Creo iQsmart 2 Instructions d'installation et d'utilisation
oXYgen Scanning Application - User Guide Addendum 5
iQsmart Hardware
This section of the addendum documents the new and updated functions and
features of the scanner hardware, organized under the following topics:
• Power up/shutdown
• Startup sequence
• Operating panel
• Light Table
• Base glass
• Masks
• Mounting originals in the scanner
Power Up/Shutdown
1. Turn on your Macintosh computer.
2. Turn on the scanner by switching on the Main Power switch on the back of the scanner.
Figure 1: Main power switch on back of scanner
3. Press the Power button on the operating panel. The Power LED is green. The Status LED is
orange for a few seconds.
6 oXYgen Scanning Application - User Guide Addendum
Figure 2: Power and status LEDs on the operating panel
The Status LED blinks green, during a series of self-tests. When the Status LED is steady
green, the scanner is ready for operation.
If the Status LED remains red or blinking green (indicating a failure), do the
following:
Turn the scanner off and then on again.
If the LED is still red, call your Service Engineer.
NOTE: Shut down by quitting the application then switching off the Main Power switch
located on the back panel. For temporary, short term shutdown, press the shutdown button
located on the operating panel.
Startup Sequence
To start up the scanner, do the following:
1. Switch on the Main power switch on the back of the scanner.
2. Press the Power button on the Operating panel. The Power LED on the operating panel is
green.
oXYgen Scanning Application - User Guide Addendum 7
During the diagnostic self-tests, the Status LED illuminates in the following sequence:
1. Switch on the Main power switch on the back of the scanner.
2. The Status LED is orange for several seconds when the scanner is switched on.
3. The Status LED turns off for several seconds while the scanner checks the firmware
software).
4. The Status LED turns green.
Base Glass for iQsmart Scanners
EverSmart users can refer to the user guide, oXYgen Scanning Application (399Z1P555C),pg.
16, Chapter 2, for information about the Base glass.
The iQsmart2 is supplied with a 12” wide Base glass which has an etched
finish.
The iQsmart2 is supplied with a 13” wide Base glass which has an anti-
reflective (AR) coating. The 13” Base glass is used for copydot scans and
reflective scans up to 550% at 12 dpm resolution (approx. 300 dpi) or at an
equal scaling per resolution. Reflective scans with a greater resolution can only
be made within the 12” boundary on the 13” Base glass.
NOTE: Scans made from transparencies can only be made within the 12” boundary on the 13”
Base glass.
8 oXYgen Scanning Application - User Guide Addendum
The following figures show the Base glass layout, as seen in the Layout
Display window of the application:
Figure 3: 12” Base glass layout Figure 4: 13” Base glass layout
For information about the CopyDot Scan, refer to the oXYgen Dot for iQsmart Scanners User
Guide (399Z151895D).
The Operating Panel
The operating panel is located at the lower right corner of the top of the
scanner and is mainly used during power up. The panel has a Power button
with LED and one Status indicator with LED.
For further information about the various sections of the panel LEDs, refer to the startup
sequence in Galaxy Scanners Installation and Maintenance – for Mac Platform (399Z1R946A).
oXYgen Scanning Application - User Guide Addendum 9
Functional description of the operating panel
The Power button with LED and the Status indicator with LED are located on
the operating panel.
The LED of the Power button indicates the Main power switch setting of the
scanner. The LED of the Status indicator indicates the status of the scanner.
NOTE: Each time you press the Power button, the scanner status toggles between on and off.
The following are the meanings of the LED of the Power button:
• Off Power is OFF.
• Green Power is ON.
• Red Power is OUTSIDE THE TOLERANCE RANGE.
The following are the meanings of the LED of the Status indicator:
• Orange Scanner is activated.
• Red Hardware problem.
• Blinking Red The interlock switches are open.
• Green Scanner is idle.
• Blinking
Green
The scanner is either working or firmware is not
updated. In the event that the firmware is not
updated, you must activate the application version.
