Creative ZEN Zen V 1GB Manuel utilisateur

Congratulations 1 English

Congratulations

Thank you for purchasing Creative ZEN™ V / ZEN V Plus! Read on to learn

how to get started with your new player!

To get the most out of your player, also read the comprehensive User’s

Guide on your Installation and Applications CD.

NOTE Product specifications may vary, depending on model purchased.

( )

1. Power switch

2. Lock

3. Microphone

4. LINE IN jack

5. Headphone jack

6. USB 2.0 port

7. Volume Increase

button

8. Volume Decrease

button

9. Record button

10. Play/Pause button

11. Back/Options

button

12. 5-way Navigation

Joystick

13. Reset button

Zen V_CLI.fm Page 1 Thursday, May 25, 2006 3:52 PM

2 Using the 5-Way Navigation Joystick

Using the 5-Way Navigation Joystick

The 5-way Navigation Joystick is one of the most important features of your

player. In this document, we will use the term "Select" to mean that you

should push the 5-way Navigation Joystick up or down to browse through

options, and then select the option by pressing down the 5-way Navigation

Joystick.

When playing music, you can do the following:

■push the joystick left or right to go to the previous or next track.

■push and hold the joystick right or left to move forward or

backward within a track.

NOTE At any time, press and hold the Back/Options button for more

options.

Zen V_CLI.fm Page 2 Thursday, May 25, 2006 3:52 PM

Getting Started 3

Getting Started

Step 1: Set up the software

1Turn on your computer.

You must log in as an administrator before you can set up the software. For

more information, refer to your operating system’s online Help.

2Insert the Installation and Applications CD into your CD-ROM/DVD-ROM

drive.

Your CD should start automatically. If it does not, follow the steps below:

i. Double-click the My Computer icon.

Alternatively, click Start →My Computer.

ii. Right-click the CD-ROM/DVD-ROM drive icon, and then click

Autoplay.

3Follow the instructions on the screen and when prompted, restart your

computer.

4When your computer restarts, follow the product registration instructions

on the screen.

WARNING DO NOT connect your player to your computer before setting up the

software.

NOTE You will require an Internet connection to register your product.

Zen V_CLI.fm Page 3 Thursday, May 25, 2006 3:52 PM

4 Charge Your Player

Step 2: Charge Your Player

1If you have not done so, connect your player to your computer’s USB port

with the supplied USB cable.

When the battery is charging, the battery charging icon flashes on the

Organic Light Emitting Diode (OLED) display.

WAR NI NG : The cord(s) included with this product may contain chemicals known to the State of

California to cause cancer and birth defects or other reproductive harm. Wash hands after handling.

NOTE ■For continuous battery charging using the USB port, make sure

your computer is not in power conservation mode. For more

information on power conservation modes, refer to your

operating system's Help.

■Connect to a computer USB port only; avoid connecting to a USB

hub.

■For express battery charging without using your computer,

purchase the ZEN Power Adapter. For more information on this

and other ZEN V Series accessories, visit www.creative.com.

Zen V_CLI.fm Page 4 Thursday, May 25, 2006 3:52 PM

Select Your Menu Language 5

2Disconnect your player from your computer when the battery is fully

charged and you see on your player’s OLED display. The battery is fully

charged in approximately six hours. If your fully charged player remains

connected to your computer for a prolonged period, the OLED display

blanks out automatically to save battery power.

Step 3: Select Your Menu Language

1If your player is not turned on, slide the Power switch towards the Power

icon and hold it there until the OLED display lights up.

2When you turn on your player for the first time, the menu is in English. To

change the language:

i. Press the Back/Options button. The main menu appears.

ii. Select System →Language, and then select the language that

you want.

3After you have finished using your player, slide the Power switch towards

the Power icon until the Shutting down message appears.

Step 4: Transfer Content

Transfer music and other files from your CD collection or computer. For

more details, see “Managing Music, Videos and Data” on page 10.

NOTE Your player will continue charging even after it turns off, as long as it

is connected to a computer or power outlet.

Zen V_CLI.fm Page 5 Thursday, May 25, 2006 3:52 PM

6 Transfer Content

To transfer or ‘rip’ music from your CD collection

1Make sure your player is connected to your computer as shown on page 4.

