RESIDENTIAL – WALL BRACKET & WALL CLOUD

495

COOPER LIGHTING

• Uses one or two

ﬂuorescent lamps

(not included)

• Contemporary styling

• Die formed steel housing

• Baked white enamel ﬁnish

• Extruded smooth opal

white acrylic refractor

• 180° uniform light

distribution

• Decorative opaque injection

molded white end plates

• Easy wiring access

• Vertical wall or horizontal

ceiling mounting

application

• Suitable for damp locations

• UL/CUL Listed

WALL BRACKET

WALL CLOUD

SERIES

2', 3' or 4'

1 or 2 Lamps

RESIDENTIAL

ALL PURPOSE

WALL BRACKETS

DIMENSIONS(2) DESCRIPTION

The Metalux Residential Wall

Bracket Series is an energy

efﬁcient luminaire designed for

versatility in application and

performance. The series feature

an opal white acrylic refractor

that produces a 180° uniform

light distribution pattern. The

versatile Wall Bracket Series

combines quality and economy

in a multi-purpose wall bracket.

The luminaire is perfect for

illuminating corridors, stairwells,

lavatories, dressing rooms,

basements, utility/task and area

lighting.

The Wall Cloud Series

incorporates a vacuum formed

soft white acrylic lens for more

residential appeal.

NOTES: (1) For complete product data, reference the Fluorescent Speciﬁcation binder. (2) Speciﬁcations & Dimensions subject to change without notice. (3) “E” in catalog

number means Electronic Ballast that operates T12 lamps. (4) Consult your Cooper Lighting Representative for availability and ordering. (5) Commercial Grade Electronic

Ballast (EB81) available on a “made to order” basis.

ORDERING INFORMATION(4)

Catalog Shipping

Number (1, 3, 5) Description Wt.

(WITH WHITE ENDS / 1 LIGHT)

6212 1 lamp 24", 20W T12 7 lbs. (3.2kg)

6313 1 lamp 36", 30W T12 9 lbs. (4.1kg)

6414 1 lamp 48", 40W T12 12 lbs. (5.4kg)

(WITH WHITE ENDS / 2 LIGHT)

6222 2 lamp 24", 20W T12 7 lbs. (3.2kg)

6424 2 lamp 48", 40W T12 12 lbs. (5.4kg)

(WALL CLOUD)

6232 2 lamp 24", 20W T12 8 lbs. (3.6kg)

6434 2 lamp 48", 40W T12 13 lbs. (5.9kg)

6434E(3) 2 lamp 48" with LE3, 40W T12 13 lbs. (5.9kg)

6434-REB1 2 lamp 48" with LE3, 32W T8 13 lbs. (5.9kg)

Wall Bracket Series

Wall Cloud Series

COOPER LIGHTING - METALUX®

WALL BRACKET

WALL CLOUD
