z QuickStart

Crestron® Flex Tabletop UC Video Conference System for Zoom Rooms™ Software

Connect

1. Remove the connector covers prior to making UC-ENGINE-Z

connections on the UC-BRKT-100-Z-ASSY bracket assembly.

UC-M150-Z QuickStart

Crestron® Flex Tabletop UC Video Conference System for Zoom Rooms™ Software

2. Make connections to the Crestron Mercury device and

UC-BRKT-100-Z-ASSY bracket assembly as shown in the following

illustration.

UC-M150-Z QuickStart

Crestron® Flex Tabletop UC Video Conference System for Zoom Rooms™ Software

3. Connect the display devices and camera to the UC-ENGINE-Z as

shown below.

UC-M150-Z QuickStart

Crestron® Flex Tabletop UC Video Conference System for Zoom Rooms™ Software

4. Bundle the cables with the integrated cable tie wraps. The cable tie

wraps are reusable.

UC-M150-Z QuickStart

Crestron® Flex Tabletop UC Video Conference System for Zoom Rooms™ Software

Complete the Installation

After completing UC-ENGINE-Z connections, secure the connector

covers using a #1 Phillips head screwdriver to replace the screws.

NOTE: For additional security, replace the screws with the spanner

screws included with the bracket assembly. A 1/4 in. bit is also supplied

with the bracket assembly to install the spanner screws.

UC-M150-Z QuickStart

Crestron® Flex Tabletop UC Video Conference System for Zoom Rooms™ Software

Configure

Apply Power

1. Press the power button on the bottom of the UC-ENGINE-Z and

apply power to all of the other devices in the system. The connected

display device will show a pairing code.

2. Remove the CCS-UCA-MEM-USB from the Crestron Mercury device.

Use the Crestron Mercury device to sign in to the Zoom Rooms service

using an activation code or a Zoom Room Sign-In.

1. Enter the pairing code shown on the display to pair the Crestron

Mercury device with the UC-ENGINE-Z. The Zoom Rooms controller

app is displayed.

2. Log in to the Zoom Rooms service with an activation code or Zoom

Rooms Credentials (email and password).

lActivation Code:

a. Tap Enter Activation Code.

b. Enter the 16-digit activation code provided by the

administrator to activate the Zoom Room that is

assigned to the activation code. The Zoom Rooms

Conference Room screen is shown on the display.

lSign In:

a. Tap Sign In.

b. Enter the Zoom Room credentials and tap Sign In.

c. Select the conference room name from the list and

tapNext. The Zoom Rooms Conference Room screen is

shown on the display.

3. Tap Settings. If a password is required, enter the password (default is

0000). The Settings screen is displayed.

4. Tap Microphone and select the Crestron Mercury device as the source.

5. Tap Speaker and select the Crestron Mercury device as the source.

6. Tap Meet Now to exit.

UC-M150-Z QuickStart

Crestron® Flex Tabletop UC Video Conference System for Zoom Rooms™ Software

Visit the Product Page

Scan the QR code to visit the product page.

UC-M150-Z

www.crestron.com/model/6511050

Additional Information

Original Instructions

The U.S. English version of this document is the original instructions.

All other languages are a translation of the original instructions.

Crestron product development software is licensed to Crestron dealers and Crestron

Service Providers (CSPs) under a limited nonexclusive, nontransferable Software

Development Tools License Agreement. Crestron product operating system software is

licensed to Crestron dealers, CSPs, and end-users under a separate End-User License

Agreement. Both of these Agreements can be found on the Crestron website at

www.crestron.com/legal/software_license_agreement.

The product warranty can be found at www.crestron.com/warranty.

The specific patents that cover Crestron products are listed at

www.crestron.com/legal/patents.

Certain Crestron products contain open source software. For specific information, visit

www.crestron.com/opensource.

Crestron, the Crestron logo, and Crestron Mercury are either trademarks or registered

trademarks of Crestron Electronics, Inc. in the United States and/or other countries.

HDMI and the HDMI logo are either trademarks or registered trademarks of HDMI

Licensing LLC in the United States and/or other countries. Huddly IQ is either a

trademark or registered trademark of Huddly AS in the United States and/or other

countries. Zoom Rooms is either a trademark or registered trademark of Zoom Video

Communications, Inc. in the United States and/or other countries. Other trademarks,

registered trademarks, and trade names may be used in this document to refer to

either the entities claiming the marks and names or their products. Crestron disclaims

any proprietary interest in the marks and names of others. Crestron is not responsible

for errors in typography or photography.

Doc ID 8467E

03/13/20

UC-M150-Z QuickStart

Crestron® Flex Tabletop UC Video Conference System for Zoom Rooms™ Software
