COTRE CO06D Manuel utilisateur

CO06D Digital Radio

Quick Start Guide

COTRE

To Users

Thank you for purchasing our product! This Manual is designed to

make you quickly grasp use of this device. In order to avoid physical

injury or property loss due to improper operation, please read this

Manual carefully before using this device.

Notice

The device meets the requirements of FCC PART 90, PART 97 and

PART 15. Local laws and regulations shall be complied with when

setting up or using the equipment, and corresponding qualifications

and relevant procedures shall be obtained if necessary. Consulting the

relevant authorities is suggested.

This equipment has been tested and found to comply with the limits for

a Class B digital device, pursuant to Part 15 of the FCC Rules. These

limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates,

uses and can radiate radio frequency energy and, if not installed

and used in accordance with the instructions, may cause harmful

interference to radio communications.However, there is no guarantee

that interference will not occur in a particular installation.

If this equipment does cause harmful interference to radio or television

reception, which can be determined by turning the equipment o󰀨 and

on, the user is encouraged to try to correct the interference by one or

more of the following measures:

·Reorient or relocate the receiving antenna.

·Increase the separation between the equipment and receiver.

·Connect the equipment into an outlet on a circuit di󰀨erent from that

to which the receiver is connected.

·Consult the dealer or an experienced radio/TV technician for help.

This device complies with Part 15 of the FCC Rules. Operation is

subject to the following two conditions:

Using Tips

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including

interference that may cause undesired operation.

ISEDC RSS warning

This product meets the applicable Industry Canada technical

specifications. / Le présent matériel est conforme aux specifications

techniques applicables d’Industrie Canada.

RF Radiation Information

1. This product is limited to occupational applications that can meet

RF energy radiation requirements. The user must be fully aware of

the RF radiation hazards and can take corresponding measures to

meet the RF radiation limitation requirements.

2. Radio frequency (RF) refers to the electromagnetic frequency that

can be radiated into space. It is a widely used technology in the

elds of communication, medical treatment, and food processing. It

will generate certain RF radiation during use.

Safety Information

In order to use the radio safely and e󰀩ciently, please read the following

safety information:

·The radio can only be maintained by professional technicians. Do not

disassemble the radio without permission.

·Only the batteries and chargers specied by our company can be

used.

·To avoid problems caused by electromagnetic interference and

electromagnetic compatibility, please turn o󰀨 the radio in places

where the "Please turn o󰀨 the radio" sign is displayed, such as

hospitals and other health care places. When taking the ight, please

turn o󰀨 the radio if the crew requests to do so.

Using Tips

·In vehicles with airbags, do not place the radio in the area where

airbag deployment may be involved.

·Please turn o󰀨 the radio before entering ammable or explosive

environment.

·Do not replace or charge the battery in a ammable or explosive

environment.

·Please turn o󰀨 the radio before approaching the blasting area and

the detonator area.

·Do not use the radio with damaged antenna. A damaged antenna

may cause minor burns when it comes into contact with the skin.

·Do not expose the radio to direct sunlight for a long time or place it

near the heating Radio.

·If you wear a portable radio, make sure the antenna is at least 2.5

cm away from your body when the radio is transmitting.

WARNING:

Changes or modications to this unit not expressly approved by the

party responsible for compliance could void the user’s authority to

operate the equipment.

CAUTION:

Use the approved charger to charge the battery. The remaining

lithium-ion battery is limited to 30% pursuant to the new lithium battery

shipment regulation approved by International Air Transport Association

(IATA). Before use, charge the battery. It is recommended that the radio

remain powered o󰀨 during charging.

Use of battery not recommend or replaced with incorrect type of battery

may result in a risk of re and explosion or personal injury.

Maximum ambient temperature around the power supply equipment

including charger must not exceed 40℃(104ºF) and device operating

temperature not exceed 55℃(131ºF).

Using Tips

RF Exposure Compliance and Control Guidelines and

Operating Instructions

To control your exposure and ensure compliance with the occupational/

controlled environment

exposure limits always adhere to the following procedures.

Guidelines:

• Do not remove the RF Exposure Label from the device.

• User awareness instructions should accompany device when

transferred to other users.

• Do not use this device if the operational requirements described

herein are not met.

Operating Instructions:

• Transmit no more than the rated duty factor of 50% of the time.

To transmit (talk), push the Push-To-Talk (PTT) button. To receive

calls, release the PTT button. Transmitting 50 % of the time, or

less, is important because this radio generates measurable RF

energy exposure only when transmitting (in terms of measuring for

standards compliance).

