Operator's Manual

3.2 Amp 22-in.

ELECTRIC

HEDGE TRIMMER

Model No.

172.79957

IWARNING: Read, understand and follow

_1 all Safety Rules and Operating Instructions

l in this manual before using this product.

• SAFETY

• ASSEMBLY

• OPERATION

• MAINTENANCE

• PARTS LIST

? For answers to your questions about this product:

Call 7AM - 7 PM, Mon.-Sat; Sun, 10 am -7pm

1-800-4-MY-HOME® (Hours listed are Central Time)

Sears, Roebuck and Co., Hoffman Estates, IL 60179 U.S.A.

Warranty. ................................................................. Page 2

Safety Rules ......................................................... Pages 3-8

Description .............................................................. Page 9

Specifications .......................................................... Page 9

Operation ............................................................ Pages 10-13

Maintenance ........................................................... Pages 14-15

Repair Parts ............................................................ Pages 16-17

ONE YEAR FULL WARRANTY ON CRAFTSMAN

ELECTRIC HEDGE TRIMMER

If this Craftsman Electric HedgeTrimmer fails due to defects in material or

workmanship within one year from the date of purchase, RETURN IT TO

THE NEAREST SEARS STORE IN THE UNITED STATES, and Sears will

replace it, free of charge.

If this Craftsman Electric Hedge Trimmer is used for commercial or rental

purposes, this warranty applies for only 90 days from the date of purchase.

This warranty gives you specific legal rights, and you may also have other

rights which vary from state to state.

Sears, Roebuck and Co., Dept. 817 WA, Hoffman Estates, IL 60179

SAVE THESE INSTRUCTIONS!

READ ALL INSTRUCTIONS!

The purpose of safety symbols is to attract your attention to possible

dangers. The safety symbols and their explanations deserve your careful

attention and understanding. The safety warnings do not by themselves

eliminate any danger. The instructions or warnings they give are not

substitutes for proper accident prevention measures.

I SYMBOL MEANING I

di_ _ k DANGER: Failure to obey a safety

warning will result in serious injury to

yourself or to others. Always follow the

safety precautions to reduce the risk of

fire, electric shock and personal injury.

A!.WARNING: Failure to obey a safety

4!I_ warning can result in serious injuryto

yourself or to others. Always follow the

safety precautions to reduce the risk of

fire, electric shock and personal injury.

CAUTION: Failure to obey a safety

warning may result in property damage

or personal injury to yourself or to others.

Always follow the safety precautions to

reduce the risk of fire, electric shock and

personal injury.

NOTE: Advises you of information or instructions vital to the operation or

maintenance of the equipment.

Read the operator's Manual(s) and follow all warnings and safety

instructions.

Failure to do so can result in serious injury to the operator and/or

bystanders.

GENERAL SAFETY INSTRUCTIONS

READ ALL INSTRUCTIONS/PLAN AHEAD

SYMBOL MEANING

WARNING: If correctly used, this hedge

trimmer is a quick, easy to handle and efficient

tool; if used improperly or without the due

precautions it could become a dangerous tool.

For pleasant and safe work, ALWAYS strictly

comply with the safety rules that are contained

in this manual.

WARNING: BE SURE to read and understand

all instructions.Failure to follow all instructions

listed below may result in electric shock, fire

and/or serious personal injury.

Safety is a combination of common sense, staying alert, and knowing

how to use your tool.

WARNING: To avoid mistakes that could [

cause serious injury, DO NOT plug in the I

hedge trimmer until the following steps have

been read and understood.

1. ALWAYS avoid dangerous conditions. DO NOT use in wet or damp areas

or expose to rain.

2. DO NOT use in the presence of flammable gases or liquids.

3. ALWAYS keep bystanders at a safe distance. NEVER allow children

near the tool.

4. ALWAYS dress for safety. DO NOT wear loose clothing, gloves,

neckties, or jewelry (rings, watches, etc.) when operating tool. They can

get caught and draw you into moving parts.

