Food Processor Blender 9635
Instructions
v003 2/03/15
PARTS
1. Blender jug cap
2. Blender jug cover
3. Blender jug
4. Speed control knob
5. Base
6. Plastic spatula
7. Push cover
8. Processor jug cover
9. Processor jug
10. Reversible blade
11. Stainless steel blade
12. Plastic blade
13. Rotor
14. Lid cover
15. Grinder
16. Grinder cover
17. Blade cover
TO ASSEMBLE THE GRINDER
• Attach the grinder cover (16) to the grinder (15) and
twist it anti-clockwise to secure.
• Remove the blender jug from the base, if fitted, and
attach the assembled grinder. Secure by twisting
anti-clockwise.
• Ensure al gnment arrows are
n l ne before use.
1
2
6
7
8
9
10
11
12
13
14
15
16
17
3
4
5
ASSEMBLY
Before use, wash all parts that come into contact with
food thoroughly.
TO ASSEMBLE THE BLENDER:
• Attach the blender jug cover (2) to the blender jug
(3) and push down the jug cover to secure.
• Fit the cap (1) into the blender jug cover (2) and
twist clockwise to secure.
• Attach the assembled
blender jug to the taller side
of the base (5) ensuring the
nodules on the jug are
aligned with the lugs on
the base and twist
anti-clockwise to
secure.
• Ensure
al gnment arrows
are n l ne before
use.
Please read carefully before use
and reta n for future reference.
Alignment
arrows
Alignment
arrows
TO ASSEMBLE THE LID COVER
•If using neither the blender nor
grinder, attach the lid cover
(14) to the base and twist anti-
clockwise to secure.
TO ASSEMBLE THE PROCESSOR
• Select the appropriate
blade and attach to the rotor.
• Attach the processor jug (9) to
the shorter side of the base.
• Place the assembled rotor
section over the column in the
centre of the processor jug as
diagram 1.
• Attach the processor jug cover
(8) to the processor jug and
twist anti-clockwise to secure,
ensuring the long plastic catch
fits into the recess on the taller
side of the base. Push food
into the processor using the
push cover (7) as diagram 2.
Diagram 1
Diagram 2
OPERATION
• Once the chosen accessories have been fitted, check the
speed knob is at “0” and then plug into the mains.
• The appliance should be used for a maximum of 60
seconds before being allowed to cool.
• Always switch off at the mains and unplug before
removing any accessories.
USING THE PROCESSOR
• When using the processor, ensure that the blender jug is
removed and the lid cover is fitted.
• To cut food into strips, place the reversible blade (10) onto
the rotor with the slicing blade uppermost and twist
clockwise to secure as diagram 3.
• To cut food into pieces, place the reversible blade (10) onto
the rotor with the slicing blade lowermost and twist
clockwise to secure as diagram 4.
• To further chop the food, add the stainless steel blade (11)
to the rotor.
• Once the food is processed, lift out the jug.
USING THE BLENDER
• Remove the blender jug cover by twisting the cover anti-
clockwise.
• Place food into the blender jug, and replace the blender
jug cover twisting it clockwise until it clicks into position.
• Set the speed knob to the desired setting.
• Once the food is blended, twist the jug clockwise to
release. Lift out the jug.
USING THE GRINDER
• Place the foodstuff into the grinder, ensuring that only
80% of the grinder is taken up.
• Set the speed knob to the desired speed.
• Once ground, twist the grinder clockwise to release.
Diagram 3 Diagram 4
WARNING
• Before use, check that the mains voltage shown on the
appliance matches that in your home.
• Check all parts, including the power cable for damage before
use. Do not use if any part is damaged in any way.
• Do not allow the power cord to hang over the edge of the work
surface or to touch hot surfaces.
• Keep away from heat sources and naked flames.
• Do not touch the surface of the appliance during use as it may
become hot, apart from the handles and knobs.
• Do not allow children to play with or near the appliance.
• Use only one function of the appliance at a time.
• For indoor, domestic use only.
• Do not touch the cutting blades.
• Do not insert any objects into the jugs while in use. A spatula
may be used when not in use.
• Do not run the appliance when the jug is empty.
• Do not attempt to remove the jug cover until the blades have
stopped moving.
• Use only for the intended use as described in this manual.
• This appliance should only be used by persons (including
children) with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, providing they have been
given supervision or instruction concerning use of the appliance
by a person responsible for their safety.
• The appliance is not intended to be operated by means of an
external timer or separate remote-control system.
TROUBLESHOOTING
No function:
• Check the appliance is plugged in to the mains and the mains
socket is switched on.
• Check that all 3 alignment points are correctly located. If any
of the 3 points are incorrectly located, the safety feature will
cut power to the appliances.
CLEANING
• Always switch off the appliance at the mains and unplug before
cleaning.
• After use, disconnect the accessories that require cleaning and
wash them in warm, soapy water. Dry thoroughly before
replacing or storing.
• Wipe the base clean with a soft damp cloth and dry
immediately.
• Wipe any food from the power cord.
• Do not use abrasive scourers or abrasive cleaning agents.
• Never immerse the base in water or any other liquid.
DISPOSAL
• Dispose of all paper, cartons, spent batteries and plastic in
accordance with your local recycling regulations. At the end of the
product’s lifespan please dispose of it at an authorised household
waste recycling centre.
DECLARATION OF CONFORMITY
We, The Enterprise Department Ltd.
of 11 Bridge Street, Bishop’s Stortford, Hertfordshire, UK. CM23 2 U
in accordance with the following Directive(s):
Electromagnetic Compatibility 2004/108/EC
EN 55014-1: 2006+A1
EN 55014-2: 1997+A1+A2
EN 61000-3-2: 2006+A1+A2
EN 61000-3-3: 2008
Low Voltage Directive 2006/95/EC
EN 62233:2008
EN 60335-1:2002+A11+A1+A12+A2+A13+A14+A15
EN 60335-2-14:2006+A1
ZEK 01.4-08/11.11
Hereby declare that:
Food Processor & Blender
Model number: 9635 (W-809A)
I hereby declare that the equipment named above has been
designed to comply with the relevant sections of the above
referenced specifications. The unit complies with all applicable
Essential Requirements of the Directives.
Mr. Stuart Fowler
Imports Director
August 2013