• (Off) When the Top door is open or the Base glass is not
in position.
NOTE: Do not open the Top door when the Status LED is blinking.
10 oXYgen Scanning Application - User Guide Addendum
Light Table
The Light Table feature is available with the iQsmart3. It enables you to use
the Base glass as a light table for evaluating and mounting original images.
To turn on the Light Table, do the following:
1. Open the Top cover of the scanner.
2. Press the Status button on the operating panel.
The Light Table turns on.
To turn off the Light Table, do the following:
Close the Top cover.
The Light Table turns off automatically.
Mounting Originals
This section describes the various methods for mounting originals on iQsmart
scanners.
NOTE: iQsmart users can find more information about masks and the Base glass in iQsmart Oil
Mounting Station (501L3R318). The general purpose and use of the masks is the same for all
iQsmart scanners, even though the masks themselves may differ.
The kit contains 11 masks, one of each of the 5 supplied masks and 6 user
defined masks.
16 Chapter 2 Preparation
Mounting Originals
This section describes the various methods for mounting originals in
the scanner.
Methods for mounting originals:
•Supplied masks
•mix format mask
•35-mm strip
•slide holder
•User defined masks
•Mounting originals directly in the scanner
•Oil mounting kit
Working with the scanner is more convenient and productive with
masks. Therefore, using masks is recommended.
The advantages of using masks include:
•Preparing the originals in advance on a different worktable, while
the scanner is busy with other scans.
•Positioning the originals is easier using the mask grid lines.
•The Base glass is kept clean (no tape marks).
•Defining multi-preview custom made formats. The defined user
formats will appear in the Format list of the application. After
preview, each image is displayed as a separate preview.
Before mounting, make sure the Base glass, Top glass and originals are
clean.
For information, refer to Oil Mounting Station With EverSmart Scanners
(Cat. No. 399Z52842A).
Mounting Originals 17
Supplied Masks
35-mm strip mask
This mask allows you to mount up to twelve 35-mm strips without a
need to cut them into separate images.
Mix format mask
With this mask, you can mount up to 26 transparencies of different
sizes, such as 35 mm, 6x7, or 4x5.
Slide Holder
The slide holder is designed for scanning up to twenty 35-mm slides
(framed 35-mm transparencies). The holder has five (5) rows, each can
hold four (4) slides. If necessary, a second holder can be used for
scanning up to 40 slides.
To use the slide holder, perform the following:
1.
1.1.
1. To insert slides, hold the slide holder with the printed side facing
you. Insert the first slide, emulsion side down and in the correct
orientation, into the bottom row. Push it all the way to the end of
the row.
2.
2.2.
2. Insert the other three slides in the same row.
18 Chapter 2 Preparation
3.
3.3.
3. When the first row is full, continue to the next row, and so on.
Make sure each slide is in its correct orientation.
Inserting slides into the slide holder
4.
4.4.
4. Mount the slide holder in the scanner with the printed side facing
you; insert the two (2) right registration holes of the slide holder
into the two right registration pins of the Base glass (the left hole
and pin are not used). The right side of the slide holder should be
aligned with the right side of the glass.
5.
5.5.
5. For more than 20 slides, use the second slide holder. Insert the
slides in the second slide holder in the same manner as in the first
holder.
For efficient scanner work, it is recommended that the bottom row is filled
first, and that each row is filled starting at the end of the row.
Mounting Originals 19
6.
6.6.
6. Mount the second slide holder in the scanner next to the first
holder; insert the left registration hole of the slide holder into the
left registration pin of the Base glass. Make sure the jigsaw edges
of the two slide holders interlock.
Two slide holders mounted in scanner
7.
7.7.
7. In Setup mode, choose 35-mm slide holder or 2 x 35-mm slide
holder from the Format options in the Setup dialog box,
depending on the mounted slide holders.
Refer to Chapter 4 Basic Scan on page 51 for details on the scan
procedure.
