Creda GCH 227 E Manuel utilisateur
ContactDetails
Pleasenotethatsomeofthecontactdetailson
thisPDFdocumentmaynotbecurrent.
Pleaseusethefollowingdetailsifyouneedto
contactus:
Telephone:08448793588
Email:[email protected]
TheHelpCentresectionofthiswebsitealsofeaturesawiderange
ofinformationwhichmaybeofusetoyouandisavailable24
hoursaday.Itincludes:
•Operatingandinstallationinstructionsdownloads
•Requestarepair
•Wheretobuyourproducts
•Literaturedownloads
•Heatingrequirementcalculator
www.credaheating.co.uk/help‐centre
A division of GDC Group Ltd
Millbrook House Grange Drive Hedge End Southampton SO30 2DF
www.credaheating.co.uk
Re
g
istered No: 1313016 En
g
land
VAT GB 287 1315 50004
EEE Producer Registration Number –
WEE/GE0057TS
Paper from sustainable sources
OPERATING INSTRUCTIONS FOR ‘GCH’ CONTROL
CONTROL MODULE type R80 ZSE designed for use with NOBO Panel heaters using Series 8 controls.
A Control module with fixed 16°C. economy setting, supplied with pilot wire for dual temperature applications.
Provides adjustable comfort temperature
and fixed economy temperature modes.
KEY to Fig. 1.
1 – Temperature adjustment control.
4 – Red Comfort mode indicator light.
5 – Green Economy mode indicator light.
6 – Amber operating indicator light.
8 – On / Off switch. l = On, 0 = Off.
OPERATING INSTRUCTIONS
Switch the heater on with switch (8).
Set required temperature with control (1).
Activate remote control device.
When the thermostat calls for heat the amber indicator (6) will also glow.
The action of the electronic thermostat provides proportional regulation of temperature. The Amber operating
indicator light will be seen to go on and off at frequent intervals as it adjusts the amount of heat supplied to
maintain room temperature. When room temperature is more than 1°C below the thermostat set point the
heater will operate continuously but during the last one degree the operation will be proportionally reduced
until the required temperature is achieved.
When the green indicator (5) is visible the heater will operate in economy mode and maintain the pre-set
background temperature. When the remote control device is activated the mode of operation is changed
from economy mode to comfort mode. The green indicator will go out and the red indicator (4) will come
on. If the room temperature is below the set point (1) the amber indicator (6) will come on and the heater
will raise room temperature accordingly. When the remote control device is de-activated heater will go
back to economy mode.
ACCESSORIE
S
Tamperproof covers are available for the switch and temperature scale mechanisms.
NOTE
The heater should not be covered or things be placed on or over the heater.
The heater is fitted with an over-temperature cut-out which will switch off the heating element in the event of
the heater becoming too hot. The element will not be switched back on again until the heater has cooled.
CLEANING
The heater may be cleaned with a damp cloth and mild detergent.
The heater may be tilted forwards on its mounting bracket for cleaning and decorating behind the heater.
Pressing the clips downward at the back of the heater will release the heater from the mounting bracket.
Telephone: 0121 328 5671 Facsimile: 0121 327 8580 Series 8 - GCH. txt - 227 E
GCH Temperature control module. 227 E
