ILLUSTRATEDPARTSLIST

IMICORNELIUSINC.

ONECORNELIUS PLACE

ANOKA,MN55303-6234

1.800.238.3600

ENDURO300 (ED300)POST-MIXDISPENSER

4-19-95,Revised 10--27--95

ãIMICorneliusCo., 1995

ManualPartNo.92185 1 of6

ILLUSTRATEDPARTSLIST

IMICORNELIUSINC.

ONECORNELIUS PLACE

ANOKA,MN55303-6234

1.800.238.3600

ENDURO300 (ED300) (POST-MIX)

FIGURE1.ENDURO300 ASSEMBLY

16 17

35 37

38 39

SEE FIGURE2

2122

Item

No.PartNo.Name

1 21491 Slide,Gate

2 22081 Restrictor,Gate

3 27107 Bracket, LeverDepressor

4 15213 Agitator,Left

5 29483 Cover,Rear

Item

No.PartNo.Name

6 29538

29495 Panel,Lower,LEV

Panel,Lower,Corco

7 29496 Extension,DripTray

8 29497 Cover,ElectricalBox

9 29507 Bracket, MotorSupport

ManualPartNo.92185

4-19-95,Revised 10--27--95

(

)

ILLUSTRATEDPARTSLIST

IMICORNELIUSINC.

ONECORNELIUS PLACE

ANOKA,MN55303-6234

1.800.238.3600

ENDURO300 (ED300) (POST-MIX)

Item

No.PartNo.Name

10 29509 BaseAss’y

11 Dispensing ValvePanelAss’y(See

Figure 5)

12 15214 Agitator,Right

13 29562 Spacer,Drain

14 29664 Lever, IceChute

15 29667 Support, ProductLines

16 29668 Baffle,ProductLines

17 53136 Cover

18 29493 Bracket, MotorMount

19 30895 Switch

20 31007 Boot, Switch

21 53011 Elbow

22 53186 Clamp

23 31622 Bulb,Florescent

24 32954 SolenoidAss’y(See Figure 3)

25 32977 Switch,Power

26 33352 ElectricalBoxAss’y(See Figure 4)

27 50328 Spacer

28 50097 Gasket, Hopper

29 52814 Insulation,ColdPlate,Side

30 52815 Insulation,ColdPlate,Back

31 51891 Gasket, Gate

32 51908 Plug

33 52882 Plate,Mounting, IceChute

34 52883 Shell, IceChute

35 52884 Cover,ColdPlate

36 71024 ”S”--Clip

37 53185 Disk,Agitator

38 52937

52952 Merchandiser,Black

Merchandiser,Gray

39 52943 Lens, Inner

40 53230

53229 DripTray,Black

DripTray,Gray

Item

No.PartNo.Name

41 52957 HopperAss’y

42 52967 Plug

43 52972 Tab,Retaining

44 70016 HexNut, No.10-32

45 70017 Insert, Nylon,No.10-32

46 70056 Washer,Flat, No.10

47 70067 Washer

48 70076 HexNut, No.8-32

49 70104 Nutsert, No.8-32

50 70164 Screw,Phil Truss Hd., No.8-32 By

3/4-In.Long

51 70171 Screw,Phil Truss Hd., No.8-32 By

3/8-In.Long

52 70178 Screw,Phil Truss Hd., No.8-32 By

1/2-In.Long

53 70204 Screw,Phil Truss Hd., No.8-32

54 70215 Screw,HexWasherHd., No.8-32

By1/4-In.Long

55 70217 Screw,HexWasherHd., No.8-32

By1/2-In.Long

56 41459 O--ring

57 70474 Retaining Ring

58 70478 Clip,Pushon

59 70555 Screw,Phil Truss Hd., No.8-32 By

3-In.Long

60 70847 Washer,Switch

61 70959 Nutsert, No.8-32

62 70997 Strike

63 70998 Latch

64 70999 Cup Rest

65 70531 Ball Stud

66 70075 HexNut, No.6-32

67 71010 Washer,No.8

68 53135 Lid,Cover

ManualPartNo.92185

4-19-95,Revised 10--27--95

(

)

ILLUSTRATEDPARTSLIST

IMICORNELIUSINC.