• Hold the radio in a vertical position in front of face with the

microphone (and the other parts of the radio, including the antenna)

at least one inch (2.5 cm) away from the nose. Keeping the radio at

the proper distance is important because RF exposures decrease

with distance from the antenna. Antenna should be kept away from

eyes.

• When worn on the body, always place the radio in approved clip,

holder, holster, case, or body harness for this product. Use of non-

approved accessories may result in exposure levels, which exceed

the occupational/controlled environment RF exposure limits.

• Use only manufacturer’s approved supplied or replacement

antennas, batteries, and accessories. Use of non-manufacturer-

name approved antennas, batteries, and accessories may exceed

the FCC and IC RF exposure guidelines.

Using Tips

• For a list approved accessories please consult your local dealer for

information.

European Union (EU) Waste of Electrical and Electronic

Equipment (WEEE) directive：

The European Union's WEEE directive requires that products sold into

EU countries must have the crossed out trash bin label on the product

(or the package in some cases). As dened by the WEEE directive, this

cross-out trash bin label means that customers and end-users in EU

countries.

EXPOSURE RF compliance et Lignes de

contrôle et Instructions opérationnelles

Pour contrôler votre exposition et garantir le respect des limites

d'exposition dans un environnement professionnel / contrôlé, suivez

toujours les procédures suivantes.

Des lignes directrices:

• Ne retirez pas l'étiquette d'exposition RF de l'appareil.

• Les instructions de sensibilisation des utilisateurs doivent

accompagner l'appareil lors de leur transfert à d'autres utilisateurs.

• N'utilisez pas cet appareil si les exigences opérationnelles décrites ici

ne sont pas remplies.

Mode d'emploi:

• Ne transmet pas plus que le facteur de marche nominal de 50%

du temps. Pour transmettre (parler), appuyez sur le bouton Push-

To-Talk (PTT). Pour recevoir des appels, relâchez le bouton PTT.

La transmission 50% du temps, ou moins, est importante car cette

radio génère une exposition mesurable à l'énergie RF uniquement

lors de la transmission (en termes de mesure pour la conformité aux

normes).

• Tenez la radio en position verticale devant le visage avec le

microphone (et les autres parties de la radio, y compris l'antenne)

à au moins 2,5 cm du nez. Garder la radio à la bonne distance est

important car les expositions RF diminuent avec la distance de

l'antenne. L'antenne doit être tenue à l'écart des yeux.

• Lorsqu'elle est portée sur le corps, placez toujours la radio dans

un clip, un support, un étui, un étui ou un harnais de sécurité

approuvés pour ce produit. L'utilisation d'accessoires non approuvés

peut entraîner des niveaux d'exposition qui dépassent les limites

d'exposition aux RF de l'environnement professionnel / contrôlé.

Using Tips

Max. SAR Level(s) Reported Limit (W/Kg)

2.48 W/kg 1g Head SAR

3.68 W/kg 1g Body SAR 8.0

INFORMATION CONCERNING SAR FOR FCC

Know the Radio

Using Tips

INFORMATION CONCERNING SAR FOR FCC

User Interface

Know the Radio

Signal strength identication Battery level identication

No signal Strong

Weak Excellent

Medium

0 grid 1 grids

2 grid 3 grids

Transmitting power identication Scanning function identication

High

Low

Scanning

Receiving non-priority channel

Receiving priority channel 1

Receiving priority channel 2

About the Device

LCD Icon

1 Antenna 12 Alarm key

2 P1 key 13 LED indicator

3 PTT key 14 Accessory port

4 P2 key 15 LCD display

5 Up key 16 Microphone

6Menu/OK key 17 Return key

7 Left key 18 Right key

8 Contact shortcut 19 Exit key

9 Speaker 20 Down key

10 Channel knob 21 Alphanumeric keypad

11 Power switch/volume control knob 22 Charging contact

Know the Radio

Message identication

Unread message(s) Inbox is full

Other identications

Direct mode

Repeater mode

Encryption enabled

Key locked

Recording enabled

Recorder full

Emergency alarm enabled

Know the Radio

Radio LED Indicators

Know the Radio

Radio Status

Standby

Low Battery

Transmit (TX)

Receive (RX)

Programming Mode (Read from Radio)

Programming Mode (Write to Radio)

Scanning

Call hang time mode

LED Indication

Blinking Green

Blinking Red

Solid Red

Solid Green

Fast Blinking Red

Fast Blinking Green

Slow Blinking Orange

Solid Orange