5. ALWAYS wear eye protection.

6. ALWAYS remove the power cord plug from the electrical outlet when

making adjustments, changing parts or cleaning.

7. ALWAYS avoid accidental start-ups. ALWAYS make sure the power

switch is in the OFF position BEFORE plugging in the power cord.

8. DO NOT abuse the power cord. DO NOT use it to carry the tool.

ALWAYS keep the cord away from heat, oil, sharp edges or moving

parts. Replace damaged cord immediately; they may create a shock or

fire hazard.

9. NEVER leave a running tool unattended. Turn the power switch to OFF.

DO NOT leave the tool until it has come to a complete stop.

10. DO NOT overreach. ALWAYS keep proper footing and balance at all

times. SAVE THESE SAFETY INSTRUCTIONS

GENERAL SAFETY INSTRUCTIONS cont.

11. DO NOT operate this unit while tired, ill or under the

influence of alcohol, drugs, or medication.

12. Children MUST NOT operate the unit.

13. Secure hair above shoulder length. DO NOT wear loose

clothing or jewelry; they can get caught in moving parts.

14. ALWAYS inspect the unit before use. Replace all damaged

parts prior to starting. MAKE SURE the unit is in original

operating condition before operating.

15. Know the controls and know how to stop the blade quickly.

16. Wear protective gear. ALWAYS use appropriate work

shoes, snug-fitting clothing; heavy- duty non-slip gloves;

eye protection such as non-fogging, vented goggles or

face screen; and sound barriers (ear plugs or muffles to

protect your hearing.

17. MAINTAIN TOOLS PROPERLY. ALWAYS keep tools clean

and in good working order.

18. CHECK FOR DAMAGED PARTS. Check for alignment of

moving parts, binding, breakage, or any other conditions

that may affect the tool's operation. Any part that is

damaged should be properly repaired or replaced before

use.

19. KEEP THE HANDLE DRY, CLEAN AND FREE OF OIL AND

GREASE. ALWAYS use a clean cloth when cleaning.

DO NOT use solvents, brake fluids, gasoline, or other

petroleum products to clean the tool, they may damage

plastic parts.

ARNING! The operation of any trimmer can

result in foreign objects being thrown into your

eyes, which can result in severe eye damage.

Before beginning power tool operation,

ALWAYS wear safety goggles or safety glasses

with side shield and a full face shield when

needed. We recommend a Wide Vision Safety

Mask for use over eyeglasses or standard

safety glasses with side shield, available at

Sears Retail Stores.

SAVE THESE SAFETY INSTRUCTIONS

ELECTRICAL SAFETY

1. Double insulated tools are equipped with a polarized plug

(one blade is wider than the other). This plug will fit in a

polarized outlet only one way. If the plug does not fit fully

into the outlet, reverse the plug. If it still does not fit,

contact a qualified electrician to install a polarized outlet.

DO NOT change or alter the plug in any way.

2. Double insulation SYMBOL eliminates the need for the three

wire grounded power cord and grounded power supply

system. Applicable only to Class II (double insulated) tools.

3. Before plugging in the tool, BE SURE that the outlet voltage

supplied is within the voltage marked on the tool's data plate.

DO NOT use "AC only"rated tools with a DC power supply.

4. If operating the power tool in damp locations is

unavoidable, ALWAYS use a Ground Fault Circuit

Interrupter to supply power to your tool. ALWAYS wear

electrician's rubber gloves and footwear in damp

conditions.

5. DO NOT expose power tools to rain or wet conditions.

Water entering a power tool will increase the risk of electric

shock.

6. DO NOT abuse the cord. NEVER use the cord to carry the

tools or pull the plug from the outlet. Keep cord away

from heat, oil, sharp edges or moving parts. Replace

damaged cords immediately. Damaged cords increase the

risk of electric shock.

8. When operating a power tool outside, ALWAYS use an

outdoor extension cord marked "W-A" or "W". These cords

are rated for outdoor use and reduce the risk of electric

shock.