ONECORNELIUS PLACE

ANOKA,MN55303-6234

1.800.238.3600

ENDURO300 (ED300) (POST-MIX)

Item

No.PartNo.Name

1 29303 Plate,MotorMount

2 29654 Plate,Adjustable,Motor

3 30794 Heater,Motor

4 32498 Motor

5 51859 Seal,MotorShaft

6 51860 Gasket, Motor

7 70018 HexNut, 1/4-20

8 70043 Washer,Flat, 1/4

9 70048 Washer,Lock,1/4

10 70257 Screw,Phil Truss Hd,1/4-20 By

1/2-In.Long

11 70260 Screw,Phil Rd.Hd., 1/4-20 By1-In.

Long

12 70341 Spring,Gate

13 70992 Receptacle,1/4-turn

14 70993 Retainer,1/4-turn

15 70994 Stud,1/4-turn

FIGURE2.MOTOR COMPONENTS

Item

No.PartNo.Name

620300501 GateSolenoidAss’y

1 28172 Plate,SolenoidMounting

2 28173 Arm,Gate Lift

3 32957 Solenoid

4 50752 Isolator

5 50754 Bearing,GateArm

6 70162 Screw,No.8-32 By1/4-In.Long

7 70015 HexNut, No.10-32

8 51689 Locktite

9 70165 Screw,No.8-32 By5/8-In.Long

10 70057 Lockwasher,No.10

11 70067 Washer, .218 I.D.By.875 O.D.

12 51348 Spacer

13 71007 Spring,SolenoidArm

14 70052 Flatwasher,No.8

15 02101 DualGateSlide Kit

FIGURE3. GATE SOLENOID ASSEMBLY

ManualPartNo.92185

4-19-95,Revised 10--27--95

(

)

ILLUSTRATEDPARTSLIST

IMICORNELIUSINC.

ONECORNELIUS PLACE

ANOKA,MN55303-6234

1.800.238.3600

ENDURO300 (ED300) (POST-MIX)

25 12 3

10 11

13 14

15 1617

1920 21

2324 26

2318 23

FIGURE4.ELECTRICALBOXASSEMBLY

Item

No.PartNo.Name

33352 ElectricalBoxand ReflectorAss’y

1 29494 Box,Electrical

2 30514 Clamp,Capacitor

3 30774 Capacitor

4 30995 PowerCord

5 31107 TerminalBlock

6 31620 Starter

7 31621 Ballast

8 31763 Timer,RepeatCycle

9 32042 Socket, Starter

10 32579 Harness,Motor

11 32682 Transformer,120/24V

12 32746 Holder,Lamp

13 32782 Harness,DispenserSwitch

14 32958 Rectifier

15 33302 Harness,Solenoid

Item

No.PartNo.Name

16 50458 StrainRelief

17 50459 Bushing,Harness

18 50475 Bushing,Jumper

19 70015 HexNut, No.10-32

20 70131 Screw,SlRdHd,No.4-40 By3/8-In.

Long

21 70147 Screw,Phil RdHd,No.6-32 By

1/2-In.Long

22 70153 Screw,Phil RdHd,No.8-32 By

3/4-In.Long

23 70215 Screw,SlWasherHd,No.8-32 By

1/4-In.Long

24 70217 Screw,SlWasherHd,No.8-32 By

1/2-In.Long

25 31206 Relay

26 70120 Screw,No.10-32 By1/2-In.Long

27 70075 HexNut, No.6-32

28 70152 Screw,No.6-32 By3/8-In.Long

ManualPartNo.92185

4-19-95,Revised 10--27--95

(

)

ILLUSTRATEDPARTSLIST

IMICORNELIUSINC.

ONECORNELIUS PLACE

ANOKA,MN55303-6234

1.800.238.3600

ENDURO300 (ED300) (POST-MIX)

FIGURE5.VALVE PANELASSEMBLY

Item

No.PartNo.Name

29647

29648

29645

29646

29510

29539

ValvePanelAss’y,8Corco

ValvePanelAss’y,8 LEV

ValvePanelAss’y,10 Corco

ValvePanelAss’y,10LEV

ValvePanelAss’y,12 Corco

ValvePanelAss’y,12LEV

1 29316 ManifoldAss’y,2-Flavor

2 29317 ManifoldAss’y,1-Flavor

3 29315 ManifoldAss’y,3-Flavor

Item

No.PartNo.Name

4 40502 Clamp

5 52792

50299 Tube,LEV

Tube,Corco

6 29641

29642

29643

29644

29490

29532

Panel,Dispensing Valve,8Corco

Panel,Dispensing Valve,8 LEV

Panel,Dispensing Valve,10 Corco

Panel,Dispensing Valve,10 LEV

Panel,Dispensing Valve,12 Corco

Panel,Dispensing Valve,12 LEV

ManualPartNo.92185

4-19-95,Revised 10--27--95

(

)