2Double-click the ZEN V Series Media Explorer icon on the desktop.

3Click the Rip Audio CDs button.

4Follow the instructions on the screen.

If you are connected to the Internet, album information is automatically

retrieved.

To transfer music, pictures or videos from your computer

1Repeat steps 1 and 2 in "To transfer or ‘rip’ music from your CD collection"

above.

2Click the Browse Media button.

3Locate your media files, and using the drag-and-drop method, copy them to

the following folders in your player:

■Media Library\Music folder for audio files

■Media Library\Videos folder for videos

■Media Library\Pictures folder for pictures.

NOTE ■Use Creative Media Explorer, Creative MediaSource Player/

Organizer or Windows Media Player 10 (and above) to transfer

files protected by Digital Rights Management (DRM) technology.

■The video function is available on ZEN V Plus players only.

■All video formats require conversion before they can be played on

your ZEN V Plus. Use Creative Media Explorer or Creative

MediaSource Player/Organizer only to convert your videos. Note

that if you choose to skip a video file, it will not be transferred to

your player.

Zen V_CLI.fm Page 6 Thursday, May 25, 2006 3:52 PM

Disconnect Your Player 7

To transfer data files

1Repeat steps 1 and 2 in “To transfer or ‘rip’ music from your CD collection”

on page 6.

2Click the Browse Documents button.

3Locate your data files, and using the drag-and-drop method, transfer them

to the Data folder in your player.

Step 5: Disconnect Your Player

When you have finished transferring files, disconnect your player.

DO NOT disconnect your player if you see the left picture below on the

display. Track or data file transfer is in progress and disconnecting your

player may damage the content being transferred. When you see the right

picture below on the display, disconnect your player.

NOTE ■You can also transfer audio files, pictures and videos using the

Browse Documents button. They will, however, be treated as

data files and cannot be played back or viewed on your player.

■Use your player's Removable Disk mode if you need to transfer

and manage data between your player and computers that do not

have Creative Media Explorer. For more information, see the

User’s Guide on your Installation and Applications CD.

Docked Docked

Zen V_CLI.fm Page 7 Thursday, May 25, 2006 3:52 PM

8 Play Media Files or View Pictures

Step 6: Play Media Files or View Pictures

You are now ready to play or view files, including Audible®and ZENcast

audio files.

To play music and Audible files

1Connect your earphones to the Headphone jack.

2In the main menu, select Music Library →category that you want.

3Select a track and select Play.

4Press the Volume Increase and Volume Decrease buttons to adjust

the volume.

NOTE ■The video function is available on ZEN V Plus players only.

■At any time, press and hold the Back/Options button for more

options.

■Files in your player are sorted alphabetically for quicker

searches.

NOTE ■To manage Audible files, you need to install AudibleManager®.

■Audible files are currently available to selected regions only.

■If available with a music track, album art will be displayed on

your player.

Zen V_CLI.fm Page 8 Thursday, May 25, 2006 3:52 PM

Play Media Files or View Pictures 9

To play ZENcast audio files

With Creative ZENcast Organizer, you can subscribe to your favorite

ZENcast channels, and download and transfer ZENcast audio files to your

ZEN V / ZEN V Plus. For more information, visit www.zencast.com.

To view pictures

1In the main menu, select Photos, and select the picture you want.

2Press and hold the Back/Options button

3Select Zoom In, and use the 5-way Navigation Joystick to pan the picture

horizontally or vertically.

To play videos

In the main menu, select Videos →Video →video that you want.

NOTE ■The video function is available on ZEN V Plus players only.

■ZENcast video files are not supported by your player.

Zen V_CLI.fm Page 9 Thursday, May 25, 2006 3:52 PM

10 Managing Music, Videos and Data

Managing Music, Videos and Data

Creative Media Explorer and Creative MediaSource Player/Organizer are

included with your player. Try out these applications to decide which one is

more suitable for your needs.