NOTE: The extension cord must have adequate wire size AWG

(American Wire Gauge) for safe, efficient use. Smaller gauge wires,

have greater capacity (16 gauge wire has more capacity than 18 gauge wire).

SPECIFIC SAFETY RULES FOR HEDGE TRIMMERS

1. ALWAYS avoid accidental starting. DO NOT carry a

plugged in trimmer with you finger on the switch. Be sure the

switch is in the OFF position BEFORE plugging it in.

2. DO NOT carry the trimmer by the cord or yank cord to

disconnect it from power receptacle. Keep cord away from

heat oil and sharp edges.

DANGER: Risk of Cut. Keep hands away from blades. Keep

both hands on handle when operating trimmer.

3. DO NOT attempt to remove cut material or hold material to be cut

when blades are moving. ALWAYS make sure the trimmer switch is

OFF when clearing jammed material from blades. DO NOT hold the

exposed cutting blades or cutting edges when picking up or holding

the hedge trimmer.

I_'I CAUTION: The blades continue to coast after the trimmer is shut off

4. DO NOT FORCE THE TRIMMER. It will do the job better and with less

chance of injuryat the rate for which it was designed.

5. DO NOT OVERREACH. Keep proper footing and balance at all times

6. STAY ALERT. Watch what you are doing. Use common sense. DO NOT

operate the trimmer when you are tired.

7. ALWAYS disconnect the trimmer from power source when not in use,

or when you are cleaning or servicing it.

8. ALWAYS store the trimmer indoors, when not in use. It should be stored

dry and high or locked in place that is out of the reach of children.

9. ALWAYS maintain the trimmer with care. ALWAYS Keep cutting blades

sharp and clean for best performance and to reduce the risk of injury.

ALWAYS inspect the extension cord periodically and replace it if damaged.

ALWAYS keep handles dry, clean and free from oil and grease.

10. CHECK FOR DAMAGED PARTS. Before further use of the

hedge trimmer, aguard or other par that is damaged

should be carefully checked to determine that it will operate

properly and perform its intended function. Check for

alignment of moving parts; binding of moving parts:

breakage of parts: mounting and any other condition that

may affect its operation. A guard or other part that is

damaged, should be properly repaired or replaced at an

authorized Sears Service Center.

WARNING: Some dust particles created by using lawn and

garden tools contains chemicals known to cause cancer,

birth defects or other reproductive harm. Some examples

of these chemicals are:

• Compounds in fertilizers, herbicides, pesticides, insecticides.

•Arsenic and chromium from chemically-treated lumber.

Your risk from these exposures varies, depending upon how

often you do this type of work. To reduce your exposure to these

chemicals:

• Work in a well-ventilated area.

•Work with approved safety equipment, such as those dust

masks that are specially designed to filter out microscopic

particles.

Your hedge trimmer has many built-in convenience features for fast, efficient

cutting. These features include the trigger switch with a saftey switch to

prevent accidental starts. Both must be pressed to start unit.

Fig. 1 Trigger Switch

Saftey Switch

Cord

Retainer

Guard

\Two Screws

to attach Guard

Blade Length 22 inches

Speed (Cutting Strokes per Minute) 3000

Cutting Capacity 3/4-inch

Cutting Action Dual

Power Requirement 120-volt, 60 Hertz AC

A'n'ACHING THE SAFETY GUARD (Figure 2)

After removing your hedge trimmer from the carton. Install the safety guard as

follows:

I_. I WARNING: To prevent serious personal injury, NEVER operate

Iyour trimmer without the safety guard in place.

1. Place the safety guard on

the trimmer, at the base of the

cutting blade (see Fig. 2).

2. Align the screw holes in the

guard with the holes in the

trimmer (see Fig. 2).

3. Insert a screw on each end

of the safety guard, using a

Phillips screwdriver.

DO NOT over tighten.

I Fig. 2

A'I-rACHING AN EXTENSION CORD (Figure 3)

An extension cord retainer is attached to the

power cord of the trimmer. This helps to

prevent the tool from unplugging. To use this

feature, simply double the extension cord about

8 inches from the end and insert it into the two

open slots at the end of the retainer (see Fig. 3).

