COX Ultrapoint AIR Manuel
Instructionleaflet
TheCoxUltrapointAIRisdesignedtoapplymortarsandtilegroutsefficientlyandcleanly.Itspowerfulactionpumpsthe
mortardeepintojointstominimisevoidsformaximumjointstrength.
Safety
1. Readandunderstandinstructionsbeforeusingthisproduct
2. Keepinstructionsafeforfuturereference
3. Weareyeprotectionandhearingprotectionwhenusingpneumatictools
4. Disconnectthisapplicatorfromairsupply(F)whenfillingorcleaningit.
Operation
5. Connectproducttoairsupply;pressOperatingTrigger(C)andAirReturnButton(A);thiswillcausetherodand
plungerassemblytomovetotherearofBarrel.
6. RemoveBarrelfromframe.
7. Disconnectairsupply(F)
8. FillBarrelwithMortar/Grout(seemixinginstructionoverleaf)
9. ReplaceBarrelinframe,ensureBarrelisplacedoverPlungerassembly
10. Reconnectairsupply(F).
11. DepressOperatingTriggertodispenseMortar/Grout(flowratecanbeadjustedbyturningtheAirFlow
AdjustmentKnob(B)).
(C) AirReturnButton
(D) AirFlowAdjustmentKnob(F) OperatingTrigger
(B) Barrel(A) Nozzle
(E) AirConnection
Caution
Theairsupplytothisproductmustnotexceed145psi(10Bar)
RecommendedMortarMix
1partcement
½parthydratedlime(optional)
Plasticisertosupplier’sinstructions
5partssievedbuilder’ssand.
Goodmixingiscritical,usingaCoxmixingpaddleisstronglyrecommended.Mixfor4or5minutestoachievea
smooth,butterymixturefreeoflumps.Ifmixinginacontainer,ensurethatthereisnounmixedmaterialinthecorners.
Addingmorewaterisnosubstituteforgoodmixing.
Addtheplasticisertothewaterratherthantheotherwayround.Poutingwaterintotheplasticisercanproducetoo
muchfroth.
Applyingthematerial
12. TheUltrapointAIRworkslikeanypneumaticsealantapplicator,flowratecanbeadjustedbyturningtheAir
FlowAdjustmentKnob(B)ontherearoftheproduct.
13. UsetheBlackNozzleforpointingandtheGreyNozzleforgrouting(mortarsaretoocoarsetoflowthroughthe
greynozzle).
14. Ifthegunblocks,thenremoveBarrel(steps5‐6frompreviouspage);emptycontentsandtryre‐mixing.
15. Ifproductwillnotflowproperly;thismaybedueto:
Incompletemixing
Insufficientplasticiserinmix
Sharpsandorgravelinthemix
Sandandcementpremixseparatinginthebag(ensurewhenusingpre‐baggedmix,thatdrymaterialsare
mixedproperly
Nozzleopeningtofine.
16. Avoidmortarcontaminatingthegunbyregularlyrinsingtherodandplungerassembly,alwayswashbarreland
nozzlethoroughlyafteruse.
Adjustingtheplunger
PCCoxLtd,TurnpikeRoad,Newbury,Berkshire,RG142LR
Tel:Sales+44(0)1635264500Fax:+44(0)1635264555E‐mail:[email protected]http://www.pccox.co.uk
1P26595
Theplungerisadjustableforwear.Tighteningthenutswillsqueezethe
rubbertotightenitsfitintheBarrel.
Note:Iftheplungerisdifficulttomoveevenwhenwetitmaybeover‐
tightened.Looseningthenutswillsolvethisproblem.
Do
Usetherightingredients
Mixwellwithapaddle
Choosetherightnozzle;blackfor
mortarsandgreyforgrouting
Don’t
Usesharpsand.Itwon’tflow
Usegravel.Itwillblockthenozzle
Makesomuchmixthatitstandsfortoolong
Usefineopeningofgreynozzlesformortars