Creative Media Explorer

Use Creative Media Explorer if:

■you are new to digital music and videos, and want to transfer them

from your CDs or computer to your player

■you want to convert, synchronize, and organize audio and video

files

■you prefer to manage your player in the familiar “Windows

Explorer” environment.

To start Creative Media Explorer, double-click the ZEN V Series Media

Explorer icon under My Computer or on the desktop. For more

information about using Creative Media Explorer, refer to its online Help.

Creative MediaSource Player/Organizer

Use the full-featured Creative MediaSource Player/Organizer if:

■you require additional features such as recording, automatic

playlist generation, and audio format conversion

■you want to manage a music library on your computer.

To start Creative MediaSource Player/Organizer, double-click the Creative

MediaSource Player/Organizer icon on your desktop.

Creative MediaSource Player/Organizer has a Home page from which you

can access common tasks. For more information about using Creative

MediaSource Player/Organizer, refer to its online Help.

NOTE The video function is available on ZEN V Plus players only.

Zen V_CLI.fm Page 10 Thursday, May 25, 2006 3:52 PM

Autres manuels pour ZEN Zen V 1GB

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Creative Lecteur MP3

Creative

Creative ZEN Mozaic Manuel utilisateur

Creative

Creative Titanium - TravelSound MP3 Titanium Manuel utilisateur

Creative

Creative ZEN MOZAIC EZ300 Manuel utilisateur

Creative

Creative ZEN Style M300 Manuel utilisateur

Creative

Creative ZEN Manuel utilisateur

Creative

Creative TRAVELSOUND I85 Manuel utilisateur

Creative

Creative ZEN Wav Manuel utilisateur

Creative

Creative Muvo Muvo2 FM Manuel utilisateur

Creative

Creative MuVo S200 Manuel utilisateur

Creative

Creative 70PF122200016 - Zen Nano 512 MB Digital... Manuel utilisateur

Creative

Creative Muvo V200 QSG Manuel utilisateur

Creative

Creative NOMAD Muvo Manuel utilisateur

Creative

Creative Muvo Audible Manuel utilisateur

Creative

Creative TRAVELSOUND I50 - QUICKSTART BACK Manuel utilisateur

Creative

Creative Muvo Muvo NX 128MB Manuel utilisateur

Creative

Creative Muvo V200_QSG Manuel utilisateur

Creative

Creative TRAVELSOUND I80 Manuel utilisateur

Creative

Creative NOMAD Jukebox ZEN NX 20GB Manuel utilisateur

Creative

Creative CLE Manuel utilisateur

Creative

Creative SOUND BLASTER X-FI GO - QUICKSTART FRONT Manuel utilisateur

Creative

Creative ZEN Style M100 Manuel utilisateur

Creative

Creative T12 WIRELESS Manuel utilisateur

Creative

Creative ZEN ZEN Micro 5GB Manuel utilisateur

Creative

Creative ZEN STONE Manuel utilisateur

Manuels Lecteur MP3 populaires d'autres marques

Blaupunkt

Blaupunkt Compact Drive MP3 Manuel utilisateur

Memorex

Memorex MMP9008 - 8GB USB 2.0 Manuel utilisateur

Meizu Electronic Technology

Meizu Electronic Technology E5 Manuel utilisateur

Naxa

Naxa NMV-173NX Manuel utilisateur

Philips

Philips PSA250 Manuel utilisateur

Zipy

Zipy go! Waving Manuel utilisateur

Sylvania

Sylvania SMPK4068 Manuel utilisateur

Sony

Sony NW-MS7 - Memory Stick Walkman Manuel utilisateur

Irradio

Irradio RF-42UC Manuel utilisateur

NABAIJI

NABAIJI SWIM MUSIC 100 Manuel utilisateur

Laser

Laser MP3-A9-4GB Manuel utilisateur

Samsung

Samsung YP-T7F Manuel utilisateur

Savant

Savant SMS-1001-00 Guide de référence rapide

Trevi

Trevi XP 71 BT Manuel utilisateur

AGPtek

AGPtek C2 Manuel utilisateur

MobiBlu

MobiBlu DAH-1500i Manuel utilisateur

Denver

Denver MPS-201 Manuel utilisateur

Steren

Steren MP3-002 Manuel utilisateur