Gently tug on the extension cord to be sure it's

firmly attached, then plug the extension cord

into a standard household receptacle.

Fig. 3

Power

Cord

ALWAYS use the trimmer properly. Before starting trimmer,

hold the unit with both hands with the blade facing away from you.

ALWAYS keep the cord behind the trimmer when in use.

DO NOT place cord over hedge where it can be cut by the blade.

TO TURN TOOL ON

Your trimmer is equipped with a safety switch to help prevent accidental starts.

You must press both the safety switch and the trigger switch to start the unit.

Autres manuels pour 172.79957

Table des matières

Autres manuels Craftsman Tondeuse

Craftsman

Craftsman Incredi-Pull 316.791200 Manuel utilisateur

Craftsman

Craftsman 316.792540 Manuel utilisateur

Craftsman

Craftsman 358.797150-32cc Important Manuel d'utilisation

Craftsman

Craftsman WEEDWACKER 358.799110 Manuel utilisateur

Craftsman

Craftsman Weedwacker 358.745310 Manuel utilisateur

Craftsman

Craftsman 316.74093 series Manuel utilisateur

Craftsman

Craftsman 316.791961 Manuel utilisateur

Craftsman

Craftsman WEEDWACKER 358.792011 Manuel utilisateur

Craftsman

Craftsman WEEDWACKER 358.798540 Manuel utilisateur

Craftsman

Craftsman WEEDWACKER 358.791820 Manuel utilisateur

Craftsman

Craftsman WEEDWACKER 358.745170 Manuel utilisateur

Craftsman

Craftsman CMEHTS822 Manuel utilisateur

Craftsman

Craftsman 536.797571 Manuel utilisateur

Craftsman

Craftsman 172.797760 Manuel utilisateur

Craftsman

Craftsman weedwacker 358.798420 Manuel utilisateur

Craftsman

Craftsman Weedwacker 172.74533 Manuel utilisateur

Craftsman

Craftsman WEEDWACKER 316.745400 Manuel utilisateur

Craftsman

Craftsman WEEDWACKER 316.731972 Manuel utilisateur

Craftsman

Craftsman CMXGCAQ108493 Manuel utilisateur

Craftsman

Craftsman 151.30383 Manuel utilisateur

Craftsman

Craftsman WEEDWACKER 358.795160 Manuel utilisateur

Craftsman

Craftsman WEEDWACKER Incredi-Pull 316.791160 Manuel utilisateur

Craftsman

Craftsman WEEDWACKER INCREDI.PULL 316.791932 Manuel utilisateur

Craftsman

Craftsman CMESTA900 Manuel utilisateur

Manuels Tondeuse populaires d'autres marques

MTD

MTD HT 51 E Manuel utilisateur

McCulloch

McCulloch T22 LS Manuel utilisateur

COCKRAFT

COCKRAFT PRO HL36-S Manuel utilisateur

Grizzly

Grizzly CT 1800 Li Manuel utilisateur

Peco

Peco Z Trimmer ZT-3000 Manuel utilisateur

Solo

Solo 116 Manuel utilisateur

Stiga

Stiga ST 1200 Manuel utilisateur

Echo

Echo GT-225 - 10-09 Manuel utilisateur

RedMax

RedMax BT17 Manuel utilisateur

GreenWorks

GreenWorks STA806 Manuel utilisateur

Parkside

Parkside PHSL 900 A3 Manuel utilisateur

Gardeo

Gardeo PRO GPTHT2560 Manuel utilisateur

Park

Park DT-810870 Manuel utilisateur

Worx

Worx WG209 Manuel utilisateur

Gardenline

Gardenline 43671/HTKS26 Manuel utilisateur

Makita

Makita 3710 Manuel utilisateur

Champion

Champion 100683 Manuel utilisateur

Stihl

Stihl FS 311 Manuel utilisateur
